Summary of Contents for LedgeTech Rocky Talkie

  • Page 1 USER MANUAL 2020...

  • Page 2: Table Of Contents

    Table of contents Operating the Rocky talkie Display screen Technical Specs FAQ - Frequently asked questions Channel Settings Privacy codes FCC Regulation, FCC ID, IC id...

  • Page 3: Operating The Rocky Talkie

    OPERATING THE ROCKY TALKIE...

  • Page 4: Display Screen

    Display screen...

  • Page 5: Technical Specs

    Technical specs Radio Service FRS (no license required) Channels Privacy Codes 121 (CTCSS and DCS) Range Line-of-sight: 25+ miles Mountains: 1 to 5 miles Forest/Hills: 0.5 to 3 miles City: Up to 1 miles Waterproofing IP56 (Splashproof / Snowproof, not submergible) Power 2 Watt Battery Type...

  • Page 6: Faq - Frequently Asked Questions

    Frequently Asked Questions What makes the Rocky Talkie different from other radios? The Rocky Talkie is designed for athletes to push their limits in the outdoors. Unlike the fragile plastic belt clips of other radios, our radio easily secures to backpacks and harnesses using an ultra-light carabiner.
  • Page 7 Motorola radio set to channel 5 privacy code 32 will match a Rocky Talkie set to channel 5 privacy code 41. The privacy codes for Rocky Talkies purchased after January 18, 2020 will match...
  • Page 8 To switch between the two, hold down the Volume + button for 2 seconds. What is the warranty policy for Rocky Talkies? The Rocky Talkie is backed by a 2 year warranty. See more about the...
  • Page 9 How long does it take to charge a Rocky Talkie? To fully charge a Rocky Talkie from 0% to 100% battery it takes around 5 hours. An indicator light near the USB-C port shows red when the radio is charging, and green indicates the radio is fully charged.
  • Page 10 Do I need a license to use Rocky Talkies? The Rocky Talkie operates on FRS license-free frequencies and no license is necessary. What frequencies does the Rocky Talkie transmit and receive? The radios transmit on FRS license free frequencies which range from 462 to 467 MHz.

  • Page 11: Channel Settings

    CHannel settings Each channel on the Rocky Talkie is set to one of the 22 allowed FRS frequencies. The first 22 channels come preset with with no privacy code activated. The rest of the 128 channels are preset with a privacy code to make finding an open channel easier.
  • Page 12 Channel Frequency (MHZ) Power 462.7000 2 watt 462.7250 2 watt 462.5625 2 watt 462.5875 2 watt 462.6125 2 watt 462.6375 2 watt 462.6625 2 watt 462.6875 2 watt 462.7125 2 watt 467.5625 0.5 watt 467.5875 0.5 watt 467.6125 0.5 watt 467.6375 0.5 watt 467.6625...
  • Page 13 Channel Frequency (MHZ) Power 462.6625 2 watt 462.6875 2 watt 462.7125 2 watt 467.5625 0.5 watt 467.5875 0.5 watt 467.6125 0.5 watt 467.6375 0.5 watt 467.6625 0.5 watt 467.6875 0.5 watt 467.7125 0.5 watt 462.5500 2 watt 462.5750 2 watt 462.6000 2 watt 462.6250...
  • Page 14 Channel Frequency (MHZ) Power 467.6375 0.5 watt 467.6625 0.5 watt 467.6875 0.5 watt 467.7125 0.5 watt 462.5500 2 watt 462.5750 2 watt 462.6000 2 watt 462.6250 2 watt 462.6500 2 watt 462.6750 2 watt 462.7000 2 watt 462.7250 2 watt 462.5625 2 watt 462.5875...
  • Page 15 Channel Frequency (MHZ) Power 462.6000 2 watt 462.6250 2 watt 462.6500 2 watt 462.6750 2 watt 462.7000 2 watt 462.7250 2 watt 462.5625 2 watt 462.5875 2 watt 462.6125 2 watt 462.6375 2 watt 462.6625 2 watt 462.6875 2 watt 462.7125 2 watt 467.5625...

  • Page 16: Privacy Codes

    PRIVACY CODEs Rocky talkie privacy codes make it so that you can only hear other radios on the same frequency and privacy codes settings. For matching your privacy code to radios from most major radio brands, match both the channel number and privacy code number (also known as subchannel number).
  • Page 17 Rocky Talkie / BCA / Motorola CTCSS Frequency (Hz) 127.3 131.8 136.5 141.3 146.2 151.4 156.7 162.2 167.9 173.8 179.9 186.2 192.8 203.5 210.7 218.1 225.7 233.6 241.8 250.3...
  • Page 18 Rocky Talkie / BCA / Motorola DCS (Octal)
  • Page 19 Rocky Talkie / BCA / Motorola DCS (Octal)
  • Page 20 Rocky Talkie / BCA / Motorola DCS (Octal)

  • Page 21: Fcc Regulation, Fcc Id, Ic Id

    (1) I’areil ne doit pas produire de brouillage, et (2) I’utilisateur de l’appareil doit accepter tout brouillage radioélectrique FCC ID: 2ATSN-ROCKY1 Name of Grantee: LedgeTech LLC Industry Canada: This device complies with license-exempt radio apparatus: Category I equipment, Parts E.2 Family radio service (FRS) devices and E.3 General Mobile Radio Service (GMRS) devices.
  • Page 22 SAR tests are conducted using standard operating positions accepted by the FCC/ISEDC with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is deter- mined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value.
  • Page 23 Le présent areil est conforme aux CNR d’ISEDC licables aux areils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’areil ne doit pas produire de brouillage, et (2) I’utilisateur de l’appareil doit accepter tout brouillage radioélectrique sub. Les tests SAR sont effectués en utilisant des positions de fonctionne- ment standard acceptées par la FCC / ISEDC avec l’appareil émettant à...
