PO Box 501 Concord, New Hampshire 03302-0501
Model Filt II-14W shown banked
to (2) 14" fryers
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury or death. Read the installation, operating
and maintenance instructions thoroughly before installing or servicing this
equipment.
DO NOT store or use gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
After installation of this equipment, immediately contact your local gas
supplier to obtain information about what action to take whenever any
person smells gas. Post this information in a prominent location.
Keep this Manual in a Convenient Location for Reference
FM-14
Quality Equipment For The Restaurant, Supermarket, and Bakery Industries
FM-18
Filt II-14/14W
Filt II-18/18W
Anets, Inc.
Tel: 603-225-6684 • Fax: 603-228-5231
Model FM-14 Filter Mate
shown under the base system
of (2) 14" fryers
DANGER
FOR YOUR SAFETY
!
WARNING
!
The Anets GoldenLine
1
GoldenFRY
Models
FM-14 Filter Mate
FM-18 Filter Mate
Filt II-14/14W Filtronic
Filt II-18/18W Filtronic
Installation,
User Operation
&
Maintenance
Manual
L20-386 R2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anets GoldenFRY FM-14
Summary of Contents for Anets GoldenFRY FM-14
- Page 1 Post this information in a prominent location. Keep this Manual in a Convenient Location for Reference The Anets GoldenLine FM-14 Quality Equipment For The Restaurant, Supermarket, and Bakery Industries...
-
Page 2: Table Of Contents
These would be packed with the fryers, if ordered. NOTE: A Parts List for each Anets Filter System is among the items shipped with each unit. If an additional copy of this list is needed, please contact the factory as directed on the back cover. -
Page 3: Filter Unit Preparation Instructions
INSTALLATION This Manual will detail the Installation and Operation of the Filter-Mate system, with notes where the Filtronic II System differs. Both the Filter Mate and Filtronic II Systems enable the user to safely and efficiently filter the cooking oil or shortening from a fryer in a banked row while the other fryers in that row are still being used. -
Page 4: Filter System Diagrams
FILTER MATE TANK Filter envelope clip Lift out handle Quick connect coupling Knurled retaining nut Pump quick-connect coupling Filter envelope Return line and optional hose connection FILTRONIC II TANK Lift out handle Quick connect coupling Knurled retaining nut Pump quick-connect coupling Filter envelope Filter envelope clip L20-386 R2... -
Page 5: Filtering Instructions
FILTERING INSTRUCTIONS CAUTION Never operate the filter unit unless the cooking oil or shortening in the fryers has been brought up to cooking temperature. WARNING Always wear protective heat-resistant gloves when performing the filtering operation. FILTERING 1. Before filtering the shortening in a fryer, turn the thermostat knob to “OFF” or the Gas Valve to “PI- LOT”... -
Page 6: Oil Disposal Instructions
Note On Using Filter Powder If filter powder is being used, add 1 cup of powder (for 14” fryers) or 2 cups (for 18” fryers) to either the fry tank or the filter tank. If added to fry tank, make sure powder is completely flushed during fry tank cleaning (Step 3) before closing drain valve (Step 4). -
Page 7: Replacing The Filter Paper
REPLACING THE FILTER PAPER If the filter paper becomes torn, or if the time to filter the oil from one unit becomes excessive, it is time to replace the Filter Envelope. DANGER Make sure the filter pan has cooled completely to room temperature before attempting to change the paper. -
Page 8: Filter Troubleshooting Guide
Inspect for blockages in the lines. Replace with a clean filter paper envelope. WARNING Only use filter paper envelopes from Anets that have been specifically designed for this filter system. Using the wrong type of filter paper can cause damage to the pump system, and will void the warranty. -
Page 9: Filter Warranty
Limitations of Liability In the event of a warranty or other claim, the sole obligation of Anets, Inc. will be the repair or replacement, at the Company’s option, of the appliance or the component part. This repair or replacement will be at the expense of Anets, Inc. except as limited by this warranty statement. Any repair or replacement under this warranty does not constitute an extension in time to the original warranty. - Page 10 Anets Authorized Service and Factory at: Parts representative (ASAP) covering 1-603-225-6684 World Wide your area, or contact Anets at the number listed to the left. Website Address: www.anets.com MAILING ADDRESS – P.O. BOX 501, CONCORD, NH 03302-0501 SHIPPING ADDRESS – 10 FERRY ST., CONCORD, NH 03301...
