Ganz MCWB-312NA Instruction Manual

600TV LINE WDR MINI CASE CAMERA
MCWB-312NA

INSTRUCTION MANUAL

Color Day/Night Ultra High Resolution
Camera with Wide Dynamic Range

PARTS DESCRIPTION

After un-packing, check if the following items are contained inside :
• Instruction manual (1)
• Video/Power Cable (1)
INSTALLATION AND ADJUSTMENT
Note: The camera can be mounted on both ceiling and wall.
1. Remove the bracket and mount the camera to the desired location by
using the provided screw.
2. Set the camera by rotating it around the screw and angling it using the
bracket.
3. Fasten all screws to hold the camera in place.
NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions.
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
Disposal of your old appliance
1. If the symbol below is attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electric products should be disposed of separately from
the municipal waste stream via designated collection facilities appointed
by the government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
4. For more detailed information about disposal of your old products, please
contact your city office, waste disposal service or the shop where you
purchased the product.
v1.0 English
• Mounting Screw (1)

PRODUCT FEATURES

Ultra High Resolution :
Advanced DSP technology combined with Sony's Super HAD II 410K pixel CCD
enables the camera to achieve a clean picture of 600TV Lines.
WDR (Wide Dynamic Range) :
Provides true WDR performance by using dual channel operations.
Sens-up :
Digitally manipulates the exposure level of the image to produce bright images
in the darkest of scenarios.
Day / Night :
Automatically detects the optimum point when to switch between color and
black & white.
3D-DNR (3D Digital Noise Reduction) :
Advanced 3D-DNR algorithms allow for a clean picture even under extreme low
light environments.
Integrated DC 3.3~12mm Lens
Designed for indoor use.

SAFETY PRECAUTIONS

1. The installation should be made by qualified service engineers and should
conform to all local codes.
2. To prevent fire or electric shock, do not expose the camera to rain or
moisture.
3. To prevent fire or electric shock, UL listed wiring should be used for the
DC 12V input.
4. Use only DC 12V regulated power supply marked class 2.
5. Never attempt to disassemble or modify the camera.
6. Be sure to connect each lead to the appropriate terminal. An incorrect
connection may cause damage to the camera.
7. Do not attempt to aim the camera at the sun or other extremely bright
objects.
8. Do not allow the camera to be subject to unstable location, strong shocks
and vibration, and strong electromagnetic field.
9. If any abnormality occurs, immediately turn off the power and consult
your dealer.

OSD MENU TREE

CAM NAME
• ON • OFF
LENS
• DC IRIS • MANUAL • EZ FOCUS
EXPOSURE
• AGC • SHUTTER • SENS-UP • LOW LIGHT GAIN • INITIAL SET • PREVIOUS
DAY / NIGHT
• AUTO • COLOR • B/W • CDS
WDR / BLC / HLC
• WDR • BLC • HLC
WHITE BAL
• ATW1 • ATW2 • AWC-SET
3D-DNR
• ON • OFF
EFFECTS
• DZOOM MODE • IMAGE FREEZE
• COLOR ADJUST • INITIAL SET
SPECIAL
• MOTION DET. • PRIVACY
• MONITOR TYPE • WSC MODE
EXIT
The detailed functions and parameter settings for your camera can be set in
the OSD (On Screen Display) menu. To access this menu your camera must
have an OSD controller or a RS-485 connection.
OSD Controls
[Enter/Set] : Enters the OSD Menu, Selects the desire option.
[Directional Buttons] : Navigates through the OSD Menu.
[Long Left] : Accesses the EZ Focus Mode.
• MANUAL
• D-EFFECT • CONTRAST • SHARPNESS
• PREVIOUS
• LANGUAGE • STABILIZER • L/L SYNC
• FACTORY RESET • COMM SET • PREVIOUS
