Ronin X Series Instructions For Use Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Ronin X Series Surgical Headlights &

Ronin X Series Chargers

Instructions for Use

(IFU)

Caution: Thoroughly read all instructions prior to operating the devices.

Ronin is a Registered Trademark of RONIN SURGICAL CORP.

RONIN SURGICAL CORP

+1 (415) 226-9414

www.RoninSurgical.com

RK0350 - Rev A - Ronin X Series Instructions for Use (IFU)

Table of Contents

Need help?

Do you have a question about the X Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ronin X Series

Page 1 Instructions for Use (IFU) Caution: Thoroughly read all instructions prior to operating the devices. Ronin is a Registered Trademark of RONIN SURGICAL CORP. RONIN SURGICAL CORP +1 (415) 226-9414 www.RoninSurgical.com RK0350 - Rev A - Ronin X Series Instructions for Use (IFU)
Page 2: Table Of Contents
BATTERY STORAGE, TRANSIT, AIR TRAVEL AND SHIPPING (page 16) TROUBLESHOOTING AND FAQ (page 17) CLEANING (page 18) MAINTENANCE (page 19) DECLARATION OF CONFORMITY (page 19) WARRANTY (page 20) RK0350 - Rev A - Ronin X Series Instructions for Use (IFU)
Page 3: Description
The headlight consists of a head mounted luminaire, a hip mounted battery holster, and Ronin approved battery packs. Available battery packs vary in energy capacity and physical dimensions. The luminaire is connected to the battery holster via a cable, and the battery holster can be loaded with a desired battery variant.
Page 4: Installation (For Charger Only)
Installation should ONLY be done by persons with proper authorization, professional licensing, and liability protection. The X Series Supercharger, or an array of X Series Superchargers, must not be installed in direct sunlight or on insulative or heat sensitive surfaces as excess heat may accumulate and cause a risk of burn or fire.
Page 5: Normal Use
WARNING: DO NOT use the Ronin X Series Headlight at a distance of less than 12 inches (30 cm) measured from the end of the luminaire to any illuminated surface. It is the responsibility of the user to ensure proper use of the headlight and monitor whether use of the emitted light is causing any desiccation, singe, burn, fire or other harmful effects at the surface.
Page 6: Unpacking The Unit
Warnings ● The user should carefully study the Instructions for Use (IFU) before using the X Series Surgical Headlight. Instructions should be followed, with special attention given to warnings, precautions, controls, and user specifications. The IFU should be made available to appropriate personnel.
Page 7 ● WARNING: DO NOT use the Ronin X Series Headlight at a distance of less than 12 inches (30 cm) measured from the end of the luminaire to any illuminated surface. It is the...
Page 8 ● To reduce the risk of fire and electric shock, DO NOT expose electrical equipment to moisture. When cleaning, do not immerse any electrical device in liquid. ● DO NOT store or use liquids of any type on or above the X Series Surgical Headlight System.
Page 9 ● DO NOT allow the emitted high intensity light to shine directly into eyes as it may cause permanent damage. ● DO NOT use the X Series Surgical Headlight System in ocular surgery or in a surgical procedure requiring direct illumination of the eye.
Page 10 Precautions ● CAUTION: Use only cleaning agents and chemicals identified by Ronin as suitable for use on the Ronin X Series Headlight system and related accessories. Use of alternative cleaning agents may cause harm to the product. See IFU section CLEANING for appropriate cleaning agents.
Page 11: Important Safety Information
● Both the power supply connector and battery are the main power disconnect devices for the Ronin X Series surgical headlight. If the LED does not turn off when the ON/OFF rocker switch is OFF or a malfunction is suspected, both unplug the power supply from the wall and remove the battery from the battery holster.
Page 12: Explanation Of Symbols
Power ON Power OFF Caution Hot Surface Caution: Refer to Instructions Stepped Variable LED Illumination Intensity "Aux 1" - Auxiliary Electrical Power Output "Remote" - Hand Operated Switch RK0350 - Rev A - Ronin X Series Instructions for Use (IFU)
Page 13: Operating Instructions (Normal Mode Operation)
WARNING: DO NOT use the Ronin X Series Headlight at a distance of less than 12 inches (30 cm) measured from the end of the luminaire to any illuminated surface. It is the responsibility of the user to ensure proper use of the headlight and monitor whether use of the emitted light is causing any desiccation, singe, burn, fire or other harmful effects at the surface.
Page 14 DO NOT FORCE THE CONNECTOR. To disconnect the cable, grasp only the connector collar (not the cable) and pull upward. Battery Selection: For use with only battery models authorized and supplied by Ronin. For a list of authorized batteries contact Ronin customer support at +1 (415) 226-9414 or email Ronin at Support@RoninSurgical.com...
Page 15: Indicator Leds, Battery Charging, And Battery Fuel Gauge
International Use: Care should be taken to ensure that you have the appropriate cord and plug configuration for the country in which the Ronin X Series Surgical Headlight is to be operated. The AC input of the Power supply is rated 100-240V, 50-60Hz.
Page 16: Battery Replacement
Battery Replacement: Contact Ronin for battery replacement. Call Ronin at +1 (415) 226-9414 or email: Support@RoninSurgical.com 13. BATTERY DISPOSAL For Battery disposal send back to Ronin or dispose of in accordance with local battery disposal regulations. 14. BATTERY STORAGE, TRANSIT, AIR TRAVEL AND SHIPPING Storage: Always remove battery from the holster unit while not in use.
Page 17: Troubleshooting And Faq
If you are having problems with the operation of the Ronin X Series Surgical Headlight, review this section to see if a solution is described. If you are still having trouble, call Ronin at +1 (415) 226-9414 or email: Support@RoninSurgical.com.
Page 18: Cleaning
Please return to Ronin for service if such a condition is experienced. The battery depletes abnormally fast. This is most often the result of a battery that is past its useful life. Please contact Ronin at +1(415)226-9414 or email: Support@RoninSurgical.com for replacement.
Page 19: Maintenance
The Ronin X Series Surgical Headlight requires no routine servicing. However, before every procedure, the X Series Surgical Headlight MUST be carefully inspected to ensure it has been properly maintained, cleaned, and is fully functional. DO NOT use if inspection reveals any debris, damaged components, or loose pieces.
Page 20: Warranty
Prior to shipping your Ronin X Series Surgical Headlight for repair under this Warranty you MUST call Ronin at +1 (415) 226-9414 and select “Customer Service” or email: Support@RoninSurgical.com...
