TIS RLY-8CH-16A Installation Manual

INSTALLATION MANUAL
RELAY 8 CHANNELS 16 AMPS
Model: RLY-8CH-16A
Output switching voltage
Output switching current
TIS Bus
Operating and display
elements
Functions
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79817 1
This device is used to control ON/OFF for lights
and other devices, electrical locks, 3
motors, shutters, and floor heaters.
P R O D U C T S P E C I F I C AT I O N S
Number of channels
Nominal voltage
Max. switching Voltage:
Nominal current per channel
Maximum total channel load
Max switching current
Max continuous current
Number of devices on 1 line
Bus voltage
Current consumption (Normal)
Current consumption (operation)
Protection
Programming button/LED (PRG)
1-8 buttons
Mechanical Switch
Lighting control ON/OFF
Curtain motor control
Scenes
Sequences
Width × Length × Height
Materials
Casing color
Button color
IP rating
Automation Made Easy
PRODUCT INFORMATION
8
0 – 230 V AC 50/60 Hz
440VAC
16 A
128 A
50A Resistive
20A Florescent
20A VAC
Max. 64
12-32 V DC
<12 mA / 24 V DC
<35 mA / 24 V DC
Reverse Polarity Protection
For assignment of the physical address
Manual ON/OFF and Programming
Relay emergency operator
8 channels controlled separately
Can set 4 group of curtains (open/close) option
8 different scenarios
8 different sequences
145mm × 75mm × 91mm
ABS fire proof
Black Gray
Silver
IP 20
-party curtain
rd
