Summary of Contents for Trantec S4.5 Series
- Page 1 Connevans S S o o l l u u t t i i o o n n s s t t o o i i m m p p r r o o v v e e t t h h e e q q u u a a l l i i t t y y o o f f l l i i f f e e This product may be purchased from Connevans Limited secure online store at www.DeafEquipment.co.uk DeafEquipment.co.uk...
- Page 2 OPERATING INSTRUCTIONS S4.5 SERIES © BBM Electronics Group Ltd, 2000...
- Page 3 Guarantee: All Trantec products are guaranteed for a period of one year from date of purchase against defects in materials and workmanship. In the event of a claim under guarantee the system should be returned to your dealer in its original packaging and with proof of purchase. Defects caused by modification, misuse or accident are not covered by the guarantee.
- Page 4 The status of the two antennas (Pass or Not Connected) is displayed briefly when the power is first connected. Connect the mains power adapter to the DC IN rear panel connection and to the mains supply. Always and only use the Trantec power supply provided with your system.
- Page 5 characters at the cursor position. Pressing the SELECT button will move the cursor along one position. Pressing the SELECT button on the last character in the name will return you to the normal display. It will be necessary to change each of the eight character locations in turn. If you miss the character you want, simply scroll round until it comes back again.
- Page 6 S4.5 Beltpack and Guitar Transmitters: • Setting Up: Screw the external antenna into the antenna connector on the top of the beltpack. The antenna can either be a short wire or a helical type. Under no circumstances should the length of a wire antenna be shortened. Neither should a wire antenna be coiled up or wrapped with the audio lead - this will reduce the performance of the radio system.
- Page 7 S4.5 Technical Specifications: • S4.5RX: RF Frequency Range: TV Channel 70 UK (others available on request) Channel Capability: 4 Channels Diversity Control: Microprocessor based Digital Switching RF Sensitivity: 0.5uV for 12dB sinad minimum Image Rejection: 1st IF >75dB 2nd IF >70dB 2nd IF Bandwidth : 100KHz.
