tradetec TLEEC360 Instructions

Martec Pty Ltd
6 Austool Pl | Ingleburn, NSW 2565
P: 02 8778 7500
F: 02 8778 7555
E: customerservice@martecltd.com.au
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION.
Tradetec Ceiling LED Emergency Exit Light - Model: TLEEC360
Remove the product from the box and inspect it for any damage. If you believe the product to be damaged or otherwise unsound, DO NOT install the product.
Please pack it back into its box and return it to the place of purchase for replacement. If the product is satisfactory, proceed with the installation.

INSTALLATION AND MOUNTING

Remove the cover using a flat blade screwdriver, release the clip by pushing in and down. The top cover can then be removed by sliding it away from the
screwdriver. The cover MUST BE mounted prior to attaching to the body.
Mount cover and connect wiring to terminals. Assemble the product by sliding the body into place.
Warranty
Voltage (V)
Frequency (Hz)
Max Ambient Temp
Class
Duration
IP Rating
Emergency Classification
Average Power Consumption
Mounting Type
Wiring
Viewing Distance
Battery Type
Battery Voltage
Charging Time
Charger Type
Max Power Consumption
Ver 1. 07.08.2017
PLEASE RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Cover
Body
12 month replacement
220-240V
50Hz
40⁰C
2
90 / 120 min
IP20
C0=E2.5 C90: E2.0 (3Hr)
2.2W (maintained)
Rod / surface / suspended or wall mounted
Terminal Block
24M
Li-ion
3.7V
16 hours
Variable
3.5W (maintained)
Battery
B
A
Page 1.
