- Page 1 TEMPERATURE SENSOR VEGA TD-11 USER MANUAL DOCUMENT REVISION FIRMWARE VERSION www.vega-absolute.ru...
-
Page 2: Table Of Contents
Indication ....................................14 Mounting Recomendations ..............................15 4 COMMUNICATION PROTOCOL ............................17 Sensor Vega TD-11 transmits the following types of packets ..................17 Packet with current readings ..........................17 Packet with time correction request ........................18 Settings packet ................................18 Sensor Vega TD-11 receives packets of the following types .................. -
Page 3: Introduction
Vega TD-11 / User Manual INTRODUCTION This manual is designated for Vega TD-11 device (hereinafter – device, converter) manufactured by Vega-Absolute OOO and provides information on powering and activation procedure, control commands and functions of the device. This manual is targeted at specialists familiar with installation work fundamentals for electronic and electrical equipment. -
Page 4: Description And Operation
Data collection periods when measurements in temperature range and out are set independently. Vega TD-11 may be used in systems where temperature control is required but its directly measurement is difficult. For example, car engine temperatures control and temperature control at the production rooms, stocks. - Page 5 Vega TD-11 / User Manual the "Active" mode. If all attempts fail, the device will continue to accumulate data and will attempt to connect to the network every 6 hours. Hold the start button pressed (min. 5 seconds) to switch the device from the "Active"...
-
Page 6: Functional
Vega TD-11 / User Manual FUNCTIONAL Vega TD-11 temperature sensor is class A device (LoRaWAN classification) and has the following features: Temperature measurement in range of -55… +100 °С Charge measuring of the built-in battery (%) Extra communication in case of security inputs actuation... -
Page 7: Marking
Vega TD-11 / User Manual MARKING Device marked with sticker that contain the next information: Device model; DevEUI; Month and year of manufacture; Sticker located in three places – on device case, in factory certificate and on the packing box. -
Page 8: Specification
Vega TD-11 / User Manual 2 SPECIFICATION DEVICE SPECIFICATION MAIN USB-порт mini-USB, type B Operating temperatures -40…+85 °С Measurement temperatures -55…+100 °С Hall sensor sensitivity 5 mT, bipolar External temperature sensor type B57861-S 103-F40 10 kOhm ±0.5 ºС in range -10…+40 ºС... -
Page 9: Default Device Settings
Vega TD-11 / User Manual DEFAULT DEVICE SETTINGS PARAMETER VALUE RU868 Frequency plan OTAA Activation type Adaptive Data Rate Confirmed Uplinks 1 second Rx 1 Delay 5 seconds Join Accept Delay Uplink number of transmissions Data rate 14 dBm Power... -
Page 10: Operation
Vega TD-11 / User Manual 3 OPERATION DEVICE APPEARANCE Vega TD-11 is represented in small plastic case which has four screws and mounting for DIN-rail. 1 – screw ø 2 mm х 8 mm, cross 2 – DIN-rail with mounting holes ø 3 mm 3 –... -
Page 11: Contacts Description
Vega TD-11 / User Manual CONTACTS DESCRIPTION Contact pair for External thermistor connection with the connection contacts security circuit Ʇ Temperature sensor has a two contact pairs. One pair (“Therm” and “ ” contacts) is for connect to external thermistor, another one is security input (“Drv” and “Sens” contacts). -
Page 12: Device Sensors
Vega TD-11 / User Manual DEVICE SENSORS Two Hall sensors are located on the board bottom. Hall sensor triggers in the presence of magnetic field what allows using temperature sensor for reed switch control. Should the any sensor trigger, the device sends a corresponding message to the LoRaWAN network (see part DVR2 –... - Page 13 Vega TD-11 / User Manual Tamper is located on the board top. Should the tamper triggering, the device sends a corresponding message to the LoRaWAN network. Tamper Revision № 06 – 10 August 2021...
-
Page 14: Indication
Vega TD-11 / User Manual INDICATION The device has one red LED located on the board. Indication is only used during device activation step in the LoRaWAN network and when operation modes are switch. LED location on the board LED SIGNAL... -
Page 15: Mounting Recomendations
Vega TD-11 / User Manual MOUNTING RECOMENDATIONS To provide the stable radio between the gateway and the end device is recommended avoiding the device installation in the places which are barriers for the radio signal getting through like a reinforced floors and walls, a basement, an underground facilities and wells, a metal case etc. - Page 16 Vega TD-11 / User Manual Location of the launch button on the board 7. By the laptop you can make sure that the device successfully sends the data. 8. Before assembling the device, it is necessary to reset the pulses accumulated during testing and connection by switching the device to the "Storage"...
-
Page 17: Communication Protocol
This part describes the TD-11 communication protocol with LoRaWAN network. ® In fields consisting of several bytes, the little endian byte order is used SENSOR VEGA TD-11 TRANSMITS THE FOLLOWING TYPES OF PACKETS 1. Packet with current readings Sent regularly on LoRaWAN port 2 Size in bytes... -
Page 18: Packet With Time Correction Request
Vega TD-11 / User Manual “Reason of sending message” field codes Code Value 0x00 Sending packet by the time 0x01 By the security input triggering 0x02 By the tamper triggering 0x03 By the Hall sensor 1 triggering 0x04 By the Hall sensor 2 triggering... -
Page 19: Sensor Vega Td-11 Receives Packets Of The Following Types
Vega TD-11 / User Manual SENSOR VEGA TD-11 RECEIVES PACKETS OF THE FOLLOWING TYPES 1. Real-time clock adjustment Sent by application on LoRaWAN port 4 Size in bytes Field description Data type 1 byte Packet type, this packet == 255... - Page 20 Vega TD-11 / User Manual Table of ID of TD-11 parameters and these possible values ID of Description Data Possible values parameter length Confirmed uplinks 1 byte 1 – confirmed 2 – unconfirmed Adaptive data rate 1 byte 1 – on 2 –...
-
Page 21: Storage And Transportation Requirements
Vega TD-11 / User Manual 5 STORAGE AND TRANSPORTATION REQUIREMENTS Vega TD-11 shall be stored in the original packaging in heated room at temperatures +5 °С to +40 °С and relative humidity less than 85%. The device shall be transported in covered freight compartments of all types at any distance at temperatures -40 °C to +85 °C. -
Page 22: Content Of The Package
Vega TD-11 / User Manual 6 CONTENT OF THE PACKAGE Vega TD-11 device is delivered complete with: Temperature sensor Vega TD-11 – 1 pc. External thermistor – 1 pc. Screw – 4 pcs. Factory certificate – 1 pc. Revision № 06 – 10 August 2021... -
Page 23: Warranty
Vega TD-11 / User Manual 7 WARRANTY The manufacturer guarantees that the product complies with the current technical documentation, subject to the storage, transportation and operation conditions specified in the "User Manual". The warranty period is 36 months if the number of data packets sent by the product is up to 25,000. - Page 24 Vega TD-11 / User Manual DOCUMENT INFORMATION Title Vega TD-11 temperature sensor Manual - Translation from Russian Document type Document number V02-TD11-01 Revision and date 06 – 10 August 2021 Revision History Revision Date Name Comments 14.09.2017 Document creation date 13.03.2018...
- Page 25 Vega TD-11 / User Manual vega-absolute.ru User Manual © Vega-Absolute OOO 2017-2021 Revision № 06 – 10 August 2021...
