Mini CC Burner Instruction Sheet
The Mini CC Burner uses propane, natural gas, or hydrogen with oxygen to create a wide range of flame
characteristics for flameworking applications. This instruction sheet is designed to provide the user
with a working knowledge of the burner to allow for safe and educated use. This instruction sheet is
not intended to be a guide for flameworking, but rather a guide for use of the Mini CC Burner. Please
take the time to thoroughly read through this instruction sheet to help ensure the proper use and
maintenance of the burner. This instruction sheet provides information about the Mini CC Burner.

High Oxy Mini CC

For the broadest range of flame types and the ability to work with a wide range of applications, the
high oxygen Mini CC offers an extra oxygenated flame. This allows for a high heat output with the
upper range to work with hard glass.

Pinpoint Mini CC

A special center fire allows the Pinpoint Mini CC to have a focused narrow surface-mixed flame.

Options and Accessories:

The Mini CC Burner has several options and accessories that are available. This section is intended to
provide any pertinent information for the options that may be applicable.
•
Stainless Steel Head Option: Replace the brass nozzle with all stainless steel construction for longer
life and cooler operations.
•
EL-2 Foot Controller / RMB Foot Controller: The EL-2 is an electronic foot-actuated positive closing
valve system. The RMB is a variable metering valve system that is metering only, not positive closing.
•
In-Line Disposable Filters Option: This is a highly recommended option to filter the fuel gas (except
hydrogen) and oxygen gases prior to the burner to reduce the possibility of containments from the
feed piping and supply sources.
•
Hose Options: There are many hose options. Latex hose, Welding hose, Tygon hose, Stainless Steel
Braided Hose, and Teflon lined hose to name a few. Refer to Bulletin 24D on the website for
ordering.

Surface Mixed:

The Mini CC Burner is surface mixed. Surface mixed burners deliver the gas and oxygen to the face
separately so that the mixing of gases happens as they exit the burner face. This produces a safe flame
for working with any application. Surface mixed burners do not have the possibility for combustion to
take place inside of the burner (this is commonly known as Flashback) since the gas and oxygen are not
mixed until they exit the burner. However, certain conditions (such as an internal leak) could cause a
Flashback to occur.
