WATSON DESKING
Assemble Whiteboard
Step 1
Attach cleats to the back of
Whiteboard with
#8 x 1/2" screws (FIG-1 at
piloted locations (at
minimum).
aluminum cleat
(board mounted)
(Miro Conference)
Attach Magnet Rail to top of
Whiteboard with
#8 x 1/2" screws (FIG-1).
Attach Seiri Tray to bottom of
Whiteboard (right or left side)
with #8 x 1/2" screws (FIG-1).
Page 1 of 2
800.426.1202
www.watsondesking.com
PRODUCT INSTALLATION:
Whiteboards - MCAWBDXXXX
magnet rail
whiteboard
FASTENER KEY
Seiri tray
& bins
#8 x 1/2"
screw
1/2"
INS50065
MIRO
