- Page 1 INSTALLATION AND OPERATION USER MANUAL WWW.UNICORECOMM.COM UB4B0M GPS/BDS/GLONASS/Galileo All-constellation All-frequency Compact High Precision Board Copyright© 2009-2021, Unicore Communications, Inc. Data subject to change without notice.
- Page 2 Before placing an order, please contact our company or local distributors for the latest specifications. * Unicore Communications, Unicorecomm, NebulasII and its logo have been applied for trademark registration by Unicore Communications, Inc. Other names and brands are the property of their respective owners.
- Page 3 © Copyright 2009-2021 Unicore Communications, Inc. All rights reserved. Foreword The User Manual offers you information in hardware features, installation and use, and performance indicators of UNICORECOMM UB4B0M. Note: This manual is a generic version. Please refer to the corresponding chapter of the manual according to the configuration of the purchased product for more information concerning the usage requirement of CORS, RTK and Heading.
-
Page 4: Table Of Contents
CONTENTS OVERVIEW ......... 1 ........................2 EATURES ........................2 ECHNICAL NDEX ........................3 OARD VERVIEW HARDWARE COMPOSITION ......4 ......................4 ECHANICAL IMENSION ....................5 NTERFACE AND UNCTION .......................... 6 UNCTION ....................6 LECTRICAL PECIFICATION ..................... 7 PERATIONAL ONDITIONS ....................7 HYSICAL HARACTERISTIC HARDWARE INTEGRATION GUIDE .... -
Page 5: Overview
1. Overview UB4B0M is a new generation compact RTK board based on NebulasII high performance and high accuracy GNSS SoC. It supports signals including BDS B1I/B2I/B3I/B1C/B2a, GPS L1/L2/L5, GLONASS L1/L2 and Galileo E1/E5a/E5b. UB4B0M is characterized by its classic small size, supports chip-level multi-path mitigation, and delivers millimeter-level carrier phase observations and centimeter-level RTK positioning. -
Page 6: Key Features
UB4B0M User Manual 1.1 Key Features Supporting BDS B1I/B2I/B3I/B1C/B2a, GPS L1/L2/L5, GLONASS L1/L2, Galileo E1/E5a/E5b, etc. Millimeter-level carrier-phase observation data Centimeter-level high-precision RTK positioning Hardware size compatible with the mainstream GNSS OEM boards on the market ... -
Page 7: Board Overview
NebulasII (UC4C0) digital processing requires. NebulasII SoC (UC4C0) The UB4B0M incorporates the processing from the NebulasII SoC, UNICORECOMM’s new generation high precision GNSS SoC with 55 nm low power design, which supports 432 channels and is equipped with a built-in UNICORECOMM’s new generation baseband engine. -
Page 8: Hardware Composition
UB4B0M User Manual 1PPS UB4B0M provides 1 PPS signal with adjustable pulse width and polarity. Event UB4B0M provides 1 Event Mark Input signal with adjustable pulse width and polarity. 2. Hardware Composition 2.1 Mechanical Dimension Table 2-1 Mechanical Dimension Parameter... -
Page 9: Interface And Pin Function
Figure 2-1 Mechanical Structure Drawing 2.2 Interface and Pin Function Apart from the antenna RF interface, UB4B0M provides the following 20 Pin SAMTEC dual-row pin. The pin distance: 2.0 mm; pin length: 4.0 mm; base thickness: 1.5 mm. Figure 2-2 Pinout... -
Page 10: Pin Function
UB4B0M User Manual 2.3 Pin Function Table 2-2 Pin Definition Signal Type Description Note Reserved Reserved 3.3V Power input 3.3 V~5 V（+5%/-3%） Reserved Reserved Reserved RXD3 COM3 Receive data LVTTL Level Low level effective, RESETIN Reset-input duration >5 ms Reserved... -
Page 11: Operational Conditions
Shock GJB150.18-2009, MIL-STD-810 3. Hardware Integration Guide 3.1 Design Notes For the normal operation of UB4B0M, the following signals need to be connected correctly: The module VCC power-on behavior is repeatable, the initial level is lower than 0.4V, and the undershoot and ringing should be guaranteed to be within 5% VCC... - Page 12 UART interface ensures that the signal and baud rate of the main device are consistent with those of UB4B0M. Antenna wires should be as short and smooth as possible; avoid sharp angle and pay attention to impedance matching.
-
Page 13: Notes For Pin
3.3 Antenna Antenna input MCX interface of UB4B0M provides an antenna feed of 4.6±0.2 V. Do not connect the antenna to the port of antenna in the module, and use a multimeter to test, that is, the voltage supply is DC4.8 V ~ 5.4 V when there is no-load. When the RF port of the module is connected to the antenna, the working current is 30~100 mA at normal temperature, and the antenna feed of DC4.6 V±0.2 V can be supplied to the outside. -
Page 14: Connection And Setting
4.2 Installation Guide UB4B0M is delivered in the form of board, allowing users to assemble it flexibly according to application scenarios and market needs. The following figure shows a typical UB4B0M installation method using a set of evaluation kit (EVK). Users can also, in the same way,... - Page 15 Desktop or laptop (Win7 and above) with serial ports, installed relevant serial driver and UPrecise software Step 1. For the UB4B0M EVK users, align UB4B0M positioning holes and pins with EVK. Note: If the EVK connector hole is 24-pin, connect the middle 24 pins of the board to the connector).
- Page 16 UB4B0M User Manual Figure. 4-2 UB4B0M Connecting to Antenna RF Wires Note: The RF connector on the board is MMCX. Please select the appropriate cable according to the packaging. The input signal gain of the antenna connector should be within 25 to 36dB. Plug and unplug the MCX RF head vertically and the time of this operation is limited.
-
Page 17: Power On
Step 6. Operate the receiver via UPRECISE and record the relevant data. 4.3 Power on The supply voltage of UB4B0M is 3.3 V, and the supply terminal voltage of EVK is 12 V. After powered on, the receiver starts up and can quickly establish communication. - Page 18 Step 1. Follow 4.2 Installation Guide to connect the power source, antenna to the board, and turn on the EVK switch Step 2. Click file - > connect the serial port, and set the baud rate; the default baud rate of UB4B0M is 115200bps Figure. 4-5 Connect the Serial Port...
-
Page 19: Led Indicators
Step 3. Click the receiver settings button to configure the NMEA message output. It is recommended to configure GPGGA, GPGSV, and other messages. Figure. 4-6 NMEA Data Output Step 4. Click the receiver settings button, configure the NMEA message output, and click send. -
Page 20: Common Commands Setup
(if the parameter part is empty, the command has only one header), and the header field contains the command name or message header. UB4B0M is simple and easy to use, and the common commands are shown in the following table:... -
Page 21: Base Station Setting
Command Description rtcm1033 comx 10 The base station mode is set as COMX, ICOMX, NCOMX to rtcm1006 comx 10 send a differential message. COMX can be appointed as rtcm1074 comx 1 anyone in COM1, COM2, and COM3; rtcm1124 comx 1 rtcm1084 comx 1 rtcm1094 comx 1 NMEA0183 Output Statement... -
Page 22: Rover Station Setting
UB4B0M User Manual Command Specification saveconfig Save settings Self-optimizing setting base station refers that there is no precise coordinate at the point where the base station is set up. The receiver can be set to self-position within a certain period at the installation point to get the average value, which can be set as the coordinates of the base station. -
Page 23: Firmware Update
The firmware of UB4B0M is updated using UPrecise software. In the UPrecise interface, click as follows: “Advanced” -> “Firmware Update”. Figure 7-1 Update Interface Click “Select Path”, select the file location of UB4B0M PKG and then click “START” (Ignore the software reset option). - Page 24 UB4B0M User Manual Figure 7-2 Update Steps Wait for the progress bar to complete 100%, and the upgrade time will be counted (usually less than 5 minutes). Figure 7-3 Update Steps When using a serial port to upgrade, please use serial port 1 of the board.
-
Page 25: Packaging
8. Packaging UB4B0M boards are packed in cartons; 100 UB4B0M boards per carton. Table 8-1 Packaging Project Description 10 boxes per carton 10 anti-static packages per box 1 UB4B0M per package... - Page 26 和芯星通科技（北京）有限公司 Unicore Communications, Inc. 北京市海淀区丰贤东路7号北斗星通大厦三层 F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China, 100094 www.unicorecomm.com Phone: 86-10-69939800 Fax: 86-10-69939888 info@unicorecomm.com www.unicorecomm.com...
