MyTek 3204 Manual page 14

Clean
Each the Cooler is equipped with two honeycomb cooling filters(I).
The honeycomb filters are located in the air inlet grills (H) at the back of the Cooler.
Follow the steps (1) to (3) below to learn how to remove it from the Cooler for cleaning.
Steps to remove / replace the honeycomb filters:
(1) (2) Pull out and remove the side air inlet grill, and then remove the honeycomb cooling filter.
(3) After removing the air inlet grill and honeycomb cooling filter on the left side, remove the air inlet grill on
the right side following steps (1) and (2).
(4) To put the honeycomb cooling filter back into the Cooler, reverse the steps from (3) to (1).
I
H
Depending on the environment, the Honeycomb cooling filters
Note:
should be cleaned at least every two months, or sooner.
14
