Summary of Contents for innovair AirClean V9
- Page 1 AirClean V9 Air Purifier AirClean V9 User Manual This document includes important tips to prolong the life of your filters and get the most out of your new air purifier.
-
Page 2: Table Of Contents
Contents Important Safety Instructions Introducing your InovaAir AirClean system ® How your AirClean system works Positioning your AirClean system System operation Getting the most out of your AirClean system Accessing the filters When to replace the filters Replacing filters Ordering new filters System warranty... -
Page 3: Important Safety Instructions
Important safety instructions Please read these instructions before operating the InovaAir System and keep for future reference. ® To reduce the risk of fire, electric shock, or injury 1. Do not detach motor-outlet module until the system has 15. The appliance is not to be used by persons (including been switched off. -
Page 4: Introducing Your Inovaair ® Airclean System
Introducing your InovaAir AirClean system ® Inside the V9 box, you will find the InovaAir unit consisting: ® • V9 System Case/Motor • V9 Pre-filter (pre-installed) • Filter Base Plate (detachable) • V9 HEPA Filter (pre-installed) • Power Cable (located in base of box) Certified Medical- Electrostatically grade HEPA filter... -
Page 5: How Your Airclean System Works
How your AirClean system works Air is drawn into the system through the sides of the unit. Air passes through the fine dust pre-filter. Air passes through the H13 HEPA filter which removes dust, allergens and sub- micron fine particle matter. The purified air is then returned to the room via the high air-flow diffuser. -
Page 6: System Operation
System operation Speed Control The system has 4 speed settings and uses an energy efficient European AC fan. Power consumption is relative to the selected speed. Control position Speed Level High Power Consumption (Watts) The higher the speed, the more times per hour the air in your living space will be cleaned, so it is recommended to run the system at the highest speed you are comfortable with. -
Page 7: Getting The Most Out Of Your Airclean System
Getting the most out of your AirClean system Always operate the system with windows closed. Air purifiers are not designed to filter the great outdoors, like an air conditioner or heater leaving a window open will render the system ineffective. Use of evaporative coolers will also reduce effectiveness. Operate the system 24/7. -
Page 8: Accessing The Filters
Accessing the filters 1. Disconnect the power cord. 2. Ensure system is sitting on a flat and even surface. 3. Pull top of the latches (A) away from the main unit. 4. Push the latches back towards the main unit (B) 5. -
Page 9: When To Replace The Filters
When to replace the filters Stage 1: Pre-filter The pre-filter is the initial stage of filtration, filtering large dust particles right down to ultra-fine sub-micron particles as well as viruses and bacteria. It is made from a patented material used in respirators and face masks. On average the pre-filter is designed to last up to 6 months of continuous use. -
Page 10: Replacing Filters
Replacing filters The HEPA filter can be lifted from the base and replaced when required. The pre-filter is wrapped around the HEPA filter & fastened with Velcro. Gently unwrap from the filter & replace with a new pre-filter. Ensure pre-filter is installed so the ‘fluffy’... -
Page 11: System Warranty
System warranty Definitions Warranty application In this warranty: This Warranty applies only: “ACL” refers to the Australian Consumer Law . “Back to Base” means where delivery a. To a Product that is supplied new to You by InovaAir ® Australia or by any other to and collection of your product from the Service Agent is your responsibility. - Page 12 AirClean V9 Air Purifier InovaAir Australia Pty Ltd Unit 8, 1 Reliance Drive, Tuggerah, NSW 2259 Australia TEL: 1300 137 244 www.airclean.com.au...
