Instruction for use
Saf-e-fire
Blue Flame Heater
Keep this instruction booklet:
if lost obtain a new copy through
your supplier or direct from us
This New Heater is :
- odourless
- 100% safe
The flame is :
- visible all-round
- perfectly adjustable
by a wonderful new
system
The wick :
- lasts for two burning seasons
- is easy to replace
Advertisement
Summary of Contents for BK Precision Saf-e-fire Blue Flame
- Page 1 This New Heater is : - odourless Instruction for use - 100% safe The flame is : Saf-e-fire - visible all-round - perfectly adjustable by a wonderful new system Blue Flame Heater The wick : - lasts for two burning seasons - is easy to replace Keep this instruction booklet: if lost obtain a new copy through...
- Page 2 In order to obtain best results from your BK Saf-e-fire Blue Flame Heater, the following instructions should be read with attention and the essential points should be clearly understood.
- Page 3 1/8" (1/2 cm) Do not raise the Wick higher. Lighting : If the wick is raised too high, a large yellow flame will Raise the wick by turning result, which must be carrying handle or regulating immediately reduced until it collar clockwise until the is blue.
- Page 4 carrying handle Regulating collar Regulating : When the wick is fully alight, The shield shown here and fixed just underneath the the flame can be adjusted by turning carrying handle or regulating collar, will always regulating collar clockwise or indicate the right direction. counter-clockwise.
- Page 5 Caution : The BK Saf-e-fire is a Blue Flame Heater. The flame should always be blue. When the heater is burning in low, medium or high position, the flame must be blue and transparent as shown here (A). If set Too High, yellow streaks will A.
- Page 6 Wick cleaning : When in continuous use, the wick should be scraped approx, once a fortnight with the wick cleaner provided. The carbon or chars formed on the wick after continuous operation can be removed by scraping the wick top. Remove flame spreader before placing the scraper on top of the wick.
- Page 7 Inserting new wick : The effective burning length of the wick is approx. 2 3/4"(7cm) which ensures, if treated correctly, a working life of two years under normal conditions. When a replacement ultimately becomes necessary, it is recommended to allow the container to burn dry.
- Page 8 5) Push wick carrier over new wick as shown here: Make sure that the stud on the wick carrier is placed between the slits of the new wick and protrudes freely. 6) Replace flame spreader on central tube and place new wick and wick carrier over the central tube in such a way, that the stud of wick carrier will be above the groove in the central tube.
- Page 9 CAUTION : Only the genuine BK wicks should be used. If there should be any difficulty to obtain these wicks, please communicate with us. Wick raising : The wick can be raised several times before replacement will become necessary. When the wick can no longer be turned approx 1/5" (1/2cm) above gallery flange, the wick can be raised quite easily.
- Page 10 Replacing glass cylinder : In case the glass cylinder is damaged or broken by very rough handling, replacement is necessary. Obtain a new cylinder through the original supplier of the stove. Open heater and take off the burner basket fitted in the lower part of the chimney. This is a push fit only and the basket is not screwed on or specially fastened.
- Page 11 Each paraffin burning appliance burns considerable quantities of air to each gallon of paraffin. g) The BK Saf-e-fire Blue Flame Heater can be used effectively for cooking. The full heat is directed straight to the bottom of any vessel placed on top.
-
Page 12: List Of Spare Parts
No.814 Screws M 4 x 8 No.815 Scraper No.816 Spring for central tube The BK Saf-e-fire BLUE FLAME HEATER is a product of the ROYAL KAMPEN ENAMEL WORKS (HOLLAND). Sole sale in England by Royal Kampen Enamelworks, 19, Moorgate, London - E.C.2. Telephone: Morarch 1814 - 3621...
