Replacement Parts List - Panasonic TX-37LZD70 Service Manual

Replacement Parts List

In case of ordering these spare parts, please always add the complete Model-Type number to your order.
RTL (Retention Time Limited)
Note:
X
Cct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
1 EAS16S06A
2 ENGF7701GF
3 J3ABAAC00001
4 K0RB00500019
5 K1ZZ00001424
6 L5EDD9T00002
7 LSEP1234A1HB
8 N2QAYB000181
9 TBLA0318
10 TBX0E83400
11 TKK0E9529
12 TKK0E9530
13 TKP0E16001
14 TKP0E23801
15 TKP0E23901
16 TKP0E24101
17 TKU0E0199
18 TKZ0E9450
19 TKZ0E9451
20 TKZ0E9454
21 TKZ0E9455
22 TKZ0E9456
23 TKZ0E9457
24 TKZC5100
25 TKZC5101
26 TMW0E109
27 TNPA4118AA
28 TNPA4138AC
29 TNPA4206AB
30 TNPA4257AA
31 TNPA4381AA
32 TNPA4382AA
33 TNPA4428AA
34 TUA0E1400
MISCELLANEOUS COMPONENTS
. R6RC/2P
. TBM0E0771
. TBM0E0814
. TES0E201
. THEL047J
. TKP0E23701
. TKP0E24001
Components Identified by
* When replacing any of these components, use only manufacturers specified parts.
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
The marking (X) indicates that board should be exchanged for service.
Description
SPEAKER
TUNER
TUNER DVB
CONTROL PANEL ASSY
80P CONNECTOR COVER
LCD PANEL
POWER SUPPLY UNIT
REMOTE CONTROL
PEDESTAL ASSY
POWER BUTTON
SPEAKER HOLDER A
SPEAKER HOLDER B
CONNECTOR COVER
SD DOOR
HDMI COVER
SIDE AV BRACKET
BACK COVER
VESA METAL
LCD BOTTOM MTG
LCD BOTTOM MTG R
LCD BOTTOM MTG L
SUPPORT METAL L
SUPPORT METAL R
LCD TOP MTG R
LCD TOP MTG L
TUNER BRACKET
G P.C.B.
S P.C.B.
GS P.C.B.
AP P.C.B.
V P.C.B.
R P.C.B.
H P.C.B.
CHASSIS FRAME
BATTERY
AV3 LABEL
REAR AV LABEL/HDMI
BUTTON SPRING
SCREW
LED PANEL
IR PANEL
Important Safety Notice
mark have special characteristics important for safety.
Cct Ref
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
CK101
FC02
FC03
FC04
FDG03
FK301
FK302
FK303
FK308
FKN01
I.C.s
RTL
IC1100
RTL
IC1101
RTL
IC2000
RTL
IC2002
RTL
IC2006
RTL
IC2008
RTL
IC2010
IC2011
IC2012
IC2013
IC2015
IC2106
IC2107
IC2301
IC2303
IC2610
IC3001
IC3101
23
Parts Number Description
TKZ0E9458 LED HOLDER
TMK0E947 BARRIER
TMK0E948 BARRIER
TPC0E83801 CARTON TOP
TPC0E83901 CARTON BOTTOM
TPD0E0202 TOP CUSHION
TPD0E0203 BOTTOM CUSHION
TPD169487 CARTON HANDLE
TPE0E4019-1 SET BAG
TUC0E570 SIDE SHIELD
TUC0E571 TOP SHIELD
TUC0E572 BOTTOM SHIELD
XTB4+18JFJK SCREW
XTV3+10JFJK SCREW
XTV3+12JFJ SCREW
XTW3+12TFJ SCREW
XYN3+F8FJ SCREW
XYN4+F10FJ SCREW
XYN4+F20FJK SCREW
TMM8E18048 TAB-RELEASE CABLE
J0KG00000011 FERRITE CORE
J0KG00000011 FERRITE CORE
J0KG00000042 FERRITE CORE
TEWA154 GASKET (10X25XT6)
TEWA594 GASKET (18X18X45)
TEWA608 GASKET (3X10X50)
TEWA608 GASKET (3X10X50)
TEWA527 GASKET (8X10X40)
TEWA640 GASKET (5X10X20)
MNZSFD7GP42 MICRO_GENX4
C3EBFC000042 EEPROM BR24L08F-WE2
C0JBAZ002261 BUFFER
C0FBBY000027 AUDIO DAC
C0JBAZ002261 BUFFER
C0CBCBE00001 REGULATOR
C0CBCBC00190 REGULATOR
C0ABBB000230 OPERATIONAL AMPLIFIER
C1BB00000947 AUDIO AMPLIFIER
C0DBGYY00281 REGULATOR
C0DBGYY00281 REGULATOR
C1AB00002746 AUDIO PROCESSOR
C0DBFFD00003 1.8V REGULATOR
C1AB00002730 AUDIO AMPLIFIER
C0DBGYY00202 REGULATOR
C0DBAJB00004 REGULATOR
AN15876A-VT VIDEO SWITCH
AN15862A-VT AUDIO SWITCH
