PHT tanks CCI
This guide provides information regarding the installation, operation, maintenance and warranty of the
PHT tanks from Premier Tech Aqua. For additional information, contact our customer service at 1 800
632-6356.
Table of content
1.
Technical Data ........................................................................................................................... 1
2.
Components Of The Holding Tank ................................................................................................. 2
3.
Installation Procedure ................................................................................................................. 2
1. Technical Data
The holding tanks are made of medium density polyethylene (MPDE).
Models
Nominal total capacity
Liquid capacity
Total length (A)
Total width (B)
Total height (C)
Inlet height (D)
Outlet height (E)
Opening diameter (F)
Approximate weight **
* Pipe invert.
** Weights indicated are approximate and not binding (for handling and lifting purposes only).
Note: The characteristics can be modified at any time
Premier Tech Aqua
Table 1 - Characteristics of PHT tanks
PHT-390
3,9 m³ / 3 900 L
1 030 gal. US
3 320 mm
130 ½"
1 250 mm
49 ¼"
1 330 mm
3
52
/
"
8
470 mm
18 ½"
210 kg
463 lb
.
Figure 1 - PHT tank
1/4
Depend of the tank function
Installation guide – PHT tanks CCI
Installation guide
PHT-660
6,65 m³ / 6 650 L
1 760 gal. US
3 965 mm
156"
1 330 mm
3
52
/
"
8
1 720 mm
67 ¾"
470 mm
18 ½"
350 kg
772 lb
Edition: 2019-01-09
Advertisement
Table of Contents
Related Manuals for Premier Tech Aqua PHT-390
Summary of Contents for Premier Tech Aqua PHT-390
- Page 1 PHT tanks CCI Installation guide This guide provides information regarding the installation, operation, maintenance and warranty of the PHT tanks from Premier Tech Aqua. For additional information, contact our customer service at 1 800 632-6356. Table of content Technical Data ........................... 1 Components of the holding tank ....................
- Page 2 Minimum 15 cm (6") in loose soil or Minimum 30 cm (12") in bedrock. Note regarding the bedding: Use 0-20 mm (0-¾") Ø gravel or sand well compacted and levelled. Premier Tech Aqua Installation guide – PHT tanks CCI Edition: 2019-01-09...
- Page 3 MBBR, pumping station and equalization tanks must be ventilated using a pipe that is at least 100 mm (4") in diameter or that is connected to the dwelling’s ventilation pipe. Premier Tech Aqua Installation guide – PHT tanks CCI Edition: 2019-01-09...
- Page 4 If you have any question or comments, do not hesitate to contact Premier Tech Aqua at 1 800 632-6356. The information contained in this document is based upon the latest information available at the time of publication and is designed to provide you with a general introduction to our products.
