Summary of Contents for JBL SYNTHESIS S3-SPP
- Page 1 SYNTHESIS Model S3-SPP OWNER’S MANUAL...
- Page 2 CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLAR- IZED) PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUT- LET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER AVEC UN PROLONGATEUR.
- Page 3 7.0 ______ CALIBRATION TEMPLATE JBL Synthesis System Owner's Manual ©1994 Harman Consumer Group JBL and Synthesis are registered trademarks of JBL Incorporated. All Rights Reserved Manual Designed by Harman Consumer Group, Marketing Services • Woodbury, N.Y. JBL Consumer Products, Inc.
- Page 4 IMPORTANT SAFEGUARDS FOR AUDIO PRODUCTS 9. Heat – The product should be situated away PLEASE READ CAREFULLY from heat sources such as radiators, heat ALL THE FOLLOWING registers, stoves, or other products that produce heat. If placed near an amplifier, IMPORTANT SAFEGUARDS check with the manufacturer for applicability.
- Page 5 IMPORTANT SAFEGUARDS FOR AUDIO PRODUCTS Figure-1 ANTENNA LEAD IN Example of Antenna Grounding WIRE as per National Electrical Code ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) 17.
- Page 6 SYNTHESIS THREE SIGNAL PROCESSING PACKAGE (S3-SPP) 2.1 Introduction Congratulations on your purchase of JBL’s Synthesis Three S3-SPP Signal Processing Package. This product has been designed and built with careful attention to sound quality and aesthetics, and should certainly enhance your lis- tening experience.
- Page 7 CH 4 CH 5 CH 1 CH 2 SIGNAL PROCESSING PACKAGE SCREEN BOOST & HF CONTOUR LEFT FRONT CENTER RIGHT FRONT SUBWOOFER S3-SPP INPUTS JBL INCORPORATED POWER SCREEN BOOST NORTHRIDGE, CA SIG GND OUTPUTS AUTO LIFT (160mA MAX) CHASSIS PARALLEL...
- Page 8 MAKING MAKING CONNECTIONS CONNECTIONS Connecting the Synthesis S3-SPP to your home to the designated front left input channel on the theater system is extremely straightforward. power amplifiers. Do this for the remaining Using the supplied interconnect kit, connect the outputs: center, right front, and subwoofer.
- Page 9 25-80 Hz for finer low frequency or ask your JBL Synthesis dealer. control. It is recommended that your JBL Synthesis dealer set the sliders for optimum performance. Please put on the included secu- rity cover to prevent accidental adjustments.
- Page 10 The screen boost can be controlled automatically Note: This unit comes configured with the by the Synthesis Three Home Media System or screen boost circuits activated for the center Cinema Only System. It can also be left on per- channel only. If your front left and right speak- manently, or be disabled.
- Page 11 5dB. If your system is being installed and calibrated by a trained JBL installer, then he or she can fine tune this control. If you are using this unit with another manufacturer’s home theatre system, then it is generally advised to leave this con- trol in the 0dB position.
- Page 12 SPECIFICATIONS SPECIFICATIONS Equalizer: Channels Five Bands (L/C/R) (11) 1/3-Octave ISO Spacing Bands (Sub) (11) 1/6-Oct ISO Spacing Type Interpolating Constant-Q Accuracy Travel 20mm Range ±6dB High Frequency Contour +10dB @ 19.5kHz Screen Boost 2.1kHz-5.4kHz; single pole Inputs: Type Active Unbalanced Impedance 10.5k Ohms Maximum Level...
- Page 13 JBL will be happy to pay all labor and material expenses for all repairs covered by this warranty. If necessary repairs are not covered by this warranty, or if a unit is...
- Page 14 CALIBRATION TEMPLATE CALIBRATION TEMPLATE Date: ______________________ Owner:_____________________ Installer:____________________...
