- Page 1 Instruction manual Temperature probe and transducers for Pt1000 with (4-20) mA output Air temperature probes AR006739, AR003964, AR005387 and AR006740 Temperature transducers Pt1000 P41x1...
- Page 2 Instruction manual of temperature probes AR006739 AR003964 AR005387 AR006740 transducers P41x1 Probe AR003964 is designed for measurement of air temperature, transducers AR006739, AR005387 and AR006740 for temperature measurement in stainless steel well (well is not included). Transducers AR006734 to AR006738 (next only P41x1) without own temperature sensors are designed for signal conversion from RTD sensor Pt1000 (3850ppm/°C) to current.
- Page 3 Storing conditions: Temperature from -30 to +80 °C, humidity from 0 to 100 %RH without condensation Material of the case: ABS Dimensions: see dimension drawing Weight: AR003964 approx. 120 g, P01x2 approx. 140 g, P41x1 approx. 125 g Liquidation: Device itself (after its life) is necessary to liquidate ecologically! Temperature probe AR003964 Temperature transducers P41x1 Temperature probe AR006739, AR005387 and AR006740...
- Page 4 For connection of the cable is necessary to unscrew four screws at case corners and remove lid. Lace the cable through a gland at the case wall. Connect the cable to terminals with respecting the signal polarity (see figure). Terminals are self-clamping and can be opened by a suitable screwdriver.
