2-way 5" Powered Multimedia Speaker System
TECHNICAL MANUAL
All manuals and user guides at all-guides.com
JBL Consumer Products Inc.
80 Crossways Park West
Woodbury, N.Y. 11797
1-800-336-4JBL in the USA
A Harman International Company
Part No.: 1112-MEDIA4
Advertisement
Related Manuals for JBL Media 4
Summary of Contents for JBL Media 4
- Page 1 All manuals and user guides at all-guides.com Media 4 2-way 5" Powered Multimedia Speaker System TECHNICAL MANUAL JBL Consumer Products Inc. 80 Crossways Park West Woodbury, N.Y. 11797 1-800-336-4JBL in the USA A Harman International Company Part No.: 1112-MEDIA4...
- Page 2 All manuals and user guides at all-guides.com...
- Page 3 All manuals and user guides at all-guides.com...
- Page 4 All manuals and user guides at all-guides.com...
- Page 5 All manuals and user guides at all-guides.com...
-
Page 6: Printed Circuit Boards
All manuals and user guides at all-guides.com Two-Way Stereo Speaker System PRINTED CIRCUIT BOARDS (viewing trace layer through the board) - Page 7 All manuals and user guides at all-guides.com...
- Page 8 All manuals and user guides at all-guides.com...
-
Page 9: Packaging Exploded View
All manuals and user guides at all-guides.com Two-Way Stereo Speaker System PACKAGING EXPLODED VIEW PACKAGING INSERT IC-5023 (C) SURVEY CARD CA-MEDIA4 (A) WARRANTY CARD CG-JBL-E (A) AC POWER SUPPLY OWNER'S MANUAL ACC-16A00221 UM-MEDIA4 (C) STEREO MINIPLUG CABLE L-20XL (C) TOP FOAM INSERT... - Page 10 All manuals and user guides at all-guides.com...
- Page 11 All manuals and user guides at all-guides.com Media 4 Two-way Stereo Speaker System Media 4 Schematic Diagram SEALED INSIDE CUP +5.2V +5.2V +5.26V +5.2V +5.2V +5.26V +5.2V +5.26V +8.9V +3.1V +10.5V +6.66V 0V +6.66V 0V +6.66V 2.0V 0.2V 0V +6.66V +1.8V...
- Page 12 All manuals and user guides at all-guides.com Two-way Stereo Speaker System Media 4 Schematic Diagram SEALED INSIDE CUP +5.2V +5.26V +5.2V +8.9V +10.5V 2.0V 0.2V +1.8V +14V +15.2V...
- Page 13 All manuals and user guides at all-guides.com Media 4 Media 4 Schematic Diagram +5.2V +5.2V +5.26V +5.2V +5.26V +5.2V +5.2V +5.26V +3.1V +6.66V 0V +6.66V 0V +6.66V 0.2V 0V +6.66V +1.8V +14V +15.2V Test voltages are printed in orange. Operational Mode voltages are displayed in boxes.
