believing in technology
INSTRUCTION
MANUAL
HL S
ERIES
20 – 25 – 30 – 50
PTM srl
Via per Isorella, 22/A
25010 VISANO -BS- ITALY
Tel. 0039 030/9952733
Fax. 0039 030/9952818
e-mail:
ptm@ptmsrl.com
web:
www.ptmsrl.com
Rev. 02A del 23/09/2020
Translation from the Original

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PTM HL Series

Summary of Contents for PTM HL Series

  • Page 1 INSTRUCTION MANUAL HL S ERIES 20 – 25 – 30 – 50 PTM srl Via per Isorella, 22/A 25010 VISANO -BS- ITALY Tel. 0039 030/9952733 Fax. 0039 030/9952818 e-mail: ptm@ptmsrl.com web: www.ptmsrl.com Rev. 02A del 23/09/2020 Translation from the Original...

  • Page 2: Table Of Contents

    MAIN MENU ................................11 SUBMENU .................................. 12 WORK MODALITY HL-SERIES 30 AND hl-series 50 ....................16 TOPCUT TIMES IN DETAIL (ONLY FOR HL SERIES 30-50) ................... 20 HL-SERIES 25 WORK MODALITY ..........................21 HL-SERIES 20 WORK MODALITY ..........................23 VOLUME VISUALIZATION (ONLY FOR HL-SERIES 20)..................24 USER CODES MENU ..............................

  • Page 3: Functions

     4-20mA Output (Optional)  Automatic activation of warranty after some hours of function HL Series 25  All the HL Series 20 functions (NO WEIGHT-VOLUME CONVERSION)  Managing of only one load  Managing of only one unload  Load and unload lock function ...

  • Page 4: Technical Features

    Drive 8 Multilink: I/O Board RF7 Multilink: RF Antenna for radio control Multilink Mod. P1000 Printer Inverter Power supply Plug power supply NOTA: All the HL-Series weight indicators, can be compatible with some previous generation accessories. HL Series – Instructions manual...

  • Page 5: What Is The Weighing Indicator Composed Of

    6. Serial number: serial number of the weighing indicator. In case of technical assistance, please communicate this number to PTM or to the authorized retailer in order to permit the product identification. Identification plate: weighing indicator identification plate. In case of technical assistance, please communicate this number to PTM or to the authorized retailer in order to permit the product identification.

  • Page 6: Keys Functions

    NOTE: Depending on the menu where you are, some keys (for example the function keys) may have extra functions or different functions from the ones in the chart. For more information please go ahead reading this manual. HL Series – Instructions manual...

  • Page 7: Text And Number Insertion

    To confirm the insertion of characters, press key  To leave without confirming the characters insertion, press key  MENU MENU MENU MENU If the weighing indicator is in Russian language, it is displayed the representation of characters in Russian. HL Series – Instructions manual...

  • Page 8: Principal Programmation Modality

    The ration for each unloading group.  THE WORKING MODALITY OF THE WEIGHING COMPUTER IS SET BY THE CONSTRUCTOR. NOTE: In this manual are given the explanation about the weighing computer settings, programming and use in ANIMAL/ANIMAL MODALITY. HL Series – Instructions manual...

  • Page 9: To Start

    TO START The operations below are the basic functioning operations for the HL-Series 30 e HL-Series 50. If you want more information about HL Series weighing indicator functioning and the work modalities, please continue reading this document. SWITCH ON /SWITCH OFF...
  • Page 10 Press on the total weight menu in order to visualize the current recipe name. NOTE: for more detailed information see the session WORK MODALITY FOR HL SERIES 30 AND HL SERIES 50 DATA PRINT (OPTIONAL) Press (F8) to print the total or partial weight data depending on the menu in which you are.

  • Page 11: Main Menu

    SUPPLY VOLTAGE  CONTRAST  BRIGHTNESS  BUZZER VOLUME  LANGUAGE [LANGUAGE]  menu menu menu menu Press to move into the different menus. Press to access to the underlined submenu. Press to exit without modifying. HL Series – Instructions manual...

  • Page 12: Submenu

    SUBMENU DENSITY (OPTIONAL) ONLY FOR HL Series 20 This menu is visible only if the conversion of the weight value in volume is activated. Activating this function in the work menu it will be visualized both the weight and the volume of the liquid contained in the vessel under which there are the load cells.
  • Page 13 COMPONENTS     ADVANCED PARAMETERS ONLY FOR HL Series 30-50 menu menu menu menu By pressing the key (F8) in correspondence of the selected component, it will be possible to set the following advanced parameters: PAUSE AUTOMATIHIC CHANGE: last load component pause, it means a ...
  • Page 14 Press to exit SUPPLY VOLTAGE menu menu menu menu This menu permits to visualize the supply voltage value applied to the HL series weighing indicator, CONTRAST menu menu menu menu This menu is used to set out the contrast of the graphic display. The 5 digits big display is automatically contrasted.
  • Page 15 This menu allows to set the language used by the weighing indicator. Press the keys to select the language. LANGUAGE     STANDARD COMPONENTS NAMES ONLY FOR HL Series 30-50 menu menu menu menu When the language used by the weighing indicator is changed it is possible to change the Components names Default Set of the new selected language.

  • Page 16: Work Modality Hl-Series 30 And Hl-Series 50

    WORK MODALITY HL-SERIES 30 AND HL-SERIES 50 The explications for the HL Series 30 and HL Series 50 work modality are described following the logic of the ANIMALS work modality. The weighing indicators can work also in TOTALS and PERCENTAGE modality.
  • Page 17 (F5) Start the loading process of the recipe by pressing (F6)  It is possible to visualize the recipe’s name, recipe’s total, the number of animals in the recipe and the ration for each animal. HL Series – Instructions manual...
  • Page 18 If a printer is connected to the weighing indicator, at the end of the load  operation there is the data printing. In no matter what moment of the loading process, the operator can activate  or deactivate the TopCut system with the key (OPTIONAL) HL Series – Instructions manual...
  • Page 19 If to the weighing indicator is connected a printer, at the end of the unloading  operation there will be the data printing HL Series – Instructions manual...

  • Page 20: Topcut Times In Detail (Only For Hl Series 30-50)

    TOPCUT TIMES IN DETAIL (ONLY FOR HL SERIES 30-50) Global time [min] Total duration of the TopCut cycle. Minimum value allowed  5min  Maximum value allowed  60min  Wait time[s] Waiting time before the introduction of the knifes into the wagon.

  • Page 21: Hl-Series 25 Work Modality

    HL-SERIES 25 WORK MODALITY PROGRAMMATION MENU Press (F5) from the total weight menu to go into the HL Series 25 programming menu. pROG pROG pROG pROG In this menu it possible to: Program the loading quantity by pressing the key (F1) ...
  • Page 22 (F8). The locked weight will flash intermittently through an acoustic sound. Interrupt the unloading process by pressing the key for 3 seconds. The  weighing indicator will automatically go back into the total weight menu. CONFIRM?? HL Series – Instructions manual...

  • Page 23: Hl-Series 20 Work Modality

    1000 1000 Pressing (F4) it is possible to lock the weight visualized on the weighing indicator. The locked weight will flash intermittently trough an acoustic sound. Press again the key (F4) to unlock the weight. HL Series – Instructions manual...

  • Page 24: Volume Visualization (Only For Hl-Series 20)

    In this case, the eventual positive weight variation (tank filling) will be visualized with the negative weight indication, vice versa the negative weight variations (tank emptying) will be visualized with the positive weight indication. NOTE: the partial weight inversion is valid also for the weight print values HL Series – Instructions manual...

  • Page 25: User Codes Menu

    Installer Password HOW TO USE THE CODES MENU The HL Series weighing indicators have the possibility to set some parameters which usually are not visible in the menus and submenus. Please note that the weighing indicator can memorize codes menu date and time...
  • Page 26 Weigh the material taken away from the tank on an external scale, and note down the weight value (e.g. 680 Kg). Carry out CODE 9, by using the value 550 Kg as MEASURED WEIGHT, and the value 680 Kg as REAL WEIGHT. HL Series – Instructions manual...
  • Page 27 CODE 15: COMPONENTS NAMES ON THE DIGITS (ONLY FOR HL Series 30-50) In this code it is possible to set out the parameters for display and scroll of the component’s names on the digits of the display at the beginning of the loading operation.
  • Page 28 It is possible to set out the speed from 1 (very slow) to 20 (very quick). CODE 50: ALARM PERCENTAGE (ONLY FOR HL Series 25-30-50) In this code it is possible to set out the parameters of the acoustic alarm. There are...
  • Page 29 It is possible to activate the printing from 1 to 3 prints. Break Prints It is possible to set a break in seconds between a copy and the following in order to allow a correct paper cut at the end of each print. HL Series – Instructions manual...
  • Page 30 CODES ACCESS: It show the last accessed code with corresponding date  and time. CODE 99: SOFTWARE RELEASE cod:99 cod:99 cod:99 cod:99 In this code it is possible to visualize the software version installed on the weighing indicator, and the weighing indicator model. HL Series – Instructions manual...

  • Page 31: Printing Examples

    ************************ xxxxxxxx ************************ NOTE: The unit of measurement printed on the total/partial weight receipt can vary depending on the calibration used. If the Weight-Volume conversion is enabled, the principal unit of measurement will be printed. HL Series – Instructions manual...

  • Page 32: Optionals

    TRASMITTER FOR AV50, AV60, AV80: RF Transmitter for each remote display.  TR60 PER AV50, AV60, AV80: RF Transmitter for each remote display.  POWER SUPPLY:  INVERTER POWER SUPPLY  PLUG POWER SPULLY FOR NEW ORDERS USE MULTILINK ACCESSORIES ONLY HL Series – Instructions manual...
  • Page 33 -12 V common - GND, negative power supply CONNECTOR “C” – 5 -PIN FEMALE CONNECTOR FOR THE CONNECTION OF LOAD CELLS ONTACT UNCTION Negative signal Positive power supply Positive signal Negative power supply Not used HL Series – Instructions manual...

  • Page 34: Trouble Shooting

    Arrange for the tank not to touch the frame in POINT 6: Check that the tank, or the frame. any point. device receiving the weight, does not touch the frame in any point. The tank does not lay Contact service. on the frame. HL Series – Instructions manual...
  • Page 35 POINT 8: Check if the power supply The scale switches on. cable is interrupted or damaged, and if the power plug and the battery clamps are oxidized. If necessary, replace them. The scale does not Contact service. switch on. HL Series – Instructions manual...
