User manual
X-PRO 50 & X-PRO 100
Réf. 40070 / 40080
EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510
Edition of 23/12/2021
More information on www.euromair.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EUROPRO X-PRO 50 and is the answer not in the manual?

Questions and answers

Related Manuals for Euromair EUROPRO X-PRO 50

Summary of Contents for Euromair EUROPRO X-PRO 50

  • Page 1 EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 Edition of 23/12/2021 More information on www.euromair.com...

  • Page 2: Table Of Contents

    13790 ROUSSET 4. USE OF THE MACHINE ..........p.10 Tél : +33 (0)4 42 29 08 96 4.1. Prerequisites ............p.10 contact@euromair.com 4.2. Starting up for spraying ..........p.11 4.3. Starting up for floor-screed ........p.11 5. DEFECTS AND REMEDIES ..........p.12 6. MAINTENANCE ............. p.13 6.1.

  • Page 3: User Manual

    1. USER MANUAL 1.1. IMPORTANCE OF THE MANUAL This manual is a key part for the use of your machine. It summarizes the procedures of starting-up, cleaning and maintenance of the device and also the safety instructions you need to observe. Read carefully all the working and safety instructions and the warnings included in this manual before starting your machine.

  • Page 4: Warning

    2. WARNING 2.1. SAFETY Using the machine in an incorrect way or in non-compliance of the safety instructions indicated in this manual can cause death or serious injuries. Read carefully all the working and safety instructions and the warnings contained in this manual before starting your machine.
  • Page 5 2. WARNING (continued) 2.1. SAFETY (continued) WORKSPACE • Maintain the workspace clean and clear. • Ambient operating temperature must be from 5°C and 35°C. • Do not use the equipment in a potentially explosive area. • Do not place any potentially inflammable objects in close proximity to the machine. •...

  • Page 6: Electric Connection

    Antony (92) or Rousset sur Arc (13). Upon receipt, the products are sorted by our employees and directed to the most appropriate processing channels. For any further information, please contact our hotline +33 4 42 29 08 96 or conseil@euromair.com. User manual - X-PRO 50 & X-PRO 100...

  • Page 7: Your Machine

    3. YOUR MACHINE 3.1. DESCRIPTION Versatile spraying machines, equipped with a steel tank and a button control panel. X-Pro 50 is also equipped with a mono-cylinder compressor. APPLICATIONS X-Pro 50: mortars, E.W.I., hydraulic coatings. X-Pro 100: liquid floor-screed, shotcrete (with projection option). Do not use corrosive products, acid products, powder products or products with a too large grain size.

  • Page 8: Identification Of The Components X-Pro

    3. YOUR MACHINE (continued) 3.3. IDENTIFICATION OF THE COMPONENTS X-PRO 50 Product outlet Air outlet Pressure manometer Compressor Rotor / stator pump Start / Stop of the machine Drain plug Manual / Auto / Reverse mode Lifting rings Potentiometer Lubricator Start / Stop of the compressor Power socket Emergency stop...

  • Page 9: Identification Of The Components X-Pro 100

    3. YOUR MACHINE (continued) 3.4. IDENTIFICATION OF THE COMPONENTS X-PRO 100 Product outlet Start / Stop of the machine Pressure manometer Manual / Auto / Reverse mode Rotor / stator pump Potentiometer Drain plug Start / Stop of the strainer Lifting rings Emergency stop Lubricator...

  • Page 10: Use Of The Machine

    4. USE OF THE MACHINE 4.1. PREREQUISITES • The electric connection has to be 400 V - 32 A - 50 or 60 Hz with a 4 x 4 mm² cable reel of 40m maximum, completely unreeled. • Place the (L) button onto MANU position makes the pump start working. •...

  • Page 11: Starting Up For Spraying

    4. USE OF THE MACHINE (continued) 4.2. STARTING UP FOR SPRAYING Install the machine on a flat floor and connect it electrically (32 A minimum plug, extension cable 40m maximum in 4 x 4 mm² minimum). Connect the hose to the product outlet (A) and mount the lance, opened, without the nozzle. Switch the machine on (button (K)).

  • Page 12: Defects And Remedies

    5. DEFECTS AND REMEDIES Defect Remedy • Check that the product is not too dry and that it sinks to the bottom of the tank, dilute it and • The machine runs but the product does not mix it well if necessary. come out at the lance.

  • Page 13: Maintenance

    6. MAINTENANCE 6.1. CLEANING PROCEDURE Disconnect the machine from the power supply before any intervention. Before unscrewing the hose, make sure it is not under pressure anymore. Empty the tank to the maximum without adding water inside. Open the lance to relieve pressure from the product hose and hold (L) button onto ARR/REV position for 10 to 20 seconds.
  • Page 14 User manual - X-PRO 50 & X-PRO 100 202102-507A-ENG...

  • Page 15: Declaration Of Conformity

    7. DECLARATION OF CONFORMITY THE MANUFACTURER : EUROPE PROJECTION 228, avenue Olivier Perroy 13790 ROUSSET DECLARES THAT THE EQUIPMENT DESIGNATED BELOW: Trademark : EUROPE PROJECTION Type : Spraying machine Model : X-PRO 50 / X-PRO 100 COMPLIES WITH THE DIRECTIVES: •...

  • Page 16: Warranty Conditions

    24 months from the date of purchase by the client. The final user can extend this manufacturer’s warranty for a further 12 months by filling in the warranty extension form on our website www.euromair.com (under After-Sale Service) within 4 weeks of purchase.
  • Page 17 Request for Warranty For any request related to the repair of an equipment covered by the manufacturer’s warranty, the customer shall have to fill the warranty form, available on our website to the following address: https://www.euromair. com/en/after-sales-service/ For a full dossier, the following documents shall have to be attached: •...
  • Page 18 User manual - X-PRO 50 & X-PRO 100 202102-507A-ENG...
  • Page 19 202102-507A-ENG User manual - X-PRO 50 & X-PRO 100...
  • Page 20 EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : +33 (0)4 42 29 08 96 – Fax : +33 (0)4 42 53 44 36 SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510 More information on www.euromair.com User manual - X-PRO 50 & X-PRO 100...
