- Page 1 / xDAQ-600(P) A Piezo Vibration Analysis and Diagnosis Unit Operation Manual V1.1 Copyright © 2020, All Rights Reserved. Ver: D01 D/C: 109-0414...
-
Page 2: Table Of Contents
/ xDAQ-600 (P) Operation Manual 目錄 Start Up ............................... 3 1. Device Info ............................ 4 1.1 Status Overview ....................... 4 1.2 DHCP Client List ....................... 4 1.3 System Log ........................5 1.4 Change Setting Log ......................5 1.5 Device Alarm History ...................... 6 2. -
Page 3: Start Up
/ xDAQ-600 (P) Operation Manual Start Up Users use the browser (default IP: 192.168.168.10, account: admin, password: IP585xAdmin), and the homepage provides links to AG300 related functions. System login screen: After successful login, the system will list the current status information, the page is as follows: Users can set the project into four major items: "Device info", "Settings", "wireless",... -
Page 4: Device Info
/ xDAQ-600 (P) Operation Manual 1. Device Info The device information includes five items: "Status Overview", "DHCP Client List", "System Log", "Change Setting Log", and "Device Alarm History". 1.1 Status Overview Users can use this project to obtain basic system information and network settings. -
Page 5: System Log
/ xDAQ-600 (P) Operation Manual 1.3 System Log Users can use this project to obtain system log data. 1.4 Change Setting Log The operation history is listed in the List directory. It can be exported via the "Export" button. -
Page 6: Device Alarm History
/ xDAQ-600 (P) Operation Manual 1.5 Device Alarm History Users can use this project to view the alarm records of all devices. Page 6... -
Page 7: Settings
/ xDAQ-600 (P) Operation Manual 2. Settings Usage settings include "LAN", "WAN", "Unit Paring", "RS485", "Maintenance info" sub- items. 2.1 LAN Users can use this project to set LAN settings, the page is shown as below: 2.2 WAN Users can use this project to set up the WAN. The page is as shown below: "Remote Access"... -
Page 8: Unit Pairing
/ xDAQ-600 (P) Operation Manual 2.3 Unit Pairing Users can register through the webpage, as shown below : Page 8... - Page 9 / xDAQ-600 (P) Operation Manual 1. Press the "Add" button to automatically create a new terminal device. 2. Check the newly generated terminal device, and press the "Edit" key to enter the editing screen, you can edit the various information of the terminal device.
- Page 10 / xDAQ-600 (P) Operation Manual 3. After editing the information, press the "Save" button, and then press the "Start Pairing" button to enter the device registration program. After successful registration, the status will show "Connected". Page 10...
-
Page 11: Rs485
/ xDAQ-600 (P) Operation Manual 2.4 RS485 Users can use this project to add equipment, set and view equipment parameters, and configure the “Alarm Trigger Time” of the alarm and the “Start Address” of the equipment. 1>. Add Motor：... - Page 12 / xDAQ-600 (P) Operation Manual Some parameters are explained as follows: Name: fill in as required Work ID : Motor factory ID Drive Mode : direct drive and inverter drive Control point : Configure DO FAE Information : Contact Information for Equipment Maintenance Personnel Engineer Information : Factory Technician Contact 2.
- Page 13 / xDAQ-600 (P) Operation Manual Some parameters are explained as follows: Line : Choose to use the first set of lines (1) or the second set of lines (2) Name : can be filled as required Vibration Name : fill in as required Velocity RMS Up Limit : When the vibration reaches this set value, an alarm will be issued.
- Page 14 / xDAQ-600 (P) Operation Manual Up Limit : When this set value is reached, an alarm will be issued. Please fill in (mm / s²) according to the specifications. Up Early Warning : When the set value is reached, a warning notification is issued.
- Page 15 / xDAQ-600 (P) Operation Manual 4. XDAQ600 (P) additionally contains PMS related setting parameters, as shown below： Page 15...
- Page 16 / xDAQ-600 (P) Operation Manual PMS parameters are described as follows : Field Description Sample Rate Keep it the same as DAQ setting Sample Number Keep it the same as DAQ setting Fa (Spinning) in RPM Motor spinning speed in RPM Threshold There are 17 known defects.
- Page 17 Ignore frequency lower than low frequency High frequency Ignore frequency higher than high frequency Note : The PMS parameters are supported for xDAQ-600 (P) only. 2>. Add the switchgear : 1. Select the "Add" button in the switchgear, enter the parameter configuration, and click "Save"...
- Page 18 / xDAQ-600 (P) Operation Manual 2. After adding other devices, you can add IEPE below. Page 18...
-
Page 19: Maintenance Info
/ xDAQ-600 (P) Operation Manual 2.5 Maintenance Info Users can use this project to add contact information of equipment maintenance personnel and factory technicians. 1. Click "Add", enter name and phone number, save and add a contact. Page 19... - Page 20 / xDAQ-600 (P) Operation Manual 2. After checking the contact list, click the "Edit" or "Delete" button to edit or delete a record. 3. Contacts can be selected on the device's settings page : Page 20...
-
Page 21: Wireless
XDAQ-600 webpage through WiFi to configure the XDAQ-600. When the XDAQ-600 is in the wireless client mode, the XDAQ-600 itself can be used as a wireless client to connect to other wireless access points (including the 4G wireless router inserted on the XDAQ-600). -
Page 22: Basic Wireless Settings
/ xDAQ-600 (P) Operation Manual 3.2 Basic Wireless Settings 3.2.1 Basic Settings This item allows users to set the most basic settings for wireless communication in wireless hotspot mode, such as network name, network mode, etc. WIFI is enabled by default. - Page 23 / xDAQ-600 (P) Operation Manual 3.2.3 Security Settings Users can use this item to set up wireless security and encryption in wireless hotspot mode to prevent unauthenticated devices from accessing and monitoring. The mode has two options: off and WPASKWPA2PSK. The default is off. After selecting "WPAPSKWPA2PSK", set the WPA parameters below.
-
Page 24: Ap+Sta Mode
/ xDAQ-600 (P) Operation Manual Set the WPA algorithm, password and key update interval. After saving successfully, the client needs to fill in the password set here when connecting to WIFI. 3.2.4 Station List Users can use this project to monitor clients connected to XDA-Q600 in wireless hotspot mode. - Page 25 / xDAQ-600 (P) Operation Manual When the XDAQ-600 is in the wireless hotspot + client mode, you can first find the available wireless hotspots by scanning the hotspot (such as inserting the 4G wireless network card of the XDAQ-600).
- Page 26 / xDAQ-600 (P) Operation Manual Select a hotspot, and the wireless client parameter section will be filled in automatically. If a password is set for this hotspot, please enter the password in the "Password" input box, and then click the "Apply" button.
- Page 27 / xDAQ-600 (P) Operation Manual After a while, if you want to know if the connection is successful at this time, you can visit the Connection Status page. 3.3.3 Connection Status Page 27...
-
Page 28: System Management
/ xDAQ-600 (P) Operation Manual 4. System Management The system includes "Basic Settings", "Configuration File", "Certificate Update", "Firmware Update", and "Log Level". 4.1 Basic Settings Users can use this project to set basic settings, including remote tool settings, language settings, adminstrator settings, user settings, network time settings, and network ID settings. -
Page 29: Settings Management (Configuration File)
/ xDAQ-600 (P) Operation Manual 4.2 Settings Management (Configuration File) Users can use this project to export system settings files for saving system settings, import configuration files to restore the system, and restore system factory settings. The page looks like this :... -
Page 30: Certificate Update
4.3 Certificate Update Users can use this item to set APNS certificate, import and configure APS client. 4.4 Firmware Update Users can use this project to upgrade the xDAQ-600 firmware. The page is as shown below : Page 30... -
Page 31: Log Level
/ xDAQ-600 (P) Operation Manual 4.5 Log Level Users can use this project to set the log level. After setting the log level and output target for a certain item, you need to click "Change Priority" to take effect. - Page 32 / xDAQ-600 (P) Operation Manual Page 32...
