Assembly Instructions & User's Manual
Outdoor Cooking Prep Station
Please keep this instruction manual for future reference
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
Customer Service: (888) 909-3888, 7:30 am to 4:30 pm PST, Monday - Friday
--------------------------------------OR-------------------------------------
Customer Service: (888) 922-2336 7:00 am to 12:00 am CST (daily)
Product not available when manual was reviewed
Item# 163868
Model# SRCPS20001
Warning:
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Live Chat at: www.academy.com
Email: customerservice@academy.com
(Made in China)
Joe Oakes
1/19/21
QA gh 01/19/21
PS NB 1/20/21
Advertisement
Summary of Contents for Outdoor Gourmet SRCPS20001
- Page 1 QA gh 01/19/21 PS NB 1/20/21 Assembly Instructions & User’s Manual Outdoor Cooking Prep Station Item# 163868 Model# SRCPS20001 Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Exploded View ..............................2 Parts and Tools Parts, Tools and Hardware ……......................……....3-4 Assembly Instructions………......................5-14 Care & Maintenance..…...…………………...................14 Warranty Information ………..………......................Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged, do not attempt to assemble the unit. -
Page 3: Exploded View
EXPLODED VIEW Please check the contents of the packaging to ensure all parts are included. If missing parts please contact customer service. -
Page 4: Parts And Tools Parts, Tools And Hardware
PART LIST Part # Description Picture Part # Description Picture Tabletop Cabinet Left Assembly Panel Door Bottom Sink Left Panel Magnet Cabinet Bottom Faucet Assembly Panel Drainage Hose Cabinet Right Door Sink Drain with Strainer Dust Panel Side Handle Door Upper Magnet Sink Rear Panel Cabinet Upper... - Page 5 TOOLS REQUIRED Phillips Head Screwdriver (Not included) Adjustable Wrench (Not included) HARDWARE Hardware # Description Picture M6 x 10 Bolt M6 x 30 Bolt M5 x 10 Bolt M5 x 12 SS Bolt M4 x 10 Bolt M4 x 10 Stepped Bolt...
-
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Choose a good, cleared assembly area and get a friend to help you put the unit together. Lay cardboard down to protect the unit finish and assembly area. STEP 1 Attach the cabinet bottom panel (#18) to the cabinet left panel (#16) and cabinet right panel (#23) with (6) M6 x 30 bolts (BB). - Page 7 ASSEMBLY INSTRUCTIONS STEP 3 Attach (2) spigots (#10) to the cabinet rear panel (#25) with (2) spigot nuts (#11). Attach the door bottom magnet (#17) to the cabinet bottom panel (#18) with (2) M5 x10 bolts (CC). Place the cylinder hole cover (#24) to the location hole directly as illustrated.
- Page 8 ASSEMBLY INSTRUCTIONS STEP 5 Attach the dust panel (#20) to the cabinet left panel (#16) and cabinet middle panel (#27) with (4) M5 x 10 bolts (CC) as illustrated. Note: DO NOT TIGHTEN hardware until the tabletop assembly has been installed in Step 10. Hardware Used M5 x 10 Bolt STEP 6...
- Page 9 ASSEMBLY INSTRUCTIONS STEP 7 Attach the door handles (#14) and door handle Adjustable up and down bases (#15) to the cabinet left door (#13) and cabinet right door (#19) with (4) M4 x 10 bolts (EE). Attach the trash can retainer (#28) to the cabinet left door (#13) with (2) M4 x 10 stepped bolts (FF) as illustrated.
- Page 10 ASSEMBLY INSTRUCTIONS STEP 9 Attach the sink right panel (#8) and sink front panel (#9) to the cabinet assembly with (7) M5 x 10 bolts (CC) as illustrated. Hardware Used M5 x 10 Bolt STEP 10 Attach the tabletop assembly (#1) to the cabinet assembly with (8) M6 x 10 bolts (AA) as illustrated.
- Page 11 ASSEMBLY INSTRUCTIONS STEP 11 Attach the side handle (#6) to the cabinet assembly with (6) M6 x 10 bolts (AA). Attach the bottle opener (#12) to the cabinet assembly with (2) M5 x 12 SS bolts (DD) as illustrated. Hardware Used M6 x 10 Bolt M5 x 12 SS Bolt STEP 12...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 13 Plastic Washer Take the faucet assembly (#3) out of the box, then insert the faucet into the mounting hole on the tabletop by screwing it tightly with the fixing nut and washers as illustrated. Fixing Nut Washer Fixing Nut STEP 14...
- Page 13 ASSEMBLY INSTRUCTIONS STEP 15 Connect the hot/cold water pipe to the spigots assembled in Step 3. Unscrew the pre-assembled bolts on the counterweight, then attach the counterweight to the hot and cold water mixing pipe and adjust its position as needed, finally screw the bolts Connect the cold tightly as illustrated.
- Page 14 ASSEMBLY INSTRUCTIONS STEP 17 Screw the drainage hose (#4) to the sink drain on the bottom of sink tightly, then feed the drainage hose through the upper panel of Tighten the drainage hose. cabinet assembly, and route through the back of the cabinet.
-
Page 15: Care & Maintenance
ASSEMBLY INSTRUCTIONS STEP 19 Cooking Prep Station (Assembled) CARE & MAINTENANCE STAINLESS STEEL SURFACE Under extreme conditions, stainless steel can rust and the rust may not be removable. These conditions may become more prevalent in coastal areas. Always use extra precautions while cleaning the stainless steel using a soft non-abrasive cloth and a stainless steel cleaner/polish to minimize the risk of scratching the surface. -
Page 16: Warranty Information
WARRANTY INFORMATION This appliance has been manufactured under the highest standard of quality and workmanship. We warrant to the original consumer purchaser that all aspects of this product will be free of defects in material and workmanship for one (1) year from the date of purchase. A replacement for any defective part will be supplied free of charge for installation by the consumer.
