EEI-2247
SUNBED
Thank you for purchasing the MODWAY SUNBED！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approx assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that has been provided.
6.Please keep all fitting out of reach of children.

Component:

1
Front Leg
x1
Customer Service 908-368-1025︱www.modwayfurniture.com
2
1
2
Lounge Back

Hardware:

A
B
C
x1
Bolt M6x25mm
x4
Bolt M6x35mm
x4
Allen Wrench
x1
3
3
Back Leg
x1
Page 1 of 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shore EEI-2247 and is the answer not in the manual?

Questions and answers

Related Manuals for modway Shore EEI-2247

Summary of Contents for modway Shore EEI-2247

  • Page 1 EEI-2247 SUNBED Thank you for purchasing the MODWAY SUNBED！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2.Owing to the size and weight of the bed, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
  • Page 2 EEI-2247 SUNBED STEP 1: Remove the plastic covers which pre-install in the end of side rail on the Lounge Back(2) by using Allen Wrench (C). Insert Lounge Back (2) into Back Leg (3) as shown by two adults. Insert 2 pieces of Bolt (A) from the pre-drilled holes on the bottom of the Lounge Back (2) into each side on the bottom of Back Leg (3).
