Bard Q/TEC Manual

Bard Manufacturing Company
Bryan, Ohio 43506
The following are the installation instructions for the Condensate Drain Box:
1. Four 3/16" holes must be drilled in the sleeve side for the drain mounting
screws. (Refer to Figure 1.)
2. A 1/2" hole must be drilled in the sleeve side for the overflow tube. (Refer to
Figure 1.)
3. Connect the drain line to the Wall Drain before mounting.
4. Place the drain box against the sleeve so the mounting holes line up.
5. Install the four mounting screws from the inside of the sleeve out.
6. Seal the inside of the sleeve where the overflow tube sticks through. (Refer
to Figure 2.)
7. Remove the pipe plug from the rear drain of the Q/T
8. Install the plug in the side Q/T
9. Install the water trap in the rear Q/T
10. Follow unit instructions for installation of the unit into the sleeve.
Copyright February, 1997
Q/T
CONDENSATE DRAIN
SYSTEM
drain.
EC
drain. (Refer to Figure 3.)
EC
EC
drain.
EC
Manual
Date
Page
7960-369A
11-01-05
1 of 4
