DOM DBS-10 Manual

SPECIFICATIONS

Model no
Free speed
Belt size
Overall Length
Weight
Air inlet
Air Hose ( ID )
Air consumption
Air pressure

AIR SUPPLY

WARNING! Ensure the air supply is clean and does not exceed 90 psi while operating the Tool.
Too high an air pressure and unclean air will shorten the product life due to excessive wear and
may be dangerous causing damage and/or personal injury.
1. Ensure tool air trigger/lever is in "off" position before connecting to the air supply.
2. You will require an air pressure of 90 psi and an air flow according to specification.
3. Drain the compressor air tank daily. Water in the air line will damage the tool.
4. Clean the compressor air inlet filter weekly.
5. Line pressure should be increased to compensate for unusually long air hoses (over 8 mts).
The minimum hose diameter should be 1/4" I.D and fittings must have the same inside
dimensions.
6. Keep hose away from heat, oil and sharp edges. Check hose for wear and make certain that all
connections are secure.
AIR BELT SANDER DBS-10
DBS - 10
16,000 rpm
10 x 330mm
260 mm
0.9 kg
1/4"bsp (or) npt
3/8"
4 cfm
90 psi
