BROWN PB2 Series Owner's/Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PB2 SERIES
ATTENTION:
ALL WARRANTY WORK MUST BE APPROVED BY
BROWN MFG. CORP.
AERATORS
BEFORE WORK BEGINS
Owner/Operator's Manual
WARNING
Before operating your machine,
stop and read this owners manual.
Do not attempt to operate the unit
until you fully understand the
material covered in this manual.
Without the knowledge contained
in this manual, injury or death can
result.

Advertisement

loading

Related Manuals for BROWN PB2 Series

Summary of Contents for BROWN PB2 Series

  • Page 1 PB2 SERIES ATTENTION: ALL WARRANTY WORK MUST BE APPROVED BY BROWN MFG. CORP. AERATORS BEFORE WORK BEGINS Owner/Operator’s Manual WARNING Before operating your machine, stop and read this owners manual. Do not attempt to operate the unit until you fully understand the material covered in this manual.
  • Page 2 Copyright Copyright ©2007 Brown Manufacturing Corporation. All photos and illustrations are property of Brown Manufacturing Corporation. This publication may be freely reproduced, either in whole or in part, provided that the content herein is not altered. Cover Pictured: Model PBR-1200.

  • Page 3: Table Of Contents

    Contents Warranty ........................... 4 Registration ........................5 Safety ..........................7 Specifications ......................... 13 Assembly ........................14 Replacement Parts PB2-SERIES................... 17...

  • Page 4: Warranty

    The obligation of Brown shall be limited to replacing or repairing the detective product, at the option of Brown. Brown shall not be responsible for any labor or cost of removal or repairing or reinstallation of its products and shall not be liable for transportation costs to and from its plant in Ozark, Alabama.

  • Page 5: Registration

    (30) days Serial No.: _________________ after receiving equipment. For further information: Date Purchased: ___/___/_____ Brown Manufacturing Corp. 6001 EAST HWY. 27 Dealer: ____________________ Ozark, AL 36360 Phone: (334) 795-6603 Toll Free: (800) 663-8909 FAX: (334) 795-3029 www.brownmfgcorp.com...
  • Page 6 Please use envelope.

  • Page 7: Safety

    Equipment Safety Warning: Read this manual before operation. Operators of the equipment must read and understand this manual. Failure to read this manual and follow these safety and operating instructions could result in serious bodily injury or even death. WARNING Before operating your machine, stop and read this owners manual.
  • Page 8 Unauthorized modifications to the equipment are not recommended. This could impair the function, safety, and life of the machine. • For any part of this manual that you do not understand, contact your dealer or Brown Manufacturing Corporation at (800) 633-8909. •...
  • Page 9 Equipment Safety Safety Decals The following safety decals should be attached to the equipment at all times. Should any decal become damaged or lost, it is the responsibility of the owner to replace it. Additional decals may be obtained from the manufacturer. WARNING ADVERTENCIA Antes de probar la unidad por primera vez...
  • Page 10 Equipment Safety Warning! Transport with WARNING care. Transport with care. Use slow-moving Before transporting to a new location, make certain vehicle emblem that the slow-moving vehicle (SMV) emblem is and flashing light. installed and is clearly visible. Use flashing lights Follow local and follow local traffic regulations.
  • Page 11 Equipment Safety Warning! Transport with care. WARNING Before transporting to a new location, make certain Transport with care. that the slow-moving vehicle emblem is installed Use slow-moving and is clearly visible. Use flashing lights and follow vehicle emblem local traffic regulations. and flashing light.

  • Page 13: Specifications

    SPECIFICATION PB2-SERIES Model # PB2-800 PB2-1000 PB2-1200 PB2-1700 Overall Width 8’ 10’ 12’ 17’ Working Width 7’3” 8’6” 11’ 16’9” H.P. Requirement 40-80 60-100 75-100 90-150 Weight - Lbs. 1925 2180 2480 2790 No. of Tines Axle Length 50-1/8” 57-5/8” 72-5/8”...

  • Page 14: Assembly

    Assembly Your Aerator comes fully assembled except the light kit and SMV placard that must be installed before operation begins. Step: 1 Find and mount your light kit into the mounting holes on the outside rear corners of your unit. Route the wiring harness through the frame so that your weights or weight boxes will not make contact or rub the wiring, use the provided wiring clips to secure the wiring onto the frame.
  • Page 15 Assembly MOUNTING INSTRUCTIONS FOR PULL KIT Step: 3 Find and mount tires and wheels onto hubs of transport dolly. Step: 4 Align transport dolly with the mounting brackets on the back of aerator frame, when mounting points are aligned install pins into the brackets. Make sure the flat sides align with the stops welded to the outside of one mounting bracket.
  • Page 16 Assembly Step: 6 Locate and mount tongue into the front 3-point hitch using the CAT II hitch pins. Mount tongue brace into top link positions and tongue height bracket on tongue assembly. This adjustable height bracket will need to be adjusted to match your tractor’s draw bar height, allowing the tongue to stay in a level position during operation.

  • Page 17: Replacement Parts Pb2-Series

    REPLACEMENT PARTS FOR ALL PB2 - SERIES BROWN AERATOR MODELS PB2-800, PB2-1000 PB2-1200 & PB2-1700...
  • Page 18 Replacement Parts PB2-Series...
  • Page 19 Replacement Parts PB2-Series Ref. No. Part No. Description 225-0001 Spool, 7.25” LH Cast Steel Double Flange 225-0008 Spool, 7.25” RH Cast Steel Double Flange 225-0002 Spool, end 255-0011 Nut, Tine, Bolt, 1/2 x 20 FLG, Stover 255-0010 Bolt, Tine, 1/2 - 20 x 2 3/4 Flanged 225-0003 Tine, LH 225-0004...
  • Page 20 Replacement Parts PB2-Series Pull Kit Hub Parts...
  • Page 21 Replacement Parts PB2-Series Ref. No. Part No. Description 225-5062 Axle for 8’ & 17’, PB2-800, PB2-1700 225-58375 Axle, 10’ PB2-1000 225-5738 Axle 12’ PB2-1200 225-0002 End Spool TC-165NTU 1 3/4” Nut NTU 700-225-0075 Spacer, axle 255-0007 Washer, 1-1/2”, flat, grade 8 225-0014 Dust cap TC-109...
  • Page 22 Replacement Parts PB2-Series Pull Kit Parts...
  • Page 23 Replacement Parts PB2-Series Ref. No. Part No. Qty Description 225-0025 Cylinder, hydraulic, 4” x 12” 225-0026 Hose, hydraulic 225-0046 Jack 225-0016 var. Tire & wheel 225-0041 Pin, pivot PRO38S32Z Pin, roll, 3/8” x 2” 225-0032 Carrier, 2-spindle, 2 tire 225-0033 Carrier, 4-spindle, 4 tire 500-22 TC-126A...
  • Page 24 Replacement Parts PB2-Series...
  • Page 25 Replacement Parts PB2-Series Ref. No. Part No. Description 225-0020 Frame, 8’, PB2-800 225-0021 Frame, 10’, PB2-1000 225-0022 Frame, 12’, PB2-1200 225-0023 Frame, 17’, PB2-1700 TC-126 Pin, CAT. II, lift TC-126A Pin, lynch, 7/16” 500-22 Pin, CAT II, top link MH-01 Manual holder UT-207A Pin, with hair clip...
  • Page 28 PB2 Series Version 1.1 May 2018...

This manual is also suitable for:

Pbr-1200
