Summary of Contents for MiTEC WTX-14014539-70-ES Series
- Page 1 WTX-14014539/40/41-70-ES-xx 8 to 12 Watt, 70 dB Gain Ku-Band ODU Operation and Maintenance Manual...
- Page 2 This page has been intentionally left blank.
- Page 3 High Power Transmitter Module This document contains information proprietary to Mitec telecom inc., or its affiliates, or to a third party to which Mitec telecom inc. may have a legal obligation to protect such information from unauthorized disclosure, use, or duplication. Any disclosure, use, or duplication of this document or of any of the information contained herein is expressly prohibited except as Mitec telecom inc.
- Page 4 This page has been intentionally left blank.
- Page 5 ES-xx High Power Transmitter Modules. It contains information intended for engineers, technicians and operators working with the transmitter module. To make inquiries, or to report errors of fact or omission in this document, please contact Mitec telecom inc . at (514) 694-9000.
- Page 6 This page has been intentionally left blank.
-
Page 7: Table Of Contents
Table of Contents Table of Contents 1 INTRODUCTION ................1 1.1 Receiving and Inspection ..................2 1.1.1 Equipment Damage or Loss ................2 1.1.2 Return of Equipment ..................2 1.2 Preparing for Installation ..................3 1.2.1 Safety Precautions ....................3 INSTALLATION & OVERVIEW ..........5 2.1 General Description ....................5... - Page 8 Table of Contents 4.1.1 Procedure ......................15 4.1.2 Transmitter Module Cooling System Preventive Maintenance......15 4.1.3 Performance Check..................16 4.1.4 Troubleshooting....................17 4.1.5 Out-of Warranty Repair..................17 APPENDIX A ..................Drawings & Schematic Diagrams ................A-1 APPENDIX B ..................Bench Test Record......................B-1 APPENDIX C ..................
-
Page 9: Introduction
Introduction 1 Introduction The WTX-14014539_40_41-70-ES-xx High Power Transmitter Modules are highly reliable, high quality, cost efficient stand-alone transmitter systems. The application for these modules is Ku- Band VSAT communication in an outdoor environment. This line of superior products, engineered using state of the art technology, is characterized by unparalleled durability and dependability. -
Page 10: Receiving And Inspection
2. Refer to the sales order, Purchase Order and the date the equipment was received. Notify Mitec Sales Administration Department of the equipment condition and obtain a Return Material Authorization (RMA) number and shipping instructions. Mitec will pay for the cost of shipping the product to the customer after the repairs are completed. -
Page 11: Preparing For Installation
Introduction NOTE Do not return any equipment without an RMA number. This is important for prompt, efficient handling of the returned equipment and of the associated complaint. Preparing for Installation Before attempting to install or use the transmitter module, we recommend that you first familiarize yourself with the product by reading through this manual. - Page 12 This page has been intentionally left blank.
-
Page 13: Installation & Overview
Installation & Overview 2 Installation & Overview General Description This section describes the installation and theory of operation of the transmitter module. The modules are stand-alone Transmitter Systems powered from 24 VDC and 110/220 VAC power sources. They will amplify an input signal from an L-Band RF source up to power levels of 8, 10, or 12 Watts CW in Ku-Band as shown below. - Page 14 Installation & Overview RF Performance ± 2.5 dB, typ. (±3.5 dB max) over full band Gain Flatness (small signal) ± 0.3 dB, p-p, max. over any 40 MHz at 10 dB back-off Gain Stability with power (expansion) 0.5 dB, max.
-
Page 15: Controls, Indicators And Connectors
Installation & Overview RF Performance O-ring Silicone Markings Labels permanent and legible Mitec Part No & Revision Level Serial No. IF Input RF Output M&C, if applicable AC Input Environmental Operational Storage Temperature to 55 C to 85 Humidity... -
Page 16: Connections And Mounting Hardware
Installation & Overview 2.3.2 Connections and Mounting Hardware The IF input connection requires a coaxial cable with an N-type male connector for the IF Input. The RF output requires a waveguide with a WR75 flat flange. An O-ring shall be used to seal the waveguide connection. -
Page 17: Securing The Transmitter Module
Installation & Overview 2.4.2 Securing the Transmitter Module Secure the transmitter module on to the mounting frame using the hardware described in section 2.3.2. Align the transmitter output waveguide flange with the mating flange of the antenna feeder waveguide. Using the O-ring and hardware provided, connect the antenna feeder waveguide. -
Page 18: If/Rf Conversion And Amplification
Installation & Overview Figure 2 block diagram illustrates the transmitter module. IF In L-Band & BUC & RF Out 10MHz reference SSPA 39 - 41dBm min @ P1dB (0 +/- 5 dBm) with 24VDC 12 VDC 8 - 12 A... -
Page 19: Internal Power Distribution Reference
Installation & Overview 2.5.4 Internal Power Distribution Reference The transmitter module operates from power source of 24 VAC for the BUC and 90 VAC to 265 VAC, 47 to 63 Hz for the SSPA. It will consume approximately 120 to 150 watts. - Page 20 This page has been intentionally left blank.
-
Page 21: Operation
Maintenance 3 Operation This chapter describes the verification of the operation and control of the transmitter module. It shall be performed by authorized personnel prior to maintenance and/or repair. Procedure Verify that the installation procedure described in Chapter 2 was completed. A complete physical check of the customer’s system is suggested. -
Page 22: Interface
Maintenance CAUTION! It is strongly recommended not to exceed -20 dBm maximum RF Input level. The RF amplifier will be in deep saturation if overdriven. RF performance will degrade significantly, and proper operation is not possible. This operational condition is the survival mode for the transmitter module. -
Page 23: Maintenance
Maintenance 4 Maintenance This chapter contains information on how to maintain, troubleshoot and repair the transmitter module. The transmitter module is extremely reliable, requiring very little preventive maintenance, or repair. Should there be a malfunction, this chapter also contains technical information to help diagnose basic failures. -
Page 24: Performance Check
Maintenance STEP 1: REMOVE 4 SCREWS TO REMOVE SHROUD COVER & BRACKETS STEP 2: REMOVE 6 SCREWS TO REMOVE SHROUD STEP 3: REMOVE 4 SCREWS TO REMOVE FAN Figure 3 – Cooling Fan Replacement To replace the fan, perform the following: 1. -
Page 25: Troubleshooting
Use Table 1 to quickly isolate a fault within the transmitter module. If the transmitter module is defective, notify Mitec and follow the process detailed in section 1.1.2. Symptom Action Fails performance test Check power source, RF source, cabling and connectors. - Page 26 This page has been intentionally left blank.
-
Page 27: Drawings & Schematic Diagrams
Appendix A Appendix A Drawings & Schematic Diagrams WTX-14014539_40_41-70-ES-xx High Power Transmitter Module - Outline Drawing Rev 2 A - 1... - Page 28 This page has been intentionally left blank.
-
Page 29: Figure 4 - Outline Drawing
Appendix A 13.40 in [340.3 mm] 11.70 in [297.1 mm] 0.41 in [10.3 mm] 8.25 in [209.6 mm] 2.34 in [59.4 mm] 6.90 in [175.2 mm] F-TYPE FEMALE IF INPUT POWER & M/C MS3102R20-15P RF OUTPUT WR75 2.03 in [51.5 mm] Figure 4 –... - Page 30 This page has been intentionally left blank.
- Page 32 This page has been intentionally left blank.
-
Page 33: Bench Test Record
Appendix B Appendix B Bench Test Record Appendix B contains the bench test record for the product version described herein. Rev 2 B - 1... -
Page 35: Serial Protocol Documentation
Appendix C Appendix C Serial Protocol Documentation Appendix C contains the Serial Protocol documentation for the product described herein, if applicable. Rev 2 C - 1... -
Page 37: Spare Parts
The order may also be sent via email or regular mail delivery, at the following address. Mitec Telecom Inc. 9000 Trans Canada Blvd. Pointe Claire, Quebec, Canada... - Page 38 Appendix C D- 2 Rev 2...
- Page 39 Spare Parts Order Form High Power Transmitter Module From: Place By: Signature: Telephone: Email: Part Description Part Number Quantity Unit Line Price* Total* * To be completed by Mitec Sales Department Fax to: Customer Service (514)694-3814 Rev 2 D - 3...
