MODEL: HEH00624
THE VORTEX ALUMINUM CLIMBER
• Always Wear a Safety Harness with this Product
• Practice Using at Ground Level
• Weight Limit: 300 lbs.
• Tree Size: 9"-18" diameter
Warning
Every year serious injury and even death occurs from hunting related falls. To ensure your safety, please COMPLETELY
read and follow this safety manual and ALL warning labels BEFORE assembling, installing or utilizing this product.
DO NOT USE THIS PRODUCT BEFORE FULLY UNDERSTANDING ALL SAFETY WARNINGS AND INSTRUCTIONS. IF YOU
HAVE QUESTIONS, ARE UNSURE ABOUT ANY INFORMATION OR NEED ADDITIONAL INFORMATION CONCERNING
YOUR PRODUCT, CONTACT OUR CUSTOMER SERVICE DEPARTMENT AT 1-866-972-6168 OR VISIT
WWW.PRIMALVANTAGE.COM. KEEP AND MAINTAIN THIS SAFETY AND INSTRUCTION MANUAL IN A SAFE LOCATION
FOR FUTURE REFERENCE.
The Field & Stream trademark is owned by American Sports Licensing Inc., and is not associated with Field & Stream Licenses
Company, LLC or Field & Stream Magazine.
Distributed by Primal Vantage Company Inc. 685 Route 10 East, Randolph, NJ 07869
Instruction and Safety Manual
SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT
©2013 (rev. 02/13)
Advertisement
Summary of Contents for Field & Stream HEH00624
- Page 1 MODEL: HEH00624 THE VORTEX ALUMINUM CLIMBER • Always Wear a Safety Harness with this Product • Practice Using at Ground Level • Weight Limit: 300 lbs. • Tree Size: 9”-18” diameter Instruction and Safety Manual Warning Every year serious injury and even death occurs from hunting related falls. To ensure your safety, please COMPLETELY read and follow this safety manual and ALL warning labels BEFORE assembling, installing or utilizing this product.
- Page 2 TREESTAND SAFETY WARNINGS Please read the following instruction manual and warnings labels completely before utilizing this product. Failure to understand and execute the instructions and warnings may result in serious injury or death. In the event of an accident, have a plan for rescue, including the use of devices that may be easily reached while suspended.
- Page 3 TREESTAND SAFETY WARNINGS NEVER adjust your stand while in use. ALWAYS ensure that you and your treestand are safely secured to a healthy tree. Your tree stand MUST be attached tightly to the tree and secured in place. If the stand is not secure, it may shift while in use, resulting in serious injury or death. DO NOT leave your treestand outside since weather and animals may cause damage.
-
Page 4: Proper Care And Maintenance
CHOOSING A SAFE TREE • ALWAYS thoroughly inspect the tree before installing your product. DO NOT install your TREE/LADDER STAND onto any dead or unsafe tree, telephone or utility pole, structural column, or man-made structure. Doing so may result in serious injury or death. •... - Page 5 MODEL: HEH00624 THE VORTEX ALUMINUM CLIMBER • Always Wear a Safety Harness with this Product • Practice Using at Ground Level • Weight Limit: 300 lbs. • Tree Size: 9”-18” diameter Cable (2) Seat Platform (1) Foot Platform (1) Seat Cushion (1)
- Page 6 MODEL: HEH00624 ASSEMBLY INSTRUCTIONS PAGE 1 THE VORTEX ALUMINUM CLIMBER Frame Support Frame Support 1. Insert 1-M12x75mm bolt through the bottom of Foot Platform. 2. Lift railing and insert frame support through attached bolt 3. Thread T-knob on bolt. 4. Insert 1-M10 Quickclip through frame support and welded tab to secure frame in place.
- Page 7 MODEL: HEH00624 ASSEMBLY INSTRUCTIONS PAGE 2 THE VORTEX ALUMINUM CLIMBER CLOSEUP 8. Wrap the cable around the back of the tree and insert the other end of Cable into the opposite railing of the Foot Platform The notched end of the Railing will secure the cable.
- Page 8 MODEL: HEH00624 ASSEMBLY INSTRUCTIONS PAGE 3 THE VORTEX ALUMINUM CLIMBER 11. With Foot Platform 1-2 feet off the ground, STEP CAUTIOUSLY on the platform. (Attach your harness to the tree as per manufacturer’s instructions). Facing the tree, slide feet into the foot straps and tighten securely. Secure bungee cord around your heels to assist in keeping feet in foot straps.
- Page 9 SEAT CUSHION INSTRUCTIONS 2. Insert the loose end of the strap through the opposite armrest and 1. Place Seat Cushion between the around the handle rail. 3. Pull strap underneath seat cushion armrests with the straps facing the ground. Insert the buckle end of the strap through and thread through the buckle.
- Page 10 BACKPACK STRAP INSTRUCTIONS FIG. 1 FIG. 3 FIG. 2 FIG. 6 FIG. 4 FIG. 5 FIG. 7 1. Turn Foot Platform over, insert the looped ends of the backpack straps up through the rear frame of the platform . (See Fig. 1) 2.
- Page 11 BACKPACKING INSTRUCTIONS PAGE 1 1. Remove Seat Cushion from Seat Platform. Fold Seat Platform so rail is towards the cable. Screw the T-Knob back on the bolt. Pull the Buckles out so they are not in the way. 2. Fold Foot Platform so that the rail is facing away from the cable towards the front of the platform. Screw the T-Knob back on the bolt.
- Page 12 BACKPACKING INSTRUCTIONS PAGE 2 6. Place the Seat Cushion upside down on top of the Foot 5. Flip over the platforms so the bottom of the foot platform is on top. Pull the backpack straps out to the sides. Platform. Put the straps of the Seat Cushion underneath the backpack straps.
- Page 13 CLIMBING INSTRUCTIONS Before beginning to climb: Check that your harness is secure, check that cables are properly secured, and make sure that the seat straps on your seat section are off to the side, they should not obstruct the cable connecting to the tree in anyway while climbing. Practice at ground level with your Full Body Harness.
- Page 14 DETAILED BUCKLE AND STRAP INSTRUCTIONS Press down on latch and insert Hold buckle as shown strap underneath teeth as shown. Pull strap to desired length. Pull slack to tighten. ALWAYS tug on strap to make sure it is secured by the buckle before use ©2013 (rev.
