Wulfsberg Electronics VSC 40C Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PRINTING INSTRUCTIONS
VCS-40C VHF Communication System
Installation Manual
150-042001, Rev H
Pages 3 through 44 are A size (8-1/2 X 11). They can be
printed single-sided or double-sided.
Pages 45 through 49 are B size (11 X 17). They can be
printed on A size or B size paper.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSC 40C and is the answer not in the manual?

Questions and answers

Summary of Contents for Wulfsberg Electronics VSC 40C

  • Page 1 PRINTING INSTRUCTIONS VCS-40C VHF Communication System Installation Manual 150-042001, Rev H Pages 3 through 44 are A size (8-1/2 X 11). They can be printed single-sided or double-sided. Pages 45 through 49 are B size (11 X 17). They can be printed on A size or B size paper.
  • Page 2 This page intentionally left blank.
  • Page 3 02-27-07 L Evans J Jensen THIS COVER SHEET IS FOR WULFSBERG ELECTRONICS INTERNAL USE. IT IS NOT TO BE PUBLISHED WITH THE DOCUMENT IT DESCRIBES THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF WULFSBERG ELECTRONICS, A CHELTON GROUP COMPANY, NEITHER RECEIPT NOR POSSESSION THEREOF CONFERS ANY RIGHT TO REPRODUCE OR USE, OR...
  • Page 4 This page intentionally left blank.
  • Page 6 In addition, Wulfsberg Electronics makes no warranty with regard to the documentation or data contained herein. Wulfsberg Electronics is not liable in the event of incidental, special, consequential, or any other damages in connection with or arising from furnishing, performance, or use of this manual.
  • Page 7 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Record of Revisions Date Date Date Inserted Date Inserted 10/2001 4/2002 8/2002 10/2003 8/2004 12/2004 3/2005 3/2007 Publication No. 150-042001 Page iii Rev. H Table of Contents Mar 2007...
  • Page 8 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Record of Revisions Date Date Date Inserted Date Inserted Page iv Publication No. 150-042001 Table of Contents Rev. H Mar 2007...

  • Page 9: Table Of Contents

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL TABLE OF CONTENTS Section Page SECTION 1 – GENERAL INFORMATION Introduction .......................... 1-1 Applicability........................... 1-1 Equipment Description ......................1-1 VC-401C VHF Communications Transceiver............... 1-1 CD-402C Control Display Unit ..................1-1 Available Configuration Variations ..................1-2 Technical Specifications ......................
  • Page 10 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL LIST OF FIGURES Figure/Title Page Three Radio System Transmit Interlock Wiring............2-3 VC-401C Outline Drawing ..................2-5 VC-401C Mounting Tray Envelope Drawing (2 Sheets).......... 2-7 RF Cable Fabrication ................... 2-11 VC-401C Rack Mount Connector ................. 2-12 VC-401C Polarizing Post Assembly ..............

  • Page 11: Section 1 - General Information

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL SECTION 1 – GENERAL INFORMATION Introduction This section contains information relative to the physical, mechanical, and electrical characteristics of the Wulfsberg VCS 40C VHF Communications System. This manual is applicable only to VC-401C Transceiver and CD-402C Control Display. Applicability This manual applies to VC-401C Transceivers and CD-402C Control Displays.

  • Page 12: Available Configuration Variations

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL The system uses full-time self-test to monitor key internal circuits and to display the word "FAIL" followed by a preassigned number to indicate which specific module has failed. Refer to the Pilot’s Guide for FAIL message details. The system is designed for compatibility with ARINC Characteristic 429 Digital Information Transfer System to allow external frequency control of the VHF communications system.

  • Page 13: Technical Specifications

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Technical Specifications Table 1-3. VC-401C Specifications CERTIFICATION: Transmitter TSO-C37d, DO-186A Class 3 & 5, and EUROCAE ED-23B. Receiver TSO-C38d, DO-186A Class C & E, ICAO Annex 10, and EUROCAE ED-23B. Intermodulation Paragraph 2.2.10 (EUROCAE ED-23B, Section 3.1.10) Desensitization Paragraph 2.2.11 (EUROCAE ED-23B, Section 3.1.11) FCC IDENTIFICATION:...
  • Page 14 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 1-3. VC-401C Specifications (Cont'd) FREQUENCY CONTROL: Gray Code/ARINC 429 Label Description TX(Out) RX(In) Eq. ID BCD BNR notes 25 kHz not 04D 8.33 kHz not 033, 10A, 10B The VC-401C has two ARINC 429 buses. Data received on either of the ARINC input channels will tune the radio.
  • Page 15 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 1-3. VC-401C Specifications (Cont'd) SIDETONE OUTPUT: 10 mW into 600 ohms (90% modulation) for -50, -51, -60, -61 20 mW into 600 ohms (90% modulation) for -54, -55, -64, -65 40 mW into 600 ohms (90% modulation) for -52, -53, -62, -63 SIDETONE FIDELITY: 6 dB maximum variation, 350 Hz to 2500 Hz DATA KEY:...

  • Page 16: Installation Kits And Accessories

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Installation Kits and Accessories A. VC-401C Connector Kits Installation of the VC-401C requires a connector kit, P/N 050-02398-0000 (see Table 1-5) and a mounting tray P/N 071-04047-0000 (see Table 1-6). Table 1-5. VC-401C Connector Kit (050-02398-0000, Rev. E) PART NUMBER DESCRIPTION 030-02704-0000...

  • Page 17: Cd-402C Connector Kits

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL B. CD-402C Connector Kits Installation of the CD-402C requires a connector kit P/N 050-02372-0000 (see Table 1-7). Table 1-8. CD-402C Connector Kit (050-02372-0000, Rev. D) PART NUMBER DESCRIPTION 030-02703-0000 CONNECTOR RD25F110JVL each 030-01058-0000 CONNECTOR PLUG, KEYING each 035-01762-0002...
  • Page 18 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 1-10. VC-401C Mounting Tray, Dual, 4 Inch, Non-Safety Wire Compatible (071-04047-0003, Rev A) PART NUMBER DESCRIPTION 154-04047 ENVELOPE DRAWING, MOUNTING TRAY, 4 INCH RF 400-04047 ASSEMBLY, MOUNTING TRAY, DUAL 4 INCH 071-04047-0002 PARTS LIST, MOUNTING TRAY, 4 INCH, NON- each SAFETY WIRE COMPATIBLE...
  • Page 19 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 1-11. VC-401C Mounting Tray Adapter Kit (050-02376-0000, Rev EB) PART NUMBER DESCRIPTION 155-05659 INSTRUCTION SHEET, DUAL TRAY KIT each 047-07849-0003 GROUND STRAP each 089-08485-0006 WASHER, EXTOOTH #6 each 200-07765-0001 PARTS LIST, BRACKET SUPPORT, LEFT each 200-07765-0003 PARTS LIST, BRACKET SUPPORT, RIGHT...

  • Page 20: Accessories Required But Not Supplied

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Accessories Required But Not Supplied Microphone with a minimum output level of 250 mV. • Headphone or speaker that accepts output rated at 2.4 Vrms into a 600 ohm impedance. • VHF Broadband Antenna with 50 Ω coaxial cable. VSWR 3:1 maximum. •...

  • Page 21: Section 2 - Installation

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL SECTION 2 – INSTALLATION General This section contains suggestions and factors to consider before installing the VC-401C and the CD-402C. Close adherence to these suggestions will assure a more satisfactory performance from the equipment. Unpacking and Inspecting Equipment Exercise extreme care when unpacking the equipment.

  • Page 22: Dual Installation Considerations

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL (3) Mark, punch, and drill the mounting holes. Care must be taken to avoid damage to adjacent equipment or cables. (4) Secure the mounting tray firmly in place. (5) Secure the VC-401C to the mounting tray. C.
  • Page 23 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Figure 2-1. Three Radio System Transmit Interlock Wiring Publication No. 150-042001 Page 2-3 Rev. H Section 2 – Installation Mar 2007...
  • Page 24 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL This page intentionally left blank. Page 2-4 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...
  • Page 25 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page and insert 154-042000, Sheet 1 of 1 (Fig. 2-2). Publication No. 150-042001 Page 2-5 Rev. H Section 2 – Installation Mar 2007...
  • Page 26 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page. Page 2-6 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...
  • Page 27 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page and insert 154-04047, Sheet 1 of 2 (Fig. 2-3a). Publication No. 150-042001 Page 2-7 Rev. H Section 2 – Installation Mar 2007...
  • Page 28 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page. Page 2-8 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...
  • Page 29 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page and insert 154-04047, Sheet 2 of 2 (Fig. 2-3b). Publication No. 150-042001 Page 2-9 Rev. H Section 2 – Installation Mar 2007...
  • Page 30 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page. Page 2-10 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...

  • Page 31: Vc-401C Harness And Connector Assembly

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL D. VC-401C Harness and Connector Assembly (1) The installing agency will supply and fabricate all external cables. The connectors and hardware required are supplied in the Wulfsberg installation kits listed in Section 1. Figure 2-4 illustrates the specific aspects of assembling the RF connector and the wiring connector housing.
  • Page 32 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Figure 2-5. VC-401C Rack Mount Connector Page 2-12 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...
  • Page 33 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 2-1. VC-401C Pin-outs DESCRIPTION DESCRIPTION D-DATA NOT USED NOT USED 429 SHIELD +28V IN NOT USED NOT USED NOT USED POWER RETURN NOT USED NOT USED NOT USED POWER RETURN DATA IN LO NOT USED NOT USED DATA OUT HI...
  • Page 34 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 2-1. VC-401C Pin-outs (cont’d) DESCRIPTION DESCRIPTION NOT USED _ARINC OUT B AUDIO SHIELD NOT USED NOT USED _ARINC IN 2B NOT USED SBY/ ACT NOT USED NOT USED NOT USED SDI BIT 9 _ARINC OUT A NOT USED NOT USED...
  • Page 35 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Figure 2-6. VC-401C Polarizing Post Assembly Publication No. 150-042001 Page 2-15 Rev. H Section 2 – Installation Mar 2007...
  • Page 36 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL This page intentionally left blank. Page 2-16 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...
  • Page 37 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page and insert 152-142100, Sheet 1 of 1 (Fig. 2-7). Publication No. 150-042001 Page 2-17 Rev. H Section 2 – Installation Mar 2007...
  • Page 38 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page. Page 2-18 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...

  • Page 39: Cd-402C Mechanical Installation

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL E. CD-402C Mechanical Installation (1) The installing agency will supply and fabricate all external cables. The connectors and hardware required are supplied in the Wulfsberg connector kits listed in Section 1. Refer to Figure 2-8 for connector assembly. Figure 2-8.
  • Page 40 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Table 2-2. CD-402C Pin-outs DESCRIPTION AUDIO HI RESERVED 8.33 ENABLE RESERVED GC 1B +28 VDC PNL DIM BUS +5 VDC/AC PNL DIM BUS AUDIO LO +10 VDC 5/28 V BACKLIGHTING 28 V HEATER P/S ENABLE GC 1A GC 2B...
  • Page 41 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page and insert 154-043000, Sheet 1 of 1 (Fig. 2-9). Publication No. 150-042001 Page 2-21 Rev. H Section 2 – Installation Mar 2007...
  • Page 42 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Remove this page. Page 2-22 Publication No. 150-042001 Section 2 - Installation Rev. H Mar 2007...

  • Page 43: Antenna Installation

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL F. Antenna Installation (1) Locate the antenna according to the manufacturer’s instructions for the antenna being used. (2) Mount the antenna on a flat metal surface to obtain a proper ground plane. Ensure the antenna is adequately grounded to the aircraft skin.

  • Page 44: Post Installation Check

    VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL Post-Installation Check Check the physical condition of the units, cables, connectors and the areas around the installations. Check to see that all mounts are secure. Check to see that all cable connections are secure.
  • Page 45 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL SECTION 3 – OPERATION General Refer to Pilot’s Guide Series III, Publication No. 150-041074. Publication No. 150-042001 Page 3-1 Rev. H Section 3 - Operation Mar 2007...
  • Page 46 VCS 40C VHF COMMUNICATION SYSTEM INSTALLATION MANUAL This page intentionally left blank. Page 3-2 Publication No. 150-042001 Section 3 - Operation Rev. H Mar 2007...
  • Page 47 Figure 2-2. VC-401C Outline Drawing (Sheet 1of 1) (Dwg. No. 154-042000, Rev. B) Publication 150-042001 Section 2 - Installation...
  • Page 48 Figure 2-3a. Mounting Tray Envelope Drawing, 4-inch Single Mount (Sheet 1 of 2) (Dwg. No. 154-04047, Rev C) Publication 150-042001 Section 2 - Installation...
  • Page 49 Figure 2-3b. Mounting Tray Envelope Drawing, 4-inch Dual Mount (Sheet 2 of 2) (Dwg No. 154-04047, Rev C) Publication 150-042001 Section 2 - Installation...
  • Page 50 Figure 2-7. VCS-40C Interconnect Diagram (Sheet 1 of 1) (Dwg No. 152-142100, Rev E) Publication 150-042001 Section 2 - Installation...
  • Page 51 Figure 2-9. CD-402C Outline Drawing (Sheet 1 of 1) (Dwg No. 154-043000, Rev E) Publication 150-042001 Section 2 - Installation...
