“Mounting…”
Split Crossover
Cover
Crossover
All manuals and user guides at all-guides.com
Speed
Clips
Spring
Clip
Mounting
Turn Clockwise
to tighten setscrew.
Speaker cable strip guage. Strip end
of wire to match illustration.
8mm
*Up to 12AWG (2x2.5mm²)
speaker wire.
Grille Ring
Gasket
Cup
Tweeter
Turn Counterclockwise
to loosen setscrew.
Midbass/
Woofer
Screws
Grille
