Summary of Contents for LiteBee Electromagnet Module Y17-AI
- Page 1 Electromagnet Module Pro d uc t M anual...
-
Page 3: Table Of Contents
CONTENTS Product introduction About the product Firmware Brief introduction Packing list Firmware version Specification Firmware updating Installation Programming Installing steps Reference case... -
Page 4: Product Introduction
Product introduction The electromagnet extension is an additional accessory for LiteBee Wing. It can lift and drop the iron materials by its electromagnet. Combined with the drone, the extension also can be programmed to transfer the matrials automatically. This extension provides a chance for kids to practice their programming skill and learn how the programming can be applied. -
Page 5: About The Product
ABOUT THE PRODUCT Packing list Specification Model: Y17-AI Size: 40*40*8mm Working voltage/current: 5V/@80mA Electromagnet unit*1 Counterweight holder*1 Electromagnet holder*1 Long bolt*8 Size of QR code: 24*30cm Max load: 500g Actual load: 0-8g Connecting cable*1 Short bolt*8 Nylon screw*2 Nut*2 Electromagnet*1 QR code for position*15 Adsorbate*20... - Page 6 “Add Extension” Click the exclamation mark (pic 1) to make sure the controller connected(pic 3) Check the version on the button line of LiteBee Go(pic 4) FV shows the version of the aircraft RV shows the version of the controller...
- Page 7 pic 1 pic 2 pic 3 pic 4...
- Page 8 How to update the version To download the corresponding document for firmware upgrading on LiteBee official web Or, you can find relevant video for firmware upgrading on YouTube channel - LiteBee, search “Guide for firmware upgrade” Official Website:https://www.litebee.com/product/liteBeeWing/download pic 5...
- Page 9 INSTALLATION Disassemble these arms of rotor； Replace them by long bolt； Fix the electromagnet on the Remove these short bolts. And then reassemble it. holder with a screw； Tighten the screw until it can't twist.
- Page 10 Insert 4 short bolts into the bottom Insert the connecting cable into the Fix the counterwight holder of the drone. electromagnet unit. on the front； Fix the electromagnet on the back.
- Page 11 Install theelectromagnet unit on the Insert the cable into the broadside Connect the power line with the bottom of the drone； of the drone. electromagnet unit. Attention: the blank side face to the bottom of the drone.
- Page 12 Finished...
- Page 13 Link the drone with the controller first Connect the controller with computer by USB cable Step 2: Electromagnet mode Start LiteBee Go Click “Add extension” Click “Identification card + attract and lift” PS: If there is a green tick mark, connected; if a orange exclamation, click the...
-
Page 14: Reference Case
Reference case Task Let the drone fly to the QR code No.0 and hover; then land and turn on the electromagnet and lift the adsorbate; take off again and fly to the QR code No.10; hover and turn off the electromagnet to drop the adsorbate; land. Case Mind map Start... - Page 16 Manufacturer: Shenzhen Makerfire Technology Co., Ltd. Website: www.litebee.com Tel: 44-830-2598 Email: sales@litebee.com Address: 25th Floor, A7 Building, Creative City, Liuxian Ave, Xili Street, Nanshan District, Shenzhen, China.
