LitoLite 5C
USER MANUAL
Guangdong NanGuang Photo&Video Systems Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LitoLite 5C and is the answer not in the manual?

Questions and answers

Summary of Contents for NANLITE LitoLite 5C

  • Page 1 LitoLite 5C USER MANUAL Guangdong NanGuang Photo&Video Systems Co., Ltd...

  • Page 2: Product Diagram

    LitoLite 5C RGBWW LED Pocket Light Product Diagram Technical Data LED Total Power: 5W x 2+4W x 3 Lithium Battery: 3.7V/2400mAh, 8.88Wh Rated Power: 7W Color Temperature: 2700K-7500K + G/M Adjustment Input Voltage/Current: DC5V/2A CRI: Average 95 TLCI: Average 97...

  • Page 3: Product Details

    Product Details 5. Display 1. Reset 6.“ ”“ ” 2. USB Type C port 7. Switch 3. Power 8. Mode 4. 1/4-20 mount Detail Description 1. Reset: To reset the fixture in the event it ever freezes up or stalls. 2.
  • Page 4 Usage 1. Powering the unit. ① Connecting the fixture with a USB cable, then connect with a USB adapter or powerbank (recommended 5V/2A or above - not included). Connecting with USB adapter. Connecting with power bank. ② Built-in battery automatically powers unit once charged and unplugged from a power source.
  • Page 5 2. Installation ① Attach the diffuser to the fixture. (See #1) ② Horizontal option. (See #2) ③ Handheld option. (See #3) ④ There are built-in magnets in both ends, allows you to simply attach the fixture on irony surface. Built-in magnet Built-in magnet Attach the fixture on irony surface...

  • Page 6: How To Operate

    Waterproof bag is an optional accessory, fixture must be setup before placed in bag or controlled via remote options. 3. Bluetooth Remote Control The LitoLite 5C has built-in bluetooth connection function. How to Operate 1. Long press 'power' button to turn on, 'NANLITE' logo will be displayed on start up.
  • Page 7 2. "Mode" button: Press to switch between modes - CCT, HSI, Effects and Menu. Battery indicator Time remaining 6.0h DIM: 100% EFFECT CCT: 5600K G/M:0 MENU ① In CCT Mode: press “Switch” button to select from DIM, CCT and G/M, press" "...
  • Page 8 In Effect mode, pres " " " " to select special effect that needed, LitoLite 5C has built-in effects including Hue Loop, CCT Loop, INT Loop, CCT Flash, HUE Flash, CCT Pulse, Hue Pulse, Storm, Police Car, TV, Paparazzi, Candle/Fire, Disco, Bad Bulb, Firework, Explosion and Welding.
  • Page 9 (1) HUE LOOP Press "Switch" button to select from DIM, HUE 1, HUE 2 and Speed(SPD), press " " and " " to adjust the value of DIM, HUE 1, HUE 2, and Speed(SPD). Speed range: 02S...30S. EFFECT 6.0h EFFECT 6.0h HUE LOOP HUE1:...
  • Page 10 EFFECT EFFECT 6.0h 02S . 6.0h CCT: 2700K-7500K CCT: 2700K-7500K SPD: SPD: Press " " " " to choose needed value. (3) INT LOOP Press "Switch" button to select from DIM 1, DIM 2, speed(SPD) and color(CLR), press " " and " "...
  • Page 11 (4) CCT FLASH Press "Switch" button to select from DIM, CCT, G/M and INTVL, press " " and " " to adjust the value of DIM, CCT, G/M, INTVL. INTVL range: 0.1S..10.0S. EFFECT 6.0h EFFECT 6.0h CCT FLASH CCT: 5600K G/M:0 DIM: 100% INTVL: 1.0S Press "Switch"...
  • Page 12 EFFECT 6.0h EFFECT 6.0h 0.1S HUE: 000 SAT: 100 HUE: 000 SAT: 100 INTVL: 1.0S INTVL: 1.1S 10.0S Press " " " " to choose needed value. (6) CCT PULSE Press "Switch" button to select from DIM, CCT, G/M, PULSES/M(minute), press " "...
  • Page 13 (7) HUE PULSE Press "Switch" button to select from DIM, HUE, SAT, PULSES/M(minute), press " " and " " to adjust the value of DIM, HUE, SAT,PULSES/M(minute). PULSES/M(minute) range: 001...240. EFFECT 6.0h EFFECT 6.0h HUE: 000 SAT: 100 HUE PULSE DIM: 100% PULSES/M: Press "Switch"...
  • Page 14 EFFECT EFFECT 6.0h 01S . 6.0h 特效 6.0h 特效 6.0h CCT: 5600K CCT: 5600K INTVL: 02S-06S INTVL: 03S-06S Press " " " " to choose needed value. (9) POLICE CAR Press "Switch" button to select from DIM, COLOR and Speed(SPD), press " "...
  • Page 15 (10) TV Press "Switch" button to select from DIM 1, DIM 2, CCT, G/M and Speed (SPD), press " " and " " to adjust the value of DIM 1, DIM 2, CCT, G/M and Speed (SPD). Speed range: 001...100. EFFECT 6.0h EFFECT...
  • Page 16 (13) DISCO EFFECT 6.0h EFFECT 6.0h 001 . 特效 6.0h 特效 6.0h Press "Switch" button to select from DIM, Color and Speed (SPD), press " " and " " to adjust the value of CCT: 5600K G/M: 0 CCT: 5600K G/M: 0 DIM, Color and Speed (SPD).
  • Page 17 EFFECT 6.0h EFFECT 6.0h 001 . 特效 CCT: 5600K G/M: 0 CCT: 5600K G/M: 0 SPD: SPD: Press " " " " to choose needed value. (15) FIREWORK Press "Switch" button to select from DIM, Color, Speed (SPD) and Decay, press " "...
  • Page 18 (16) EXPLOSION Press "Switch" button to select from DIM, CCT, G/M, Speed (SPD) and Decay, press " " and " " to adjust the value of DIM, CCT, G/M, Speed (SPD) and Decay. Speed range: 001 …100. Decay range: 001 …100. EFFECT 6.0h EFFECT...
  • Page 19 " and " " to set the language (Chinese and English). ·Lighting effects and additional functionality maybe added with future firmware releases, for details of these please see www.nanlite.com. 3. Long press the "Power" button to turn off the light.

  • Page 20: Safety Precautions

    Safety Precautions 1. Please open the package to check for damage caused in transit, if damaged please do not use and contact place of purchase or manufacturer as soon as possible. 2. Do not use if power cord is damged or unplug with excessive force. 3.

  • Page 21: What's In The Box

    If the failure is not resolved after troubleshooting, please contact place of purchase. This manual and all stats within it were produced under controlled conditions, and are accurate at time of print. Any future changes to design/technical data can be found at www.nanlite.com.
  • Page 22 Version:V2 2020-09-03 +86-754-85751187 +86-754-85300887 service@nanlite.com Zhanglin,324,Dongli Chenghai Shantou Guangdong China www.nanlite.com...
