Summary of Contents for VOX electronics EM2101
- Page 1 ICE MAKER INSTRUCTION MANUAL EM2101 Read this manual carefully before use and save it for future reference...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire, explosion, electric shock, or injuries when using your ice maker, follow these important safety instructions: 1. Before use check if the voltage power corresponds to the one shown on the appliance nameplate. - Page 3 from frostbite. 15. Do not immerse any part of the appliance in water. 16. To disconnect, turn any control to “OFF”, then remove the plug from the wall outlet. 17. Do not plug or unplug the appliance with wet hands. 18.
- Page 4 structure clear of obstruction. 39. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. 40. WARNING: Do not damage the refrigerant circuit. 41. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
-
Page 5: Control Panel
KNOW YOUR ICE MAKER Handle Evaporator Top lid Ice tray Viewing window Ice shovel Front cover W ater reservoir Back housing Front housing Control panel Infrared light-em itting diode Infrared light-receiving diode Filter Ice basket Drain plug Ice spoon "M AX" water level (Product may be subject to change without prior notice) CONTROL PANEL... -
Page 6: Before First Use
Key (with indicator) Function ON/OFF Start or stop the appliance； Long press for cleaning； Standby mode: “ICE” indicator blinks; Cleaning condition：“ICE” indicator blinks quicker； Working condition: “ICE” indicator lights solidly. ICE FULL “ICE FULL” indicator lights up when the ice basket is full. ADD WATER “ADD WATER”... -
Page 7: Using Your Ice Maker
Fig.1 Fig.2 Fig.3 3. Make sure the ice maker is level and on a stable table or platform as to avoid malfunction. 4. The incline angle of the ice maker cabinet should not exceed 45°during transportation or use. Do not turn the ice maker upside down. Doing so could cause the compressor or refrigerating system to operate incorrectly. - Page 8 4. Fill the water reservoir with drinking water. NOTE: Do not fill above the MAX water level mark. 5. Replace the ice basket and close the top lid. 6. Press “ON/OFF” key and the “ICE” indicator lights solidly. 7. The ice-making cycle will last approximately 7-15 minutes, depending on the ambient temperature and water temperature.
-
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE To keep your ice tasting fresh and your ice maker looking great, we recommend cleaning your ice maker once a week. 1. Stop the ice-making cycle by pressing the “ON/OFF” key, unplug the ice maker from the wall outlet and allow it to warm up to room temperature. -
Page 10: Troubleshooting
（Fig.4） （Fig.5） （Fig.6） TROUBLESHOOTING Problem Possible causes Solution “ADD WATER” 1. Low water level or lack of 1. Stop making ice, refill water and indicator turns on water. then press “ON/OFF” key to restart 2. The water screen at the ice-making cycle. - Page 11 “ICE FULL” 1. Ice basket is full and the 1. Remove the ice from ice basket. indicator lights up infrared light is blocked by 2a. Wipe unknown objects on the the ice. infrared light-emitting diode & 2. Infrared light-emitting light-receiving diode and restart the diode &...
-
Page 12: Technical Parameters
There is air in the water pipe, so there will be resonance noise produced when pumping water. TECHNICAL PARAMETERS Model: EM2101 Applicable climate: ST/SN/N/T Class: I Power source: 220-240V/50-60Hz Rated power: 120W Refrigerant/Refrigerant amount: R600a/23g Foaming agent: C Net weight: 8.3Kg...
