Summary of Contents for ElectrIQ iQ-SPEED
- Page 1 USER MANUAL HD BABY MONITOR CAMERA WITH WIFI iQ-SPEED Thank you for choosing electriQ Please read the manual before using this camera and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire product range...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION AND SAFETY PARTS LIST PRODUCT OVERVIEW INSTALLATION CAMERA ADJUSTMENT CAMERA FUNCTIONS APP INSTALLATION PREPARING THE CAMERA FOR APP CONNECTION WI-FI CONNECTION DEVICE SCREEN SETTINGS MENU TROUBLESHOOTING TECHNICAL SPECIFICATION SUPPORT... -
Page 3: Introduction And Safety
Thank you for choosing electriQ With your new HD baby camera, you can rest easy knowing that you can see your baby with a few easy clicks. Watch your camera feed from the comfort of anywhere in your home and know that you can always be sure that your baby is safe. -
Page 4: Parts List
PARTS LIST BRACKET SCREWS CAMERA USB CABLE (2 Meters) POWER ADAPTOR AND WALL PLIGS PIN (FOR SD CARD REMOVAL) MOUNTING BRACKET PRODUCT OVERVIEW Working status indicator Microphone SD card slot Reset Speaker Call button Power inlet... -
Page 5: Installation
INSTALLATION Your baby monitor can be installed in two ways for increased adaptability. You can install your camera by simply standing the camera on a flat surface, or use the provided tools for wall mounting. FLAT SURFACE INSTALLATION Simply unpackage your new baby monitor, attach the provided USB cable to the provided plug and plug into the mains. -
Page 6: Camera Functions
CAMERA FUNCTIONS Red light: The camera network is abnormal. Flashing red light: Awaiting Wi-Fi connection WORKING STATUS INDICATOR Blue light: Camera running correctly Flashing blue light: Currently connecting MICROPHONE Captures sound for your video SD CARD Supports local SD Card storage (Max.128G) Press and hold for 5 seconds with provided pin to RESET reset the camera (if you have modified settings, they... - Page 7 1. Once installed the app 2. Read the Privacy policy and needs to be registered, press the Agree button. following next steps:Press register button at the bottom of the screen. 3. Enter your email address or phone number press continue to register.
- Page 8 4. A verification code 5. Type in the password you will be sent by the would like to create. This method selected in needs to be 6-20 characters, step 3. Enter the code containing letters into the app. numbers. 6. The app is now registered. It will automatically log you in following registration.
- Page 9 SETTING UP YOUR HOME WITHIN THE APP TUYA is designed so it can work with a large number of compatible smart devices within your home. It can also be set up to work with multiple devices within different houses. As such during the setup process, the app requires that different areas are created and named to allow easy management of all your devices.
- Page 10 SETTING YOUR LOCATION Use your finger to move the orange HOME symbol. When the symbol is in the approximate location of your home, press the CONFIRM button in the top right corner. ADD ANOTHER ROOM Type the name of the room to add, and press Done in the top right corner.
- Page 11 CONNECTING USING QR CODE Before initiating the connection, make sure your phone is connected to the WiFi network you wish to connect the camera. 1. Open app and press 2. Select the type of device as “+” to add device, or “Smart video Camera”...
- Page 12 2. Press the orange button 3. Enter the password for your WIFI network (Please at the bottom of the note this is case sensitive) screen to confirm.
- Page 13 4. Choose “Continue” and use camera to scan the QR Code show your phone. Hold your phone about 15-20cm from the camera to scan the code and wait for device to connect. (EXAMPLE) 5. The camera will then attempt to connect to your network, which can take around 30 seconds.
-
Page 14: Device Screen
DEVICE SCREEN – LIVE VIEW Settings Quality of feed Displays current signal strength Mute video feed Enter full screen view Record live view video. Capture a photo of live feed. Press to speak through the camera. Access Access previously previously captured images recorded videos... -
Page 15: Settings Menu
SETTINGS MENU CHANGING THE NAME OF YOUR DEVICE When in any of the device screens further settings for the device can be accessed, by pressing on the three dots in the top right hand corner. The top option within this allows you to change the name of the device to something relevent to the use of the product, such as “FRONT DOOR”... - Page 16 Press “PIR” to set the motion sesnsor sensitivity. Low/Medium/High/Off Low: Wake up and record footage if any motion. Medium: Wake up and record footage if any motion in front of the camera last for more than 5 seconds. A notification will be sent to mobile devices at the same time. High: Wake up and record footage if any motion in front of the camera last for more than 1 second.
-
Page 17: Troubleshooting
TROUBLESHOOTING CONNECTION Ensure the WiFi password has been entered into the app correctly ( Case sensitive) Check that the phone is connected to the WiFi you are connecting the device to. Ensure the network you are connecting it to is 2.4Ghz (5Ghz WiFi networks are not supported), and that there is a strong WiFi signal to the item. -
Page 18: Technical Specification
TECHNICAL SPECIFICATION Camera Image sensor 1080P Colour Sensor 1/2.9''CMOS Shutter 1/25~1/100,000 per second Adjust angle Tilt：0°~60°；Pan：0~355° Lens 3.6mm Angle of view 105° Day & night Electronic (IR-CUT filter with auto switch) Digital WDR Video Audio Video compression H.264 Bit rate 32Kbps~2Mbps Audio Input/output Built-in microphone and speaker... -
Page 19: Support
UK SUPPORT www.electriQ.co.uk/support Service Line: 03303903061 Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk Unit J6, Lowfields Business Park Lowfields Way, Elland West Yorkshire, HX5 9DA Disposal: Do not dispose this product as unsorted municipal waste. Collection of such waste must be handled separately as special treatment is necessary.
