175LB TOW-BEHIND SPREADER
ASSEMBLY AND OPERATION INSTRUCTION MANUAL
HELPFUL HINTS:
READ THE DIRECTIONS BEFORE ASSEMBLY
WHEN ALL ELSE FAILS, READ THE DIRECTIONS AGAIN
If your spreader does not spread evenly, be sure the FRONT on the gear
box points to the front of the spreader. The impeller must turn clockwise.
Reversing the gear box will cause the impeller to turn counter clockwise.
Clean the impeller plate after each use. Fertilizer stuck on the impeller blades
will cause uneven spreading.
Your spreader is designed to be pushed at three miles per hour, which is
a brisk walking speed. Slower or faster speeds will change the spread
patterns. Wet fertilizer will also change the spread pattern and flow rate.
Clean your spreader thoroughly after each use. Wash between the shut off
plate and bottom of the hopper.
Gears are permanently lubricated at the factory. Do not open the gear box
or dirt may enter.
Advertisement
Summary of Contents for Euro garden SP31510
- Page 1 175LB TOW-BEHIND SPREADER ASSEMBLY AND OPERATION INSTRUCTION MANUAL HELPFUL HINTS: READ THE DIRECTIONS BEFORE ASSEMBLY WHEN ALL ELSE FAILS, READ THE DIRECTIONS AGAIN If your spreader does not spread evenly, be sure the FRONT on the gear box points to the front of the spreader. The impeller must turn clockwise. Reversing the gear box will cause the impeller to turn counter clockwise.
- Page 2 1. Remove and identify loose parts from carton and bag. Big Flat Washer Ø6...
- Page 3 ASSEMBLY INSTRUCTIONS STEP 1: 1.Assembly the first flat washerØ20,the support spacer,the second flat wahsner Ø20, and the third flat washer Ø20 onto the end of the axle of lnstall tube assembly in turn.First insert the Ø4x40 cotter pin into the small hole on the axle and then bend to fix it.(see illustration a).
- Page 4 Step3 Connect two Hitch Braces (each at one side) and the hole at the back of Hitch Tube by using Bolt M6x50 and Nylon Lock Nut M6 ,don't screw them up temporarily.(see illustration e) 2.Connect two Hitch Braces (each at one side) and the hole at the middle of Adjust Plate Support Tube by using Bolt M6x50 and Nylon Lock Nut M6,don't screw them up temporarily.
- Page 5 Step 5 1.Put the Hopper Screen into the end of Hopper Assembly(see illustration j) 2.Put the support rod into the hole on the hopper using Hex Bolts M6x20, Big Flat WashersØ6 and nylon Lock nuts. Step 6 Connect Adjust Handle Assembly and Support Bar by using two Bolts M8x40 and two Nylon Lock Nuts M8 and don't screw them up moderately.
- Page 6 Step 7 1.Connect the Hitch Break and the head of Hitch Tube by using two Hex Bolts M6x50 N ylon Lock Nuts M6. Connect them according to the illustration m would be ok as well.Through this way, the length of Hitch Tube is changed. Step8 Step8...
-
Page 7: Parts Drawing
PARTS DRAWING PARTS DRAWING PARTS DRAWING PARTS DRAWING... -
Page 8: Parts List
PARTS LIST Ref# Description QTY Ref# Description Tire Fixing Plate for Wing Nut Spacer Nylon Flat Washer Flat WasherØ20 Wing Nut M6 Bushing Hex Bolt M8x40 Cotter Pin Ø4x40 Hex Bolt M6x20 Swivel Axle Adjust Handle Gear (Driver) Handle Crip Spring Pin Ø4x35 Big Flat WasherØ6 Shaft Support Cap...
