Summary of Contents for Lippert Components Lippert Insight
- Page 1 Lippert Insight™ back-up camera OWNER'S MANUAL...
-
Page 2: Table Of Contents
Camera reset Introduction The Lippert Insight™ Back-up Camera is a 12V camera that streams wireless video to a mobile device using the OneControl application showing the rear view of the trailer. Images used in this document are for reference only when assembling, installing and/or operating this product. -
Page 3: Camera Setup
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury if not performed safely and within the parameters set forth in this manual. The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury and/or product or property damage if not safely adhered to and within the parameters set forth in this manual. - Page 4 Read through and accept the License Agreement by tapping I Accept>> (Fig.3A). Login to access the camera by tapping Login>> (Fig. 4A). If you have an existing community account, fill in your email and password for that account and tap Login (Fig. 5A). Or continue with Facebook, Google, Apple ID, or Create Your Account (Fig.
- Page 5 Choose Scan with Camera (Fig7A). Tap Grant Location Permissions (Fig. 8A) and grant location permissions to the app. Tap Grant Camera Permissions (Fig. 8B) and grant camera permissions to the app. Scan the gateway label (Fig 9). This label is found on the bottom of the camera (Fig. 10A) and also on a sticker placed in the unit by the OEM.
- Page 6 The ID field will auto populate with the camera's SSID number (Fig. 11A) and the Password field (Fig. 11B) will be blank. No password is needed at this time. Tap Connect>> (Fig. 11C). Note: Be sure that the mobile device's Wi-fi is turned on. If Wi-Fi is not on, the app will prompt you to turn it on.
- Page 7 12. Confirm the details entered by tapping Confirm>> (Fig. 15A). 13. Set up a 4-digit security pin for the OneControl app (Fig. 16A). Note: You can skip the Pin Setup by tapping Skip>> (Fig. 16B ). 14. OneControl app setup is now complete, tap Continue to App>> (Fig. 17A). 15.
-
Page 8: Operation
Operation When in full view (Fig. 20), you can use your thumb and index finger to "pinch zoom" the main viewing area of the camera. While zoomed in, a small full view window will appear in the lower right corner of the screen (Fig. 21A). Use your index finger to move around the main zoomed in view. -
Page 9: Camera Reset
What is happening? What is happening? Why? Why? What should be done? What should be done? Turn battery disconnect on. Connect to shore power. Camera not powered up. Connect 7-way to tow vehicle. Mobile device does not Make sure Wi-Fi is active on mobile device. Wi-Fi not turned on. - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. Lippert prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. ...
