SATO Argox PI-1000 Series Quick Start Manual

Keypad and function button

1. Scan key
2. Cursor key
3. Control Key
4. Numeric keys
5. Power key
6. User-defined keys
Alpha key
Switches between the character
input mode and the number
input mode [abc][ABC] lit on the
LCD screen indicates the
character input mode. When
[123] is lit, the terminal is in the
number input mode.
Control Key
ESC: The Escape key
ENT: The Enter key
BS: The Backspace key
Fn key:
► Fn+Down: Adjust the backlight brightness
► Fn+Left: Reduce the volume.
► Fn+Right: Increase the volume
Reset Key
Power key + Scan key: Warm / Software reset
Power key + Scan key(6 sec up): Cold / Hardware reset
PI-1010/PI-1030 EN 300 328 BT RF Power EIRP 1.92 dbm
PI-1030 EN 300 328 WIFI RF Power EIRP 19.04 dbm
Argox Information Co., Ltd.
7F., No.126, Ln.235, Baoqiao Rd.,
Xindian Dist., New Taipei City 231,
Taiwan (R.O.C.)
Tel: +886-2-8912-1121
Fax: +886-2-8912-1124
http://www.argox.com
See User Manual for more information
Copyright © 2016. Argox Information Co., Ltd. All Rights Reserved.
All manuals and user guides at all-guides.com
SCAN
6
PI-1010 EN 300 328 BT RF Power EIRP 1.92 dbm
PI-1030 EN 300 328 BT RF Power EIRP 1.92 dbm
PI-1030 EN 300 328 WIFI RF Power EIRP 19.04 dbm
49-PI101-002
Rev. A – May,2018
1
2
PI-1000 Series Mobile Computer
3
Quick Start Guide
4
Depending on the configuration ordered, the PI-1000 Series shipping
container may include:
5
PI-1000
Holder (Option)
Quick Start Guide Hand strap
USB Cable or
RS-232 Cable with USB power cord
Plug and Power Supply (Accessory)
