Summary of Contents for EMC CG 100
- Page 1 O p e r a t i o n M a n u a l o f C G 1 0 0 / 5 0 0 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction 2. Shipping list 3. Specification 4. Overview 5. Operation 6. General data 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw... -
Page 3: Introduction
Introduction The CG 100/500 is a comb generator, it has been developed to provide a means of quickly and very easily checking the accuracy of EMC conducted emission test systems. Key features Small size… battery powered. • Simple operation…simply connect to the EUT port and switch on. -
Page 4: Shipping List
Shipping list CG 100/500 unit Earth bonding cable Charger adapter, CE eligibility criteria USB Cable Operation Manual Wooden storage box Figure 2-1 CG-100/500 Comb Generator and Accessories 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376... -
Page 5: Specification
Specification 3.1 Electrical Specifications Frequency range 100kHz~400MHz Frequency step size 100kHz/500kHz Switchable Maximum Mains Voltage range of LISN 240Vdc or 240Vac, 60Hz Output socket-1 IEC 320-C14 AC Power Inlet Output socket-2 RJ45 Output socket-3 RJ11 3.2 Battery and Charger Battery type Lithium-ion Rechargeable battery Battery Capacity 3.6V/6000mAh... -
Page 6: Overview
Overview Front and Top panel: Frequency step select Switch Power ON/OFF Switch LED indicator Charger connector Item Description Frequency step switch Select frequency step 100kHz or 500kHz Power switch Turn on or off CG100/500 LED indicator Battery status indicator Mini USB connector For Charge input (5Vdc) 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376... - Page 7 Right panel: AC socket Ground stud AC socket Generator output, connect to LISN Ground stud Ground point, connect to Safety earth ground. Left panel: RJ45 connector RJ11 connector RJ-45 socket Generator output, connect to ISN for T4&T8 RJ-11 socket Generator output, connect to ISN for T2 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw...
-
Page 8: Operation
Operation 5.1 Battery charging Before use the CG100/500, please make sure the internal battery has been charged, And the batteries completely charge is suggested. CAUTION During charging, the Power switch shall be in the OFF position! CAUTION The charger input of CG100/500 does not exceed 5.2Vdc. 5.2 General operation 5.2.1 Power On Switch The switch turns the unit power on or off. - Page 9 5.2.3 Connection with LISN 1. Connect an earth bonding wire from the earth stud on the CG100/500 to a reliable earth point, ensuring a good connection. 2. Connect the supplied Power cord from the AC socket on the CG100/500 to the mains EUT outlet on the LISN.
- Page 10 Typical data Step: 100k 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw...
- Page 11 Step: 500k 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw...
- Page 12 ISN of RJ45 (RBW=10kHz, VBW=30kHz) ISN of RJ11 (RBW=10kHz, VBW=30kHz) 1F, No.8, Lane38,Wensan 3rd street,, Kwei Shan Dist, Taoyuan City, Taiwan TEL : 03-3286-998 FAX : 03-3288-376 http://www.emci.com.tw...
