JONES CLOTHING RACK
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED:
Phillips head screwdriver
Do not throw away packing materials and carton until after assembly.
Assemble all parts on a clean, smooth surface
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight. Do not place over heat or air conditioning
Blot spills, do not rub, with a clean white cloth.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
A x4
B x2
C x2
D x1
G x2
E x1
F x1
(c) Screw
(b) Screw
(a) Screw
(d) nut
[M6x10mm] x9pcs
[M6x28mm] x8pcs
[M6] x5pcs
[M6x50mm] x2pcs
( g ) Open end wrench
(e) Screw
(f ) Allen Key
[M10] x1pc
[M4x28mm] x4pcs
[4mm] x1pc
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.
© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
Page 1 of 4
Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
Advertisement
Table of Contents
Summary of Contents for URBAN OUTFITTERS JONES 54463229
- Page 1 [M10] x1pc [M4x28mm] x4pcs [4mm] x1pc EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights. Page 1 of 4 Any unauthorized reproduction, adaptation, distribution or other infringement will be prosecuted.
- Page 2 Align tube (A) with tube (C). Press firmly together and insert bolt (c). Tighten with supplied hex key (f). EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
- Page 3 (a) and tighten with supplied hex key (f). Tighten all bolts completely. STEP 4. Align bottom shelf as shown. Insert screws (e). Tighten with screwdriver (not included). EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights.
- Page 4 STEP 5. Align back brace from STEP 1 with the assembled frame as shown. Insert bolt (b) and nut (d). Tighten with supplied hex key (f) and wrench (g). STEP 6 EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC. © 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent rights. Page 4 of 4...
