WWD2-2IW
Daintree® Wireless Controls
Wireless Wall Dimmer
Product Overview
The Daintree® Wireless Wall Dimmer is a battery-powered wall switch for use in a Daintree Networked or Daintree EZ
Connect application. The WWD2-2IW device installs into an existing junction box to replace the existing wall-mounted
switch with a wireless solution that enables dimming and on/off commands to be delivered to the luminaires in its
commissioned space. The communication with the Daintree system utilizes a secure and reliable wireless connection
which helps minimize installation costs and complexity.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
RISK OF ELECTRIC SHOCK
• Disconnect power before servicing or installing product.
IMPORTANT
To ensure the product warranty is valid, please ensure
all installation instructions and environmental conditions
for storage and operation are complied with.
Installation to be performed by factory trained or qualified
personnel.
Save These Instructions
Use only in the manner intneded by the manufacturer.
If you have any questions, contact the manufacturer.
WARNING
Prepare Electrical Wiring
Electrical Requirements
• When replacing a line voltage switch, the
power must be off at the branch circuit
breaker. Bypass the line voltage switch to
provide uninterrupted power to the fixtures
and make sure the connection is properly
insulated before installing the wireless switch.
DT041
