Summary of Contents for AM Telecom AMM5500

Page 1 AM TELECOM Communication Module AMM5500 Hardware User Guide Rev 0.1 2021.04...
Page 2 IN NO EVENT WILL AM TELECOM OR ITS AFFILIATES BE LIABLE FOR ANY LOST PROFITS, LOST SAVINGS OR INCIDENTAL, INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES, ARISING OUT OF USE OR INABILITY TO USE THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 3 Revision History ■ Version Date Description Editor Draft 2021.04.01 Initial release M.S KANG...
Page 4: Table Of Contents
Contents INTRODUCTION ........................6 1. SYSTEM SPECIFICATION ....................7 1.1..................7 HYSICAL FEATURE 1.2............... 8 NTERFACE PARTS SPECIFICATION 1.2.1. Coaxial RF connector ................8 1.2.2. Host interface connector ................. 8 1.3..................9 ODEM SPECIFICATION 1.3.1. Modem Frequency specification .............. 9 1.3.2.
Page 5 6. MECHANICAL DESIGN GUIDE ................... 25 6.1..................25 LAYOUT GUIDE 6.2....................26 NSERT NUT 6.3....................... 26 CREW 7. CAUTIONS ........................27 7.1..................27 AFETY PRECAUTIONS 7.2..............27 RODUCT HANDLING PRECAUTIONS 8. ACRONYMS ........................28 9. OEM/INTEGRATORS INSTALLATION GUIDE ..............29 CONTACT INFORMATION ....................
Page 6: Introduction
Introduction This module is designed with a Qualcomm MDM9207 chipset solution. It supports LTE, GNSS with small size and thin 3.0mm thickness. It will be given a best choice to all customers who want LTE wireless data communication. Any portable devices such as Laptop, Tablet PC and PDA, and various M2M devices can be designed with minimum efforts.
Page 7: System Specification
1. System Specification 1.1. Physical feature Item Specification 30.0±0.50 (W) x 42.0±0.50 (D) x 3.0±0.30 (H) mm (*1) Dimension Weight T.B.D Mounting type Screw : The dimension includes a label thickness (*1) NOTE Figure 1. Physical dimension Note A: Transceiver and Receiver antenna for LTE bands Note B: Receiver antenna for LTE bands.
Page 8: Interface Parts Specification
1.2. Interface parts specification 1.2.1. Coaxial RF connector SIGNAL Figure 2. Coaxial connector The terminal specifications of the RF interface connector (20279-001E-01) used in this product are as follows. Connector Signal Terminal Contents Remarks Tx/Rx SIGNAL Max 6GHz Support Signal RF Interface Conn Tx/Rx The recommended RF connectors to connect with the product are listed below.
Page 9: Modem Specification
1.3. Modem specification 1.3.1. Modem Frequency specification Technology Downlink Uplink Comment 2110 ~ 2170 MHz Band 1 1920 ~ 1980 MHz 1930 ~ 1990 MHz Band 2 1850 ~ 1910 MHz 1805 ~ 1880 MHz Band 3 1710 ~ 1785 MHz 2110 ~ 2155 MHz Band 4 1710 ~ 1755 MHz...
Page 10: Electrical Specification
1.3.2. Electrical Specification Parameter Description Min. Typ. Max. Units +VPWR Operating voltage High-level Input Voltage, CMOS Low-level Input Voltage, CMOS 0.63 High-level Output Voltage, CMOS Low-level Output Voltage, CMOS 0.45 Note: Refer to 4.Current Consumption...
Page 11: Environment Specification
1.3.3. Environment Specification Item Spec. Storage Temperature -40℃ to + 90℃ Operating Temperature -40℃ to + 85℃ Humidity (Operational) 85% relative humidity, Non-condensing Vibration (Operational) 5 Hz to 500 Hz sinusoidal, 1.0G Drop No damages after 75cm drop over concrete floor ESD [Electrostatic discharge] +/- 1 kV Human Body Model...
Page 12: Rf Specifications
1.4. RF specifications 1.4.1. RX/TX frequency specification - LTE mode Specification Comment Item UL conf Condition DL conf Unit RB idx Maximum 1.4MHz QPSK 1.4MHz 1,5 RB Low/ Output 5MHz 5MHz 1,8 RB High 22.0dBm Power 10MHz 10MHz 1,12 RB +/- 2.0dB (Class III) 15MHz...
Page 13: Rx/Tx Frequency Specification - Wcdma Mode
B1<-96.3 Minimum QPSK QPSK 1.4MHz B2<-94.3 Sensitivity Level full RB 5MHz B3<-93.3 10MHz B5<-94.3 10MHz 50 RB 15MHz B7<-94.3 B8<-93.3 20MHz B12<-93.3 B20<-93.3 64QAM Maximum input QPSK 10MHz >- 25.7 10MHz 50 RB Cat4 50RB Level 1.4.2. RX/TX frequency specification - WCDMA mode Item Specification Maximum Output Power...
Page 14: Interface Connector
2. Interface Connector 2.1. Pin assignment Pin Name Pin NO Pin NO Pin Name POWER_KEY (*1) USB_D+ Reserved (*1) USB_D- Reserved (*2) Notch (*2) (*2) Notch Notch (*2) (*2) Notch Notch (*2) (*2) Notch Notch (*2) Notch UART1_RTS (*1) Reserved UART1_TXD WAKE_UP UART1_RXD...
Page 15: Pin Description
2.2. Pin Description Block Pin name Pin Voltage /OUT Description Ground Ground Ground Ground Ground Ground Ground Ground Power Ground Ground Ground Ground 3.8V Main power(3.4V ~ 4.2V) 3.8V Main power(3.4V ~ 4.2V) 3.8V Main power(3.4V ~ 4.2V) 3.8V Main power(3.4V ~ 4.2V) 3.8V Main power(3.4V ~ 4.2V) Notch...
Page 16 UART1 Input for Request to send UART1_RTS 1.8V signal(RTS) from DTE (HOST → MODULE) UART1 Serial data input from DTE UART1_TXD 1.8V (HOST → MODULE) UART1 Serial data output from DTE UART1_RXD 1.8V (HOST  MODULE) UART1 data carrier detect UART1_DCD 1.8V (HOST ...
Page 17 Interface SGMII_RX_M SGMII receive - minus SGMII_TX_P SGMII transmit - plus SGMII_TX_M SGMII transmit - minus ETH_RESET_N 2.85V Ethernet PHY reset ETH_INT_N 1.8V Ethernet PHY interrupt SGMII_MDIO_CLK 2.85V SGMII Clock SGMII_MDIO_DAT 2.85V SGMII Data (*1) Reserved (*1) Reserved (*1) Reserved (*1) Reserved (*1)
Page 18: Modem Interface Description
3. Modem Interface Description 3.1. Power supply Requirement of Input Voltage is refer to the below table Item Pin NO Comments Units Supply 2, 4, 70, 72, 74 Voltage (High-level Input Voltage) (Low-level Input Voltage) (High-level Output Voltage) 0.45 (Low-level Output Voltage) Note : The Operating Voltage Range MUST never be exceeded;...
Page 19: Usim Interface
Figure 3. USB interface circuit 3.3. USIM Interface This module supports UIM interface as the below table. Pin no. Pin name Pin description Direction UIM_PWR UIM power Output UIM_CLK UIM clock Output UIM_RESET UIM reset Output UIM_DATA UIM data Output/Input Figure 4.
Page 20: Wlan Interface
UART1_RTS Request to send Module ← Host UART1_DSR Data set ready Module → Host UART1_DTR Data terminal ready Module ← Host UART1_DCD Data carrier detect Module → Host UART1_RI Ring indicator Module → Host UART2_RXD Receive Data Module → Host UART2_TXD Transmit Data Module ←...
Page 21: In/Out Interface
Pin no. Pin name Pin description In/Out Direction SGMII_RX_P SGMII receive - plus Module ← Host SGMII_RX_M SGMII receive - minus Module ← Host SGMII_TX_P SGMII transmit - plus Module → Host SGMII_TX_M SGMII transmit - minus Module → Host SGMII_MDIO_CLK SGMII Clock Module →...
Page 22 Figure 7. Power_Key Circuit...
Page 23: Reset_Key
3.7.2. RESET_KEY To reset, it must keep low for more This pin is for hardware reset of this module. than 2.5 seconds and the maximum time is less than 5 seconds. Pin no. Pin name Pin description Direction Hardware Reset, Active low RESET_KEY Input Internal pulled-up to1.8V...
Page 24: Usb_Disable
3.7.4. USB_DISABLE This pin is used when you do not use the USB function. Pin no. Pin name Pin description Direction Active low signal to disable USB USB_DISABLE Input operation Note: Please do Not Connect, if you do not use this pin. 3.7.5.
Page 25: Current Consumption
4. Current Consumption The current consumption of the module is listed as below table. The listed current consumption is tested when the power supply of module is 3.3 V. Mode Unit Condition Typ. Peak current Band 7 CH BW=10MHz, TX=0dBm Data Call Band 7 CH BW=10MHz, TX=22.5dBm...
Page 26: Insert Nut
5.2. Insert nut Figure 10. Insert nut guide Note: (1) Insert nut must be connected to GND for RF radiation performance. (2) This guide is based on PCI express®M.2 connector (Kyocera part no. 24 6411 067 101 894B). In case of using different kind of connector, customer should consider if the insert nut and screw need to be changed.
Page 27: Cautions
Safety precautions This module should be used at authorized places or environments due to frequency jamming possibility while operating. If occur any issues when the module operates at not authorized places or environments, AM TELECOM does not have any responsibility. ①...
Page 28: Acronyms
⑪ Do not presses the shield CAN. It can cause electrical short or declining RF performance by the CAN damage. 7. Acronyms Word Description Band Width A type of (relative) scale that represents the difference of some value as An abbreviation for the power ratio in dB of the measured power referenced to one milliwatt (mW).
Page 29: Oem/Integrators Installation Guide
OEM/Integrators Installation Guide Important Notice to OEM integrators 1. This module is limited to OEM installation ONLY. 2. This module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). 3. The separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations 4.
Page 30 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 31 Industry Canada Statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Page 32 End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains IC: 27086-AML550”. Plaque signalétique du produit final Ce module émetteur est autorisé...
Page 33: Contact Information
9. Contact Information ➢ Korea E-mail Sales@amtel.co.kr AM TELECOM Co., Ltd #608, YatapLeaders bldg., 42, Jangmi-ro, Bundang-gu, Address. Seongnam-si Gyeonggi-do, 463-828, Korea ➢ Japan E-mail amjapan@amtel.co.jp AM Japan Co., Ltd Address. #201E Shinkasumigaseki Bldg. Lobby floor., 3-3-2, Kasumigaseki, Chiyoda-ku, Tokyo, 100-0013...
