- Page 1 OI WOW Eclipse Undersink Storage 147/6114 48cm 30cm 60cm Issue 1 - 10/10/13...
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below Left side panel Back panel x 2 Right side panel Adjustable shelf Top panel Bottom panel Door panel Corner piece x 4...
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note:The quantities below are the correct amount to complete the assembly .In some cases more fittings may be supplied than are required. Φ4 x 12mm Screw x 30 Locking Pin x 16 Locking Nut x 16 Φ3 x 12mm... - Page 5 Assembly Instructions Step 1 Assembling side panel and door panel Loosen straight hinge screw as shown to separate it into & Φ4 x 12mm screws to fix straight hinge onto door panel Screw locking pins into corner pieces as shown. Tips: not make the hinge in wrong way Attach corner pieces...
- Page 6 Assembly Instructions Step 2 Assembling the unit Carefully attach side panels to top panel and bottom panel ,insert locking nuts into it, tighten locking nuts to secure the unit. Step 3 Assembling back panel Use Φ3 x 12mm screw to fix back panel to the unit,please make sure the bracket hole on back...
- Page 7 NOTE:If you have damaged or missing components, After above assembly, please call the Customer Helpline:08456 400800 double check and make sure all Argos LTD,489-499 Avebury Boulevard, screws are tightened before us. Central Milton Keynes, MK9 2NW...
-
Page 8: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
