Summary of Contents for Texi SIRIUS
- Page 1 Operation Manual Laser Machine SIRIUS...
-
Page 2: Security Considerations
Security Considerations Before operating the equipment, it is strongly recommended that the users should read this specification and follow the operation manual strictly and NOBODY is allowed to start up the machine EXCEPT THE PROFESSIONALS. This equipment adopts four kind of laser device (Strong laser radiation), the radiation may cause the following accident: 1) Fire the tinder surroundings. - Page 3 Catalog A Appearance of the machine and accessories B Process for installing machine C Laser tube installation and optical path adjusting D Software installation (Attached) E Equipment operating instructions (Attached) F Daily maintenance of machine and analysis of common problems to solve G Warranty terms H Attachment...
- Page 4 Appearance of the machine and accessories: The whole appearance Pic 1-1 The whole appearance...
- Page 5 Power cord Pic 1-3 Connection of the whole machine and the accessories Pic 1-4...
- Page 6 pump Pic 1-5 Machine foundation Pic 1-6...
- Page 7 The blower pipe clamp Pic 1-7 The laser signal line The connector of water in or out Water chiller Pic 1-8...
- Page 8 The exhauster pipe Pic 1-9 Blower Pic 1-10...
- Page 9 Chiller accessories 1-11 English operation panel Pic 1-13...
-
Page 10: Laser Tube Installation
Laser tube installation： Please notice when customers is in the installation of the laser tube A In the positive and negative pole connected to the situation of optical laser tube, the anode is the light side, the electrode is the laser tube with spiral side as shown in Figure 1-14 (laser tube high pressure cap), such as wrong would lead to the laser tube damage The water inlet Outlet of... - Page 11 Negative electrode line The first reflector frame Pic 1-15 D Water work, in order to prevent the laser tube having the bubble phenomenon, take the way that make the water from low to higher as shown in Figure 1-2 (cathode in anode out, low into higher refers to the inlet and outlet of the laser tube).
- Page 12 Laser tube installation and adjusting optical path: Engraving machine in the process of using ,a variety of reasons may occur light path offset, resulting in no light or optical phenomenon is not correct, please refer to the following methods optical path adjustment: Laser tube Pic 1-16 The first step:...
- Page 13 marking the mark (Attention: please use the non metal sheet metal shielding to prevent the laser radiation hurt , test spot about the location , and then adjusted). Gradually move the beam to the farthest from the first reflector position, then press the pulse, make a mark. If the two markers do not coincide, adjust the copper screws on the first reflector , so that the two laser spot center mark coincidence (repeated debugging until the two marks overlap completely).
- Page 14 Auxiliary air tube Laser head Pic 1-19 Laser tube Pic 1-20...
- Page 15 The fourth step: if the laser does not fall within the light hole center, such as deviation: to raise or lower the light pipe. And deviation: only second reflector inwards or outwards adjustment. (such as adjusting the laser tube or a reflector position need to redo the second step and the third step, the spot completely Coincidence) Diagram of center adjustment Pic 1-21...
- Page 16 Production equipment maintenance Equipment’s routine maintenance is reduce the wear to make the equipment always in a basic work with good technology condition. The basic requirements of routine maintenance are: Operator use the equipment should strictly follow the rules,always observe the working condition of the equipment,the device should be kept intact,accessories should kept tidy,complete the safety equipment,wiring,and plumbing should intact;...
- Page 17 repeated several times until the mirror clean. Note: ① gently wipe the lens and should not damage the surface coating; ② wiping process should gently to prevent falls; ③ Please be sure that the convex upward at install the lens Fifth, clean rail (recommended cleaned once every two weeks,operations when shut down ) Rail, linear shaft as one of the core components of the device, due to the different pieces of processed material and some special materials will generate a lot of dust and corrosive fumes during processing, has a great...
- Page 18 (5)When the machine stops working,you should clean the machine comprehensively. The equipment work areas hold be clean and tiny no oil or waste on the ground; equipment accessories should be complete, properly, clean. In order to ensure the normal operation of the equipment to extend the service life of the equipment operator, routine maintenance, each shift before the end of the work, the holiday and festival before the holiday time should maintain the machine in accordance with the regular maintenance to the continuous operation equipment cannot Shutdown maintenance.
- Page 19 Common problems of laser cutting engraving system Analysis method Treatment method phenomenon Boot but 1.Check whether the 1.check the electrical wires machine is not machine electricity is ok again 2.check main 2.set up the parameters refer start parameters is correct by software instructions 1.Adjust the light path 1.Check wether the optical...
-
Page 20: Warranty Clause
Warranty clause Thank you for purchasing our laser machine.We have to announce to you that if you operate don’t according to specified items in “operating manual” ,we don’t warranty the damage of the machine. One. The content and deadline of the warranty 1 Warranty contents If the laser engraving machine you have buy generate quantity problem due to the material or manufacturing below the mark, our company will warranty refer to terms of the warranty period... -
Page 21: Parts Warranty
Parts Warranty Warranty Warranty period period Parts name Parts name （ month ） （ month ） Laser power Water-cooling supply Switching power Air pump supply Control Strap Driving Water pump Motor Mirror Focus lens Circuit Sliding block... - Page 22 Slider way Limit switch Other electric General Laser tube appliance’s parts (Note: non-damaged quantity reasons, we don’t warranty ）...
- Page 23 Cutting parameter values Description: cutting speed and material details may vary, this form is only for reference. The order of the data in the table: optimum range of cutting speed,optimum power range below optimum cutting speed,the maximum cutting speed rage without considering the effect of cutting. Unit: mm/s Cutting power Speed...
- Page 24 Strima Sp. z o.o. Swadzim, st. Poznańska 54 62-080 Tarnowo Podgórne, Polska We declare, that the following product: Laser machine TEXI SIRIUS (SF1390-I) which this declaration relates, complies with the following directives: Low voltage directive 2014/35/EU Harmonized norm used: EN 60825-1:2014...
- Page 25 Dealer:...
