13862-02 1.2022 TABLE OF CONTENTS 1. Introduction ..................... 1 2. Operation ....................3 2.1 Installation ....................3 3. System ......................6 3.1 Specifications .................... 6 3.2 Components .................... 11 3.2.1 Gateway (H210) ................11 3.2.2 Repeater (H110) and Climate Station (H111)........13 3.2.3 Sensor Nose (H321) ...............
Page 3: Introduction
AROYA 1. INTRODUCTION Thank you for choosing the AROYA system from METER Group. Prior to use, verify the sensor arrived in good condition. The AROYA system works in a wireless mesh network. A wireless mesh network allows data and files to be transferred from one device to another through wireless transmission. The AROYA system components are FCC approved (Class A) and can communicate wirelessly between each other.
Page 4 INTRODUCTION AROYA System Conﬁguration Existing Customer Network Modem Misc other equipment Port 8883, Port 8443 Switch (e.g., Wi-Fi router) ® Internet *PoE injector (if needed) AROYA Gateway AROYA AROYA AROYA Repeater Repeater Climate AROYA AROYA AROYA Wireless Wireless Repeater Climate Climate Sensor Sensor...
Page 5: Operation
Please read all instructions before operating the AROYA to ensure it performs to its full potential. PRECAUTIONS METER sensors are built to the highest standards, but misuse, improper protection, or improper installation may damage the sensor and possibly void the manufacturer’s warranty. Before integrating AROYA into a system, make sure to follow the recommended installation instructions and have the proper protections in place to safeguard sensors from damage.
Page 6 Install the Repeater at approximately shoulder height in a hallway. Use Mounting screws inserted into the mounting bracket to secure to wall. All system configuration work is done at METER before installation occurs at Configuration the customer site. Connect Repeater to PoE and Verify...
Page 7 (Figure 10) until the LED flashes green. Mounting Insert sensor into slabs or larger substrate types. All system configuration work is done at METER before installation occurs Configuration at the customer site. Wake Sensor Nose and Verify The Sensor Nose is shipped to the customer in SLEEP mode, indicated by a solid red status LED light on the end where the cable is connected.
Page 8: System
SYSTEM 3. SYSTEM This section describes the specifications and components of the AROYA Gateway, Repeater, Climate Station, and Sensor Nose. 3.1 SPECIFICATIONS MEASUREMENT SPECIFICATION ATMOS 14 Temperature and Relative Humidity (RH) Sensor Relative Humidity (RH) Range 0–100% RH (0.00–1.00) Resolution 0.10% RH Accuracy Sensor measurement accuracy is variable across a range...
Page 9 AROYA Accuracy Sensor measurement accuracy is variable across a range of temperatures. Refer to the chart in Figure Figure 4 Temperature sensor accuracy Equilibration Time <165 s (response time in 1 m/s air stream) (t, 63%) Long-Term Drift <0.03 °C/year, typical Vapor Pressure Range 0–47 kPa...
Page 10 SYSTEM Barometric Pressure Range 1–120 kPa Resolution 0.01 kPa Accuracy ±0.05 kPa at 25 °C TEROS 12 Soil Moisture, Temperature, and Electrical Conductivity (EC) Sensor Volumetric Water Content (VWC) Range Mineral soil calibration 0.00–0.70 m Soilless media 0.0–1.0 m Apparent dielectric 1 (air) to 80 (water) permittivity (ε...
Page 11: Gateway (H210)
AROYA COMMUNICATION SPECIFICATIONS Output Gateway Ethernet (PoE) Wireless communication Bluetooth mesh (Gateway, Repeaters, Sensors) Sensor types SDI-12 based Antenna Make Raltron Model number RST-W2-P-110-SMA-H Gain 4.15 dBi vertically polarized, dipole professionally installed NOTE: This radio transmitter IC-5123A-MGM12P0 has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
Page 12 SYSTEM ATMOS 14 w/radiation shield Diameter 10.0 cm (3.94 in) Height 8.5 cm (3.35 in) Sensor Station (H321) Length 6.99 cm (2.75 in) Width 18.00 cm (7.10 in) Height 3.02 cm (1.19 in) TEROS 12 Length 9.4 cm (3.70 in) Width 2.4 cm (0.95 in) Height...
Page 13 AROYA ELECTRICAL CHARACTERISTICS Power Lithium-ion (Li-on) Battery cannot be replaced by the user. rechargeable battery NOTE: The Gateway device does NOT have a battery. It is powered over Ethernet (PoE). Power over Ethernet (PoE) 42.5–57.0 V, up to 25.5 W CAUTION: If using a nonmanufacturer supplied PoE device to power this system, ensure that the voltage rating does not exceed the recommended values stated above.
Page 14 SYSTEM Antenna Front/top cover (end cap) LED indicates active internet connection (ﬂashing orange) NOTE: If the internet connection is slow, the light may ﬂash green instead of orange. This also indicates active connection. Ethernet POE port (RJ 45) Figure 6 AROYA Gateway—front, top view Back/bottom cover (end cap) Red LED...
Page 15: Repeater (H110) And Climate Station (H111)
AROYA 3.2.2 REPEATER (H110) AND CLIMATE STATION (H111) The AROYA Repeater/Climate Station receives data from the Sensor Nose and transmits data to the gateway wirelessly. The Repeater acts as a range extension for the network and funnels the data to the Gateway device. The Repeater operates on a Bluetooth Mesh network and relies on an active PoE connection to supply power to the device.
Page 16 SYSTEM Ethernet cable to PoE Blue seal grommet Outer cover gland Climate station gland Solar panel Repeater ATMOS 14 in radiation shield Ethernet cable from Climate Station Antenna Figure 9 AROYA Climate Station—front, top view...
Page 17: Sensor Nose (H321)
AROYA 3.2.3 SENSOR NOSE (H321) Figure 10 Figure 11 show the AROYA Sensor Nose. The Sensor Nose contain a TEROS 12 soil moisture sensor, location for plant, communication components, and antenna to communicate data gathered by the TEROS 12 to the Repeater or directly to the gateway if the base is close enough.
Page 18 SYSTEM Figure 11 AROYA sensor nose—bottom view...
Page 19: Service
The AROYA Sensor Station, Sensor Nose, Repeater, and Climate Station, and Gateway should be returned to METER in the event that it quits working for any reason or if the battery no longer holds a charge. Please refer to Section 4.2...
Page 20: Troubleshooting
SERVICE 4.3 TROUBLESHOOTING Table 5 lists common problems and their solutions. If the problem is not listed or these solutions do not solve the issue, contact Customer Support. Table 5 Troubleshooting Problem Possible Solutions GATEWAY Check that the device is powered on by observing the red light is on. Confirm internet connectivity through the orange flashing light.
Page 21: Customer Support
NOTE: For products purchased through a distributor, please contact the distributor directly for assistance. 4.5 TERMS AND CONDITIONS By using METER instruments and documentation, you agree to abide by the METER Group, Inc. USA Terms and Conditions. Please refer to metergroup.com/terms-conditions...
Page 22: Appendix A. Compliance Certifications
METER Group, Inc. USA. The use of accessories other than those recommended, or changes to this product that are not approved by METER Group, may void the compliance of this product and may result in the loss of the user’s authority to operate the equipment.
Page 23 AROYA U.S.A. DIGITAL EMISSIONS COMPLIANCE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 24: Canada
(no longer holds a charge), the user should return the Sensor Nose, Repeater, or Climate Station to METER Group, Inc. USA. Do not mix this battery with the solid waste stream. Contact Customer Service for return information.
Page 25 AROYA This device must accept any interference received, including interference that may cause undesired operation. FCC § 15.19 EXIGENCES D’ÉTIQUETAGE Cet appareil est conforme à la partie 15 des règles de la FCC et aux normes RSS exemptes de licence d’Industrie Canada. Son fonctionnement est soumis aux deux conditions suivantes. Cet appareil ne doit pas provoquer d’interférences nuisibles, et Cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable.
Page 26 APPENDIX A Cet équipement génère, utilise et peut émettre de l’énergie de radiofréquence et, s’il n’est pas installé et utilisé conformément au manuel d’instructions, peut provoquer des interférences nuisibles aux communications radio. Le fonctionnement de cet équipement dans une zone résidentielle est susceptible de provoquer des interférences nuisibles, auquel cas l’utilisateur devra corriger les interférences à...
Page 27 AROYA DÉCLARATION CLASSE A DU CANADA Cet appareil numérique de la Classe A est conforme à toutes les exigences du Règlement canadien sur les équipements causant des interférences. RADIO PRECAUTION STATEMENT Radio transmitters IC-5123A-MGM12P0, IC-25859-H110A00, and IC-25859-H310A00 have been approved by Innovation, Science, and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated.
Page 28 (ne tient plus la charge), l’utilisateur doit renvoyer la station du capteur, le nez du capteur, le routeur ou le routeur de climat à METER Group, Inc. USA. Ne mélangez pas cette batterie avec le flux de déchets solides. Contactez le service...
