I.
INTRODUCTION
T
he RICON PF4000 Series Low-Floor Vehicle Access Ramp is an electrically operated ramp
that allows easy access to vehicles for people using mobility equipment; wheelchairs, scoot-
ers, etc. The ramp has been designed for custom installations and is operated by the vehicle
driver using a dashboard mounted control switch.
This manual contains operation and maintenance instructions for the ramp. It is important to
user safety that the vehicle operators be completely familiar with the operating instructions. For
installation instructions, please refer to the service manual. Once the ramp is installed, it is very
important that it be properly maintained by following the Ricon recommended cleaning, lubrica-
tion, and inspection instructions.
If there are questions about this manual, or additional copies are needed, please contact Ricon
Product Support at one of the following locations:
Ricon Corporation
7900 Nelson Road
Panorama City, CA 91402 ........................................................................ (818) 267-3000
Outside (818) Area Code .......................................................................... (800) 322-2884
World Wide Website
...................................................................WWW.RICONCORP.COM
Ricon U.K. Ltd.
Littlemoss Business Park, Littlemoss Road
Droylsden, Manchester
United Kingdom, M43 7EF................................................................(+44) 161 301 6000
A. RICON ONE-YEAR LIMITED WARRANTY
When the vehicle is safely parked
with the doors open and driver
holds the control switch in the
DEPLOY position, the ramp ex-
tends from the vehicle and stops
when it contacts the ground. As a
safety function, if the ramp en-
counters an obstruction, move-
ment will automatically stop. After
the ramp is used, the driver holds
the switch in the STOW position
and the ramp retracts into the ve-
hicle. The rated load capacity is
800 pounds (364 kilograms).
(refer to following page)
32DPF401.A
1-1
Advertisement
Table of Contents
Summary of Contents for Ricoh PF4000 Series
- Page 1 INTRODUCTION he RICON PF4000 Series Low-Floor Vehicle Access Ramp is an electrically operated ramp that allows easy access to vehicles for people using mobility equipment; wheelchairs, scoot- ers, etc. The ramp has been designed for custom installations and is operated by the vehicle driver using a dashboard mounted control switch.
-
Page 2: One-Year Limited Warranty
RICON CORPORATION ONE-YEAR LIMITED WARRANTY Ricon Corporation (Ricon) warrants to original purchaser of this product that Ricon will repair or replace, at its option, any part that fails by reason of defective material or workmanship as follows: • Repair or replace parts for a period of one year from date of purchase. A complete list of parts covered by this warranty can be obtained from Ricon Product Support. -
Page 3: Shipment Information
B. SHIPMENT INFORMATION ¡ When the product is received, unpack the product and check for freight damage. Claims for any damage should be made to the carrier immediately. Be sure the installation kit contains all items listed on the kit packing list. Please report ¡... -
Page 4: Product Terminology
D. PRODUCT TERMINOLOGY The references used throughout this manual are illustrated in Figure 1-1 and defined in Table 1-1. Refer to Service Manual, Chapter V for more details. FIGURE 1-1: RAMP REFERENCE 32DPF401.A... - Page 5 TABLE 1-1: PF4000 RAMP COMPONENTS REF. NAME DESCRIPTION Left Right Reference point from outside the vehicle looking inward. Back Front Cassette type enclosure, rigidly attached to the vehicle, which con- Ramp Enclosure tains the ramp. Drive System Motor Electric motor used to operate the ramp. Drive System Components used to extend/DEPLOY and retract/ STOW the ramp.
- Page 6 32DPF401.A...
