PETROL WATER PUMP
P P W P - 2 0 0 0 & 3 0 0 0
O W N E R S M A N U A L

Advertisement

Table of Contents
loading

Summary of Contents for ParkerBrand PPWP-2000

  • Page 1 PETROL WATER PUMP P P W P - 2 0 0 0 & 3 0 0 0 O W N E R S M A N U A L...
  • Page 2: Table Of Contents

    INTRODUCTION CONTENTS This manual has been produced by Parker Products Ltd. and should be kept with the product and referenced GENERAL SAFETY ........................4-5 for operation, maintenance and troubleshooting. SAFETY SYMBOLS ........................6-7 FOR SAFE OPERATION ......................8-11 This manual contains an overall description of the product, together with all the necessary information for using the WHAT'S IN THE BOX? ......................
  • Page 3: General Safety

    GENERAL SAFETY GENERAL SAFETY For safe operation and maintenance symbols are moulded in relief on the machine or shown on a label. • READ THIS MANUAL CAREFULLY BEFORE USING THIS MACHINE. • FAILURE TO FOLLOW SAFETY PRECAUTIONS OR INSTRUCTIONS CAN CAUSE EQUIPMENT DAMAGE •...
  • Page 4: Safety Symbols

    SAFETY SYMBOLS SAFETY SYMBOLS This symbol, before a safety comment, indicates a PRECAUTION, a WARNING or a DANGER. Ignoring this warning can lead to an accident for yourself or WARNING! To reduce the risk of injury, DANGER! Keep away from sources of ignition. for others.
  • Page 5: For Safe Operation

    FOR SAFE OPERATION FOR SAFE OPERATION • • • IMPORTANT SAFETY INFORMATION Do not allow children to operate the pump. Keep children and pets Do not overload the pump. use the correct pump for your Check all the nuts, bolts, screws are tightened. •...
  • Page 6 FOR SAFE OPERATION FOR SAFE OPERATION GENERAL SAFETY INSTRUCTIONS and other equipment during operation. MAINTENANCE CAUTION - engine speed has been factory set to provide safe operation • • Water pumps are designed to give safe and dependable service if Do not enclose the water pump in any structure.
  • Page 7: What's In The Box

    WHAT’S IN THE BOX WHAT’S IN THE BOX OPERATION WATER PUMP MAIN UNIT +6.5HP 4 STROKE ENGINE STRAINER TUBE TUBE +FUEL TANK & CAP TIE-IN LINKER +STARTER RECOIL +EXHAUST +AIR FILTER +PUMP HOUSING +INTAKE PORT +DISCHARGE PORT TUBE LINKER RUBBER SPARKPLUG CLAMP SEAL...
  • Page 8: Product Features

    PRODUCT FEATURES PRODUCT FEATURES FUEL DISCHARGE PUMP CHAMBER EXHAUST TANK PORT FILLER CAP OIL LEVEL COIL ALARM PACK ON/OFF OIL FILLER OIL FILLER SWITCH DIPSTICK DIPSTICK OPEN OIL DRAIN PLUG FRAME...
  • Page 9 PRODUCT FEATURES PRODUCT FEATURES FILTER THROTTLE, CHOKE & FUEL VALVE INTAKE PORT STARTER PUMP DRAIN RUBBER RECOIL PLUG FEET...
  • Page 10: Inspection

    Fully inspect Water Pump before use. Ensure all correct parts are supplied with the product. It is important to fully secure all four of the rubber feet to the water pump frame to provide a level and If any parts are missing/damaged or for support contact ParkerBrand customer services directly on 01507 499198.
  • Page 11 ASSEMBLY ASSEMBLY LOCATE FILTER & COVER ASSEMBLE FILTER & COVER ATTACH STRAINER TO HOSE TIGHTEN CLAMP TO HOSE Locate both parts of the filter, the filter and the Attach the filter cover to the filter simply by Attach the suction hose to the filter. Secure the suction hose to the filter using the tube filter cover.
  • Page 12 ASSEMBLY ASSEMBLY ATTACH HOSE TO INTAKE PORT TIGHTEN CLAMP TO HOSE ATTACH HOSE TO INTAKE PORT TIGHTEN LINKER TO INTAKE PORT Attach the suction hose to the tube tie-in as Secure the suction hose on to the tube tie-in using The suction hose is now ready to attach to the Turn the tube linker in a clockwise direction until shown in the image above.
  • Page 13 Attach the lay flat hose to the tube tie-in as Secure the lay flat hose on to the tube tie-in using shown in the image above. the tube clamp. ParkerBrand lay flat hose (SKU:MISC-PPWP-2LFH & MISC-PPWP-3LFH) is available separately from www.parkerbrand.com...
  • Page 14 ASSEMBLY ASSEMBLY ATTACH HOSE TO DISCHARGE PORT TIGHTEN LINKER TO DISCHARGE PORT The illustration shows exactly what order to place the parts to sucessfully attach the lay flat hose to your water pump. The lay flat hose is now ready to attach to the Turn the tube linker in a clockwise direction until water pump discharge port.
  • Page 15: Pre-Operation

    PLO-4STR) is available separately from www.parkerbrand.com NOTE: This pump is not supplied with any oil within the engine, there is only trace left from testing. WARNING! To carry out this procedure, place the pump on level ground with the engine switched off.
  • Page 16 PRE-OPERATION PRE-OPERATION REMOVE FUEL CAP CHECK FUEL FILTER FILL FUEL TANK LOCATE PUMP CHAMBER REMOVE CHAMBER FILLER CAP FILL PUMP CHAMBER Before starting the engine it is important to Remove the pump chamber filler cap by Completely fill the pump chamber with water To add fuel, remove the fuel filler cap.
  • Page 17: Starting The Engine

    STARTING THE ENGINE STARTING THE ENGINE FUEL LEVER ON CHOKE LEVER ON/OFF SWITCH RECOIL STARTER CHOKE LEVER THROTTLE LEVER Pull the starter recoil gradually until you feel Let the engine idle for a short while to preheat When the pump is in operation, the speed can Push the fuel lever to the right position).
  • Page 18: Stopping The Engine

    STOPPING THE ENGINE SHUTTING DOWN THE PUMP SHUTTING DOWN THE PUMP STOPPING IN AN EMERGENCY THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK Move the throttle to its slowest position Move the fuel lever to the left (Off position). In an emergenciy turn the power switch in an (indicated by a tortoise).
  • Page 19: Maintenance

    MAINTENANCE MAINTENANCE DRAIN THE PUMP REMOVE PUMP DRAIN PLUG OIL CHANGE REMOVE DRAIN PLUG & DRAIN OIL After use and before storage it is good practice to With the pump drain plug fully removed the water Locate the oil drain plug at the base of the machine. Remove the plug to allow the engine oil to flow out drain the pump chamber.
  • Page 20 MAINTENANCE MAINTENANCE AIR FILTER SERVICE REMOVE AIR FILTER SECURING HANDLE REMOVE AIR FILTER SECURING WASHER REMOVE AIR FILTER FROM MACHINE The air filter is located on top of the machine next To access the air filter first loosen the securing nut With the securing nut removed now remove the The main body of the air filter can now be removed to the fuel tank.
  • Page 21 MAINTENANCE MAINTENANCE Clean all the air filter components with a SPARK PLUG SERVICE REMOVE SPARK PLUG CAP damp rag to remove any deposits. Wash the foam filter with warm soapy water, rinse and allow to dry thoroughly. HANDLE WASHER COVER The spark plug cap is located between the Grip the end of spark plug cap and pull firmly.
  • Page 22 MAINTENANCE MAINTENANCE REMOVE SPARK PLUG SET SPARK PLUG GAP IDLE SPEED ADJUSTMENT THROTTLE ADJUSTMENT SCREW ADJUST THROTTLE SCREW Gap 'A' Set Between 0.6mm - 0.7mm Use the spark plug wrench provided to remove the Check the spark plug gap (A), it should be between Start the engine outdoors and allow it to warm Let the engine idle for a short while to preheat Use a screwdriver to turn the throttle screw to...
  • Page 23 MAINTENANCE MAINTENANCE DRAIN THE FUEL TANK LOCATE FUEL DRAIN REMOVE FUEL DRAIN BOLT DRAIN FUEL Push the fuel lever all the way to the right (On position) The fuel drain bolt is located on the bottom of the Use a funnel and a suitable container to catch any Remove the fuel drain bolt by turning it in an carburettor on the gold bowl.
  • Page 24 MAINTENANCE MAINTENANCE The warranty does not cover fuel system damage or engine WARNING - Petrol is highly flammable and explosive. You can be STORING THE PUMP 5. Stop the engine, and allow it to cool. Proper storage preperation is essential for keeping your pump trouble 6.
  • Page 25 MAINTENANCE MAINTENANCE STORAGE PRECAUTIONS REMOVAL FROM STORAGE CARBURETTOR MODIFICATION FOR HIGH ALTITUDE OPERATION NOTE - When the carburettor has been modified for high altitude If your pump will be stored with petrol in the tank and carburettor it is Check the pump is as described in the PRE-OPERATION chapter of this At high altitude the standard carburettor air-fuel mixture will be too rich.
  • Page 26 MAINTENANCE MAINTENANCE ANNUALLY EACH 1 MONTH 3 MONTHS 6 MONTH EACH 1 MONTH 3 MONTHS 6 MONTH ANNUALLY PART PROCEDURE PART PROCEDURE OR 20 HRS OR 50 HRS OR 100 HRS OR 20 HRS OR 50 HRS OR 100 HRS OR 300 HRS 300 HRS Check Level...
  • Page 27: Troubleshooting

    Relocate pump and/or hoses to reduce head Clogged fuel filter, Carburettor Take engine to a qualified mechanic. Replace or repair faulty parts. malfunction, valves stuck etc 01507 499198. If this does not solve your problem, please contact the ParkerBrand customer service department...
  • Page 28 Please be aware products and parts may change design without notice. Please be aware products and parts may change design without notice. For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com...
  • Page 29 PUMP HOUSING M8 X 25 FLANGE BOLT INTAKE FLANGE Illustrations accurate at time of going to print. Please be aware products and parts may change design without notice. For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com...
  • Page 30 Please be aware products and parts may change design without notice. Please be aware products and parts may change design without notice. For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com...
  • Page 31 PUMP HOUSING M10 X 25 FLANGE BOLT INTAKE FLANGE Illustrations accurate at time of going to print. Please be aware products and parts may change design without notice. For a High Resolution copy of this exploded parts diagram please visit www.parkerbrand.com...
  • Page 32: Specification

    Min. Fuel Consumption (g / kW.h) Unpacked Weight (kg) Min. Fuel Consumption (g / kW.h) Unpacked Weight (kg) *All measurements are approximate. *All measurements are approximate. If you require further information please contact ParkerBrand directly If you require further information please contact ParkerBrand directly...
  • Page 33: Guarantee

    This includes items such as recoils, starting mechanisms, spools, carburettors, blades and the like. ☑ The Emission of Gaseous & Particulate Pollutants for Internal Combustion Engines Please go to www.parkerbrand.com in order to view the full warranty terms and exemptions from to be Installed in Non-road Mobile Machinery (2006/105/EC) Technical file complied by: the warranty.
  • Page 34 P P W P - 2 0 0 0 & 3 0 0 0 July 2021 Rev 1.0...
