- Page 1 System X4 PRO Four Camera Surveillance System For use with the Flashback 4 DVR and Flashback 4G Modem DocRef#0070602 System X4 PRO - User Guide Revised 2017-08-14...
-
Page 2: Table Of Contents
Page 28 Appendix B - List of SMS Commands Page 30 Appendix C - Technical Specifications Page 31 Appendix D - Flashback Specifications Page 32 Appendix E - Contact Page 33 DocRef#0070602 System X4 PRO - User Guide Page 1... -
Page 3: Features
● Texting of Alarm/Trigger ID# and “Name” ● Remote Arming and Disarming ● Remote Assignment of Alarms/Triggers and Cameras/Accessories ● Save/Clear Settings to Memory ● External 5” Monitor for Easy Camera Setup ● Phonebook with Four Contacts DocRef#0070602 System X4 PRO - User Guide Page 2... -
Page 4: Chapter 1 - Hardware
SIM cards. Enclosure: The System X4 PRO is housed in a waterproof enclosure and is IP66 rated. The enclosure lid is secured with four screws underneath two protective covers. The enclosure is ABS to allow use of an optional internal GPS antenna (not included with the System X4 PRO). - Page 5 C) C AMERA/ACCESSORY 3 CONNECTOR D) C AMERA/ACCESSORY 4 CONNECTOR E) P OWER CONNECTOR F) F LASHBACK 4G MODEM ANTENNA CONNECTOR 1 (GOLD) G) F LASHBACK 4G MODEM ANTENNA CONNECTOR 2 (GOLD) H) M ONITOR CONNECTOR I) C ONTROL MODEM ANTENNA CONNECTOR (GOLD) J) S ENSOR ANTENNA CONNECTOR (SILVER) DocRef#0070602 System X4 PRO - User Guide Page 4...
- Page 6 Chapter 1 - Hardware ANTENNAS A) C ELL ANTENNA (x3) B) S ENSOR ANTENNA Antennas: The System X4 PRO includes three and one . The C ELL ANTENNA S ENSOR ANTENNA three connect to the three . The ...
- Page 7 Chapter 1 - Hardware INSIDE A) i -Conex POWER PLUG (MALE) B) i -Conex CAMERAS 2 & 4 PLUG (FEMALE - WHITE) C) i -Conex CAMERAS 1 & 3 PLUG (FEMALE - YELLOW) D) F LASHBACK 4G MODEM SMA PLUG 1 E) F LASHBACK 4G MODEM SMA PLUG 2 F) M ONITOR PLUG DocRef#0070602 System X4 PRO - User Guide Page 6...
- Page 8 Control Modem SIM Card Slot: The is under the cellular modem board. C ONTROL MODEM SIM CARD SLOT WARNING: Be sure the antennas are connected and the SIM card is installed, before connecting power! DocRef#0070602 System X4 PRO - User Guide Page 7...
-
Page 9: Chapter 2 - Sms Commands
This command will return a Settings SMS. (See Page 12 for more information on the Settings SMS.) “SET TRIGGERS : xxxxxxx” Command: This command will arm or disarm the triggers of the System X4 PRO. (See Page 14 for more information on Modes.) This command will return a Settings SMS. DocRef#0070602... - Page 10 DVR Control.) This command will return a O1 SMS. “SET POLLING : ## x” Command: This command will set the polling interval of the System X4 PRO. (See Page 22 for more information on Polling.) This command will return a Settings SMS.
-
Page 11: Chapter 3 - Administrator Number
Administrator Number: After the System X4 PRO is connected to the cell network, the administrator number needs to be programmed. The administrator is the only number that can send SMS commands to the System X4 PRO. - Page 12 The administrator number can be transferred at any time with the same command. The new administrator will then receive a Settings SMS, and the original administrator will no longer be able to send SMS commands to the System X4 PRO, or receive SMS messages from the System X4 PRO.
-
Page 13: Chapter 4 - Settings Sms
This parameter indicates the interval that has been set for the polling. (See Page 22 for more information on Polling.) >SAVE : ON/OFF: This parameter indicates if the System X4 PRO will save all of the entered settings (See Page 26 for more information on Saving). DocRef#0070602... - Page 14 15 for more information on Setup Mode) O R w hen the next scheduled poll is (See Page 22 for more information on Polling) O R i f the System X4 PRO is in the Always On Mode (See Page 23 for more information on Always On Mode).
-
Page 15: Chapter 5 - Modes
When the System X4 PRO is armed, it will process every alarm/trigger it receives. At every alarm/trigger the System X4 PRO will send a “Trigger # Activated” SMS, a “T#>” SMS, and activate any assigned relays. (See Page 16 for more information on Alarms/Triggers.) (See Page 19 for more information on Relays/Cameras.) - Page 16 Chapter 5 - Modes Setup Mode: For fifteen minutes after connecting the battery, the System X4 PRO will be in the Setup Mode, as indicated on the last line of the Settings SMS. The modem will stay on the entire fifteen minutes to receive SMS commands. After fifteen minutes, the System X4 PRO will automatically send a Settings SMS, and the last line will say, “Next poll in ## xxx”.
-
Page 17: Chapter 6 - Alarms/Triggers
Receiving an Alarm/Trigger: When a sensor sends an alarm, the System X4 PRO will receive and process the alarm, and then trigger the corresponding trigger. (Example: An alarm with an ID of 3 will trigger T3.) - Page 18 SET T2 : R4 15 M SET T3 : R1 OFF SET T4 : “DOOR” SET TA : R3 90 M CLEAR T3 CLR T1 (See Page 19 for more information on Relays/Cameras.) DocRef#0070602 System X4 PRO - User Guide Page 17...
- Page 19 ● The trigger name can be 10 characters max, and will always be shown in ALL CAPS. ● The “CLEAR T#” command will set the trigger to activate none of the four relays. A Trigger Activated SMS will still be sent. DocRef#0070602 System X4 PRO - User Guide Page 18...
-
Page 20: Chapter 7 - Relays/Cameras
Powering On a Camera or Accessory: When a relay is activated by either a trigger or SMS command, the camera or accessory will power on. The System X4 PRO provides 12 volts up to 1.7 Amps to each camera or accessory. - Page 21 ● The Relays/Cameras can be set from 1 second to 90 minutes, or “ON” infinitely. ● ANY TIME THAT ANY OF THE RELAYS/CAMERAS ARE ON, THE OUTPUT1 (DVR) WILL BE ON. DocRef#0070602 System X4 PRO - User Guide Page 20...
-
Page 22: Chapter 8 - Dvr Control
Chapter 8 - DVR Control DVR Control The System X4 PRO has the ability to power on the Flashback 4 DVR (and Flashback 4G Modem) independently of the cameras/accessories. “SET O1 : ## x” Command: This command will turn on or turn off the OUTPUT1 (Flashback 4 DVR). The OUTPUT1 will remain on or off until another trigger or SMS command activates it again. -
Page 23: Chapter 9 - Polling
Settings SMS to notify the end of the Setup Mode! When the System X4 PRO modem goes to sleep there is no connection to the cell network. The modem will only connect to the cell network when there is an alarm/trigger or when it reaches the next polling interval. - Page 24 The maximum polling interval is 72 hours. This command will return a Settings SMS. (See Page 12 for more information on the Settings SMS.) Note: ● Increasing the polling interval of the System X4 PRO can dramatically increase the battery life. Always On Mode: The polling can also be set to “ON”...
-
Page 25: Chapter 10 - Contacts
The System X4 PRO can store four additional contacts. WARNING: The contacts will receive a copy of every SMS sent by the System X4 PRO. However, only the administrator can send SMS commands the the System X4 PRO! “SET CONTACT : +#############” Command: This command will add a number to the contacts. - Page 26 To clear all of the saved contacts, send the following SMS command to the System X4 PRO: “ C LEAR CONTACTS ” This command will return a Contacts SMS. Note: ● Clearing the contacts DOES NOT clear the administrator number. DocRef#0070602 System X4 PRO - User Guide Page 25...
-
Page 27: Chapter 11 - Saving
Saving: In the default mode, the System X4 PRO does N OT save any of the settings (including the ADMIN and PHONEBOOK numbers.) The saving feature can be turned on with the “SET SAVE : ON” command, at which time all of the current settings (including the ADMIN and PHONEBOOK numbers) will be saved to memory. - Page 28 This command will clear all of the settings (including the ADMIN and PHONEBOOK numbers) from the memory. After this command is processed, the System X4 PRO will be able to receive a “SET ADMIN : +###########” from A NY phone number.
-
Page 29: Appendix A: Quick Setup Guide
DVR on for 60 minutes. Wait to receive a Relays SMS indicating Relay 4 is on for 59 more minutes. Notes: ● ANY TIME ANY OF THE RELAYS/CAMERAS ARE ON, THE DVR WILL BE ON. DocRef#0070602 System X4 PRO - User Guide Page 28... - Page 30 Wait 90 seconds for the Flashback Modem to connect to the network. Now navigate to the static IP address of the SIM card. Note: ● The default username and password is “admin” and “admin”. DocRef#0070602 System X4 PRO - User Guide Page 29...
-
Page 31: Appendix B - List Of Sms Commands
● SET POLLING : ## x ● SET T# : xxxxxxx ● CLEAR T# ● SET R# : xxxxxxx ● CLEAR R# ● SET O1 : xx # ● SET SAVE : xxxxxxx DocRef#0070602 System X4 PRO - User Guide Page 30... -
Page 32: Appendix C - Technical Specifications
4 Pin Military MALE (x4), 3 Pin Military MALE (x1), Connectors 4 Pin Military FEMALE (x1), SMA (x4) Dimensions 9.45” x 7.00” x 2.35” (24.0 x 17.8 x 6.0 cm) Weight 2.35 lbs (1.07 kg) DocRef#0070602 System X4 PRO - User Guide Page 31... -
Page 33: Appendix D - Flashback Specifications
5 - 12V DC Current Video 4x Standard Definition Storage 1 TB Flashback 4G Modem Specifications: Power 5 - 12V DC Current Frequencies GSM, HSPA+, LTE SIM Card mini-SIM (2FF) (Standard SIM) DocRef#0070602 System X4 PRO - User Guide Page 32... -
Page 34: Appendix E: Contact
Appendix E - Contact Appendix E: Contact Contact: IntelliCam LLC 11138 Air Park Road, Suite H Ashland, VA 23005 (+1) 804-798-1004 www.intellicam-llc.com DocRef#0070602 System X4 PRO - User Guide Page 33... - Page 35 DocRef#0070602 System X4 PRO - User Guide Page 34...
