DwarfConnection DC-X.LINK-XS3 Quick Start Manual

Quick sTarT guidE
DC - X.LINK-XS3
What's in the Box?
1x X.LINK-XS3 wireless video receiver
1x NPF battery plate
1x Spacer for NPF battery plate
1x Mounting piece for NPF battery plate
1x Power cable 4-pin to D-Tap
4x M3x6 socket head screws
4x M3x25 flat head screws
Getting Ready
1. Power your devices. Find details about
proper powering options in the product
manual provided on our website.
2. Connect the receiver to the monitoring,
recording or distribution device of your
joice.
Establishing a Connection
Use the power switch to turn on your receiver.
Make sure that your devices are set to the
same channel. (see "Choosing a Channel")
It takes between 10-30 seconds for the
transmitter to connect to the receiver. During
this brief period, the receiver's video output
displays "Waiting for connection".
Once the transmitter recognizes a video input,
the video format will be displayed on the
OLED display.
RSS Indicator
The RSSI (Wireless Received Signal
Strength Indicator) is displayed right next
to the channel information on the OLED
display. Five dots show the signal strength:
Status Description
Radio signal strength is weak and
0-1
artefacts are visible in the video signal
Radio signal strength is normal and
2-3
video quality is good
Radio signal strength is very strong and
4-5
video quality is very good
