- Page 1 Rev: 17-01-17...
- Page 5 I. Screw 4 cam bolts (#A) into the left side panel (#3) and the right side panel (#4) using a Phillips screwdriver. II. Insert the other end of the cam bolts (#A) into the bottom panel (#5). III. Insert cam locks (#B) into the pre-drilled holes on the bottom panel (#5) and lock using a Phillips screwdriver.
- Page 6 I. Screw 7 cam bolts (#A) into the front panel (#2) using a Phillips screwdriver. II. Insert the other end of the cam bolts (#A) into the left side panel (#3), the right side panel (#4) and the bottom panel (#5). III.
- Page 7 I. Align the bottom assembly to the bottom panel (#5). II. Insert flat washer (#L) onto the bolt (#K) then secure using the Allen wrench (#M). Align the hinges (#F) to the pre-drilled holes located on the back panel (#1) and top panel (#6) insert screw (#G).
- Page 8 I. Align the left support (#C) and right support (#D) to the corners and insert screw (#E). Secure using a Phillips screwdriver. II. Align handle (#H) to the pre-drilled holes along the sides and insert the bolts (#I). Secure using a Phillips screwdriver. III.
